Cannondale RIZE Series Owner's Manual Supplement
  1. Manuals
  2. Brands
  3. Cannondale Manuals
  4. Bicycle
  5. RIZE Series
  6. Owner's manual supplement

Cannondale RIZE Series Owner's Manual Supplement

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
saFety inFormation ............................... 1
about this supplement .......................... 2
intended Use ............................................... 3
Building Up a Frameset ........................... 4
Bike stands ................................................... 4
extreme temperatures ............................. 4
repainting and refinishing ................... 5
tire size ......................................................... 6
rear shocks .................................................. 6
maximum Fork Length ............................ 7
Please note that the specifications and information in this manual are subject to change for product
improvement. For the latest product information, go to
READ THIS MANUAL CAREFULLY!
It contains important safety information.
Keep it for future reference.
Owner's Manual Supplement
122174.PDF
CONTENTS
rize
Frame sPeCiFiCations .............................. 8
Frame Data ................................................... 8
shock Data ................................................... 8
Geometry...................................................... 8
replacement Parts .................................... 9
integrated Headtube ..............................10
Frame Protection .....................................10
BB30 information .....................................12
seatstay ........................................................14
tightening torques .................................14
replacement Parts ..................................14
maintenanCe .............................................16
http://www.cannondale.com/tech/.
02/08

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RIZE Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cannondale RIZE Series

Summary of Contents for Cannondale RIZE Series

  • Page 1: Table Of Contents

    ..........6 tightening torques .........14 maximum Fork Length ......7 replacement Parts ........14 maintenanCe ..........16 Please note that the specifications and information in this manual are subject to change for product improvement. For the latest product information, go to http://www.cannondale.com/tech/. 02/08...

  • Page 2: About This Supplement

    Cannondale retailer. question about your bike, please contact your Cannondale Dealer immediately, or call us at one of the telephone numbers listed on the Important Composites back cover of this manual.

  • Page 3: Intended Use

    (3) heavier and have more suspension travel generalized and evolving. Consult your than a cross country bike, allowing them Cannondale Dealer about how you intend to be ridden in more difficult terrain, over to use your bike. larger obstacles and moderate jumps, (4)

  • Page 4: Building Up A Frameset

    Extreme Temperatures Before building up a frameset, consult with • Protect your carbon bike from extreme your Cannondale Dealer and the component temperatures when storing or transporting it. manufacturers, and discuss your riding style, • allow your bike to cool off or warm up before...

  • Page 5: Inspection And Crash Damage

    (see refinishing chemicals. Part ii, section D. inspect For safety in your Cannondale Bicycle owner’s manual.) WARNING Do not ride your bike if you see any sign of damage, such as broken, splintered, or repainting, painting over, retouching, or delaminated carbon fiber.

  • Page 6: Tire Size

    CPsC recommends. ASK YOUR CANNONDALE DEALER FOR THE RIGHT TIRES FOR YOUR BIKE AND ITS PARTICULAR COMPONENTS! YOU CAN BE SEVERELY INJURED, PARALYZED OR KILLED IN AN ACCIDENT IF YOU IGNORE THIS WARNING.

  • Page 7: Maximum Fork Length

    1174.PDF HEADTUBE HEADSET PARTS or ADAPTERS MAXIMUM FORK LENGTH 530 mm Maximum Fork Length (530mm) maximum Fork Length is an important frame safety testing specification. you must observe the measurement when installing headset parts, headset adapters, installing and adjusting a fork, and selecting replacement forks.

  • Page 8: Frame Specifications

    FRAME SPECIFICATIONS FRAME DATA SHOCK DATA BB SHELL WIDTH 68mm, BB30 STROKE 50mm MAX. FORK LENGTH 530mm EYE-TO EYE 200mm MAX. TIRE WIDTH 26 x 2.35in uPPER BuSHING WIDTH 22.2 ± 0.05mm SEAT POST DIA. 31.6mm LOWER BuSHING WIDTH 22.2 ± 0.05mm FRONT DERAILLuER DIA.

  • Page 9: Replacement Parts

    DOWNTUBE CHAINSTAY BB30 BOTTOM BRACKET SHELL REPLACEMENT FRAME PARTS For update-to-date kit NO.(QTY) ORDER NO. KIT DESCRIPTION information, please visit kP002/ kit,BaDGe,HeaDsHok www.cannondale.com/tech. QC843/BBQ kit,seatBinDer,mtn Qr,34.9,BLk QC842/BBQ kit,seatBinDer,mtn,34.9,BLk 3.(2) kF014/ kit,CaBLe stoP inserts-2 4.(10) kF086/ kit,GUiDes, HyDr.Brake.,10PCs kP054/ kit,GUarD,sCUFFGUarD,DowntUBe kF103/...

  • Page 10: Integrated Headtube

    PLEASE NOTE: Damage to your bike caused by cable rubbing is not a condition covered under your warranty. Also, adhesive frame guards are not a fix for incorrectly installed or routed cables or lines. If you find that applied guards are wearing out very quickly, consult with your Cannondale Dealer about the routing on your bike.
  • Page 11 1174.PDF CARBON HEADTUBE ALLOY HEADTUBE MACHINED BONDED CUPS CUPS 1 1/8” ADAPTER CARBON OR ALLOY HEADTUBE 12mm REPLACEMENT PARTS ORDER NO. KIT DESCRIPTION QsiseaL/ kit,seaL,UPPer BearinG,58mm oD HD169/ kit,BearinGs, HeaDset- 2 kP058/ kit,HeaDset,int HeaDsHok to 1 1/8” kP002/ kit,BaDGe,HeaDsHok...

  • Page 12: Bb30 Information

    SI BB30-to-68mm Standard Adapter the adapter (Cannondale kit kF365/) converts the BB30 bottom bracket cranksets for use with 68mm bottom brackets. the adapter is not a repair part and will only work in undamaged frames in good condition. improper installation or removal can result in damage and void applicable frame warranty.
  • Page 13 1174.PDF STEP 1 STEP 2 KT011/ BB30 SHELL BEARING REMOVAL KT010/ TOOL INSTALL BEARINGS WITH TOOL AND HEADSET PRESS ADAPTER ADAPTER INSTALLATION Make sure the GROOVE REMOVAL in the adapter is installed onthe DRIVE SIDE. KP009/ (68mm) ADAPTER GROOVE CIRCLIPS REMOVED KF365/ (68mm) KF366/...

  • Page 14: Swingarm, Shock Link, Seatstay

    Swingarm, Shock Link, Seatstay TIGHTENING TORQuES InLbs Loctite No. 1, 7,11 12, 17 12 REPLACEMENT PARTS ORDER NO. KIT DESCRIPTION kP069/ kit,sHoCk,FoX rP23,riZe 1,5,7(2),8(2), kP072/ kit,Link,Hware,riZe 9(6),11(2) kB61902/ kit,BearinG,1 #6902-2rs(iD-15, oD-28, tHiCk-7) 12,14(2),15 kP070/ kit,PiVot swinGarm, riZe 2(6) kP073/ kit,BearinG,6 #6800-2rs(iD-10, oD-19, tHiCk-5) kP074/ kit,LoCtite 638,10 mL...
  • Page 15 1174.PDF 121518 13mm 121833 121837 121835 121899 121899 SHOCK LINK ASSY 121835 121835 Lightly grease the shaft of 1,12 121832 before assembly. 121899 121899 121832 8TLSSA00 SEATSTAY ASSY 116357 121899 121140 121835 121836 121899 121836 121835 121834 121834 SWINGARM 19mm 116549 113510 113510...

  • Page 16: Maintenance

    Please consult your Cannondale Bicycle owner’s manual for more information on basic bike maintenance. Consult with your Cannondale Dealer to create a complete maintenance program for your riding style, components, and conditions of use. Follow the maintenance recommendations given by the component manufacturers for the various non-Cannondale parts of your bike.

Table of Contents
