- Page 1 Getting Started with the RL1 www.jgroptics.com...
- Page 2 Getting Started with the RL1 This guide will give an overview of how to get started with the RL1 automated return loss meter. For more information, please visit www.jgroptics.com or email support@jgroptics.com www.jgroptics.com...
- Page 3 Getting Started with the RL1 M12 Cable Communications and charging cable for the RD-S RD-S Remote-head detector with Gen.2 integrating cavity SD00 Slide detector cap SD01 Automated return loss meter Slide FC detector adapter www.jgroptics.com...
- Page 4 Getting Started with the RL1 M12 input (from 2 RD-S) M12 output (to RL1) Micro-USB charging port • Press once: power on or reset the wireless connection • Press and hold for 7 seconds: power off • Press once: reset...
- Page 5 Getting Started with the RL1 Use the M12 cable to connect the RD-S from the output port (with the RL1 diagram) to the RL1 input port. Connect a power cable to the RL1 and turn on the unit. www.jgroptics.com...
- Page 6 Getting Started with the RL1 Swipe left and right on the front panel touchscreen to access the various pages. Swipe all the way to the right to access the Detectors page. Make sure the RD-S is turned on. Press the wireless button to turn on the RD-S.
- Page 7 Getting Started with the RL1 • Press X on an item in the Paired list to unpair a detector. • Press and hold on the touchscreen to rescan for wired detectors. www.jgroptics.com...
- Page 8 Getting Started with the RL1 To pair a new detector, press on an item in the Pair New list. Wired device Wireless device www.jgroptics.com...
- Page 9 Getting Started with the RL1 Battery indicator Ready to use Wireless signal strength www.jgroptics.com...
- Page 10 Getting Started with the RL1 Swipe two pages left to access the Setup page. RL acquisition speed DUT length Acquisition mode www.jgroptics.com...
- Page 11 Getting Started with the RL1 Optional: connect an ethernet cable to the RL1. By default, the RL1 will be assigned an IP address dynamically. This is used to access the RL1 webpage which shows device information and the steps for self-calibration.
- Page 12 Getting Started with the RL1 Swipe one page left to access the Measure page. Measurement types , RL, RL , RL dual Total • Displays system output channel and DUT length (if applicable) • Press to change outputs • Press and hold for more...
- Page 13 Getting Started with the RL1 • Tap on the touchscreen to enable real- time display • Press and hold to return to Local mode from Remote mode Tap on a column or row header to add/remove/change a test parameter www.jgroptics.com...
- Page 14 Getting Started with the RL1 Set up test parameters as desired. Real-time display: • IL has the same accuracy as a full measurement • RL has the same accuracy as Fast mode www.jgroptics.com...
- Page 15 Getting Started with the RL1 Swipe one page left to access the Reference page. • The columns and rows are auto-generated based on the RL1 configuration and peripherals • Tap on a column or row header to reference that parameter •...
