Generac Power Systems QT Series Owner's Manual page 61

(2) 1 0F58660ST01
(2) 2 0F58610ST01
(2) 3 0F58650ST01
(3) 4 0F58640AL01
(2) 5 0F58620ST01
(2) 6 0F58630ST01
(3) 7 0F58600AL01
8 0C2454
9 0E3257
10 0E5968
11 0F3949L
12 0F2766
14 0F3185
15 0F3416
16 0F3949E
17 0C2634A
18 022473
19 022097
20 022127
21 0F3072
22 078115
25 0F5048D
26 0F5049
27 0F3949B
29 0F4073A
30 0F4073F
31 087233
32 0F3180
33 0F3635C
34 0F4073
35 0F3890B
36 0F4073B
37 0F3890A
38 042568
40 022447
41 049813
(1) 42 077992
43 0912970094
44 0F8869D
45 078115A
46 066760
(2) NOTE: PART NUMBER SHOWN IS FOR TAN / STEEL. REFER TO THE SAMPLE
GUIDE BELOW FOR AVAILABLE COLOR AND/OR ALUMINUM PART NUMBER FORMAT.
0FXXXX0ST01 = TAN / STEEL
0FXXXX0AL01 = TAN / ALUMINUM
0FXXXX0ST08 = T- GRAY / STEEL
0FXXXX0AL08 = T- GRAY / ALUMINUM
0FXXXX0ST05 = WHITE / STEEL
0FXXXX0AL05 = WHITE / ALUMINUM
(3) PART NUMBER SHOWN IS FOR TAN. SEE GUIDE BELOW FOR AVAILABLE COLOR AND PART NUMBER
FORMAT.
0FXXXX0AL08 = T- GRAY / ALUMINUM
0FXXXX0AL05 = WHITE / ALUMINUM
1 REAR WRAP C3
4 DOOR C3
2 CENTER SUPPORT C3
2 DISCHARGE DUCT LH & RH SIDE C3
2 FRONT CORNERS C3
1 DISCHARGE CENTER DUCT C3
1 ROOF C3 ALUM
40 SCREW THF M6-1 X 16 N WA Z/JS
6 SCREW TH-FRM M6 W/CAP SHKPRF W
1 GASKET EXTRUDED TRIM (547" LG)
3 INSULATION SPLITTER SML
3 SPLITTER
2 STRINGER SPLITTER C3
2 SUPPORT SPLITTER C5 130KW
1 INSULATION ROOF TOP REAR
1 ASSEMBLY COVER ACCESS
5 WASHER FLAT 1/4-M6 ZINC
1 WASHER LOCK M6-1/4
1 NUT HEX 1/4-20 STEEL
12 INSULATION RETAINMENT HANGER
30 WASHER SELF LOCKING DOME #4-40
4 VISE-ACTION LATCH SLOTTED CIR
4 TAB PULL
3 INSULATION SPLITTER
1 INSULATION ROOF TOP
1 INSULATION DUCT TOP
2 RIVET POP .1875 X .450 SS
1 SPLITTER EXTENDED LENGTH
1 INSULATION SPLITTER EXTENDED LENGTH
4 INSULATION DOOR
11 RETAINER INSULATION (820)
1 INSULATION DUCT FRONT
5 RETAINER INSULATION (740)
4 SCREW HHC M6-1.0 X 20 G8.8
4 WASHER SHAKEPROOF INT 1/4
4 NUT HEX M6 X 1.0 G8 YEL CHR
29 NUT HEX LOCK M6-1.0 SS NY INS
4 ASSY WIRE 14 AWG 34.8" GRN/YEL
1 KEY VISE-ACTION LATCH SLOT CIR
10 WASHER SELF LOCKING DOME #8-32
1 STRIP SEALANT 1/8 X 1 (44.52"LG)
0FXXXX0ST13 = BISQUE / STEEL
0FXXXXALT13 = BISQUE / ALUMINUM
0FXXXX0ST14 = GRAY / STEEL
0FXXXXALT14 = GRAY / ALUMINUM
0FXXXXALT13 = BISQUE / ALUMINUM
0FXXXXALT14 = GRAY / ALUMINUM
