Network Ports - Biamp Modena Hub Network Administrator's Manual

Some communication ports might be locked by default, typically for security reasons in routed or
restricted network segments such as public wireless access for guests. For optimal operation of
Modena Hub, ports in the table that follows should be open and without restriction.
Port
80
443
5353
8443
6000
7000-7200
20000:40000
* UDP broadcast must be enabled to allow the automatic discovery of Modena units from the app.
Physical Connections
Modena Hub/Hub+ unit has the following
external connections for networking and audio/
video connections:
1. Antenna connections (Modena Hub+ version
only)
2. Power connection
3. HDMI output
4. USB 2.0/3.0 port (Type A) input
5. RJ-45 1000Mbit
Ethernet port

Network Ports

TCP/UDP
TCP
TCP
UDP
TCP
UDP
TCP
UDP
1
Notes
Web GUI (HTTP)
Web GUI (HTTPS)
Zeroconf Service
Hub-Apps communication
*Automatic discovery service
Client video streams
WebApp webRTC
3
2 4
1
5
