- Page 1 Technical documentation WING W100-200 Check us on WING E100-200 WING C100-200 WG-ver.2.1 (09.2017)
-
Page 2: Table Of Contents
WING W100-200 WING E100-200 WING C100-200 ORIGINAL INSTRUCTION TABLE OF CONTENTS 1. INTRODUCTION ..........................................................3 1.1. PRECAUTIONS, REQUIREMENTS, RECOMMENDATIONS .............................................3 1.2. TRANSPORT ..........................................................3 1.3. INITIAL STEPS TAKEN BEFORE THE INSTALLATION .............................................3 2. STRUCTURE, INTENDED USE, PRINCIPLE OF OPERATION ............................................3 2.1. INTENDED USE ..........................................................3 2.2. -
Page 3: Introduction
1. INTRODUCTION 1.1. PRECAUTIONS, REQUIREMENTS, RECOMMENDATIONS Detailed analysis of this documentation, as well as assembly and use of equipment, according to the descriptions contained therein, and following all safety requirements, is the basis for the correct and safe operation of the device. Any other use that contradicts this instruction may cause accidents with serious consequences. Unauthorised personnel should have limited access to the device, while the personnel should be properly trained. -
Page 4: Structure (Wing W100-200, E100-200, C100-200)
WING W100-200 WING E100-200 WING C100-200 2.3. STRUCTURE (WING 100-200) WING E100-200 – ELECTRIC AIR CURTAIN WING C100-200 – COLD AIR CURTAIN WING W100-200 – WATER AIR CURTAIN 1. Electric heaters 1. Control system 1. Heat exchanger 2. Control system 2. -
Page 5: Assembly/ Disassembly Of Side Covers
The range of the air jet - assembly height - horizontal installation - vertical installation fan speed fan speed height of assembly [m] width of the door [m] WING W100, W150, W200 WING W100, W150, W200 WING E100, E150, E200 WING C100, C150, C200 WING C100, C150, C200 9-10,5 m/s*... -
Page 6: Horizontal Assembly With Using Instalation Handles
WING W100-200 WING E100-200 WING C100-200 3.2.1. HORIZONTAL ASSEMBLY WITH USING INSTALATION HANDLES. It is possible to assemble WING do the wall horizontally in two options: OPTION I: Assembling handles with their arms faced downwards. In this option you should first screw the installation handles to the wall (1) with intervals W1 for a 1m curtain (there are 2 installation hanles) and W1, W2 for 1.5m and 2m curtain (there are 3 installation handles) so that the handles' arms are levelled. -
Page 7: Vertical Assembly With Using Instalation Handles
3.2.2. VERTICAL ASSEMBLY WITH USING INSTALATION HANDLES. It is possible to assemble WING to a wall vertically on both sides of the gate (with the motor on the bottom or on the top). For this option it is not important if you screw the handles down to the unit first and then screw the whole down to the wall or first attach the handles to the wall and then screw the curtain down to the handles. - Page 8 WING W100-200 WING E100-200 WING C100-200 VENTING OF DEVICE/DRAINING OF HEATING MEDIUM Ventin of the curtain water coil followed by loosening the union connection on the outlet connection. In case of the vertical assembly with the coils connection on the bottom side, the acces to the vent valve is by removing the side cover.
-
Page 9: Elements Of Automatics
Recommended safety devices and wires WING W100-200 WING E100-200 WING C100-200 Device 1,5m 1,5m 1,5m Overload and short circuit protection C6/6kA B16/3/6kA B20/3/6kA B25/3/6kA C6/6kA IDN=30mA type AC lub A IDN=30mA type AC lub A IDN=30mA type AC lub A Differential current protection IN=16A IN=40A... -
Page 10: Start-Up, Operation, Maintenance
WING W100-200 WING E100-200 WING C100-200 5. START-UP, OPERATION, MAINTENANCE 5.1. START-UP/PUTTING INTO OPERATION ● Prior to the commencing of any installation or maintenance work, disconnect power supply and secure it against unintentional reactivation. ● It is recommended to use filters in the hydraulic system. It is recommended to clean/rinse the system, draining a few litres of water, prior to the connecting of hydraulic conduits (the supply conduits, in particular). -
Page 11: Complaint Procedure
It is forbidden to place, dispose of and store worn-out electric and electronic equipment, together with other waste. Dangerous compound contained in electronic and electric equipment have a very adverse impact on plants, micro-organisms, and, most importantly, on humans, as they damage our central and peripheral nervous system, as well as circulatory and internal system. -
Page 12: Technical Data
WING W100-200 WING E100-200 WING C100-200 8. TECHNICAL DATA 8.1 WATER AIR CURTAIN – WING W100-200 – temperature of water at the inlet to the device – temperature of water at the outlet from the device – temperature of air at the inlet to the device –... -
Page 13: Electric Air Curtain - Wing E100-200
8.2 ELECTRIC AIR CURTAIN – WING E100-200 – temperature of air at the inlet to the device – temperature of air at the outlet from the device – heating output of the device Parametry WING E100 WING E150 WING E200 [°C] III/1850[m³/h]/62dB(A)* III/3150[m³/h]/62dB(A)*... -
Page 14: Technical Information To The Regulation (Eu) No 327/2011 Implementing Directive 2009/125/Ec
WING W100-200 WING E100-200 WING C100-200 10. TECHNICAL INFORMATION TO THE REGULATION (EU) NO 327/2011 IMPLEMENTING DIRECTIVE 2009/125/EC WING 100 EC WING 150 EC WING 200 EC 28.5% 27.5% 28.0% Total VSD-No 2016 VTS Plant Sp. z o.o., CRN 0000144190, Poland 1-2-2801-0232 1-2-2801-0233 1-2-2801-0234... -
Page 15: Complaint Form
11. Complaint Form VTS POLSKA Sp. z o.o. Al. Grunwaldzka 472 A 80-309 Gdańsk Polska www.vtsgroup.com The company submitting the notification: The company that installed the equipment: Date of notification: Type of device: Factory number*: Date of purchase: Date of installation: Place of installation: Detailed description of defect: Contact person:...
