Generac Power Systems QT Series Owner's Manual page 35

1 0F3182 1
0F6194 1
0G0993 1
0G0998 1
0G0991 1
0G0997 1
2 0F3183 1
0F6195 1
0F6203 1
0G0994 1
0G0996 1
0G1000 1
0G1048 1
0G1049 1
0G0992 1
0G0995 1
0G0999 1
0G1094 1
0G1095 1
3 068405C 1
4 087272 1
5 072878 1
6 0C9708 REF
7 0F3726B 1
8 0C2454 9
9 023454 1
10 0F8408 4
11 046526 4
12 0A2601 1
13 072879 1
14 052646 4
15 043123 4
16 051779 4
17 092950 1
18 04576100CJ 4
19 022155 2
20 0C2428 2
21 023484N 1
22 022392 2
23 052259 2
24 051769 3
25 0E7230 3
26 0F3033 1
27 0F2722 1
28 083549 4
29 020151 1
30 023365 3
31 033133 1
32 033143 2
33 086032 2
34 090063 1
35 090064 1
36 090152 1
37 022661L 1
38 028739A 2
39 085662D 1
40 068113A 1
41 068406 1
42 0F6834 1
43 023484N 1
44 * 052624 1
* ROTOR REPLACEMENT PARTS.
** PARTS INCLUDED WITH TRANSFORMER.
ROTOR 390 70AB3 CPL
ROTOR 390 70KB3 CPL
ASSY RTR 390 45AB3 CPL
ASSY RTR 390 45KB3 CPL
ASSY RTR 390 55KB3 CPL
ASSY RTR 390 55AB3 CPL
STATOR 390 70AB3 CPL
STR 390 70KB3 CPL
STR 390 70GB3 CPL
ASSY STR 390 45GB3 CPL
ASSY STR 390 45KB3 CPL
ASSY STR 390 45AB3 CPL
ASSY STR 390 45JB3 CPL
ASSY STR 390 45 LB3 CPL
ASSY STR 390 55GB3 CPL
ASSY STR 390 55KB3 CPL
ASSY STR 390 55AB3 CPL
ASSY STR 390 55JB3 CPL
ASSY STR 390 55LB3 CPL
EXITER FIELD 2"LG SPD CONN
ASSY EXCITER 2.00" STK
KEY SQ 3/8 X 3-1/4 STEEL
INSTR HYPOT TEST (NOT SHOWN)
ASSY FLYWHEEL CPL
SCREW THF M6-1 X 16 N WA Z/JS
KEY WOODRUFF #E
SCREW HHC M10-1.50 X 16 G10.9
WASHER LOCK M10
SCREW HHC M16-2.0 X 45 G8.8
SPACER .69 X 2.75 X .37 ST/ZNC
WASHER FLAT M14
WASHER LOCK M14
NUT HEX M14-2.0 G8 YEL CHR
COLLAR SLIP FIT 390 MM
STUD M14-2.0 X 650 G5 ZINC
WASHER LOCK #6
SCREW PHTT #6-32 X 1/2 ZYC
BUSHING SNAP SB-2.5-31
PIN DOWEL 1/2 X 1-1/4
WASHER FLAT M12
WASHER LOCK M12
SCREW HHC M12-1.75 X 80 G10.9
SHIELD ALT EXCITER 390
COVER EXCITER SHIELD
SLEEVE RUBBER
CLAMP VINYL .312 X .203 Z
WASHER SHAKEPROOF INT #8
SCREW HHM #8-32 X 3/8
SCREW HHM #8-32 X 7/8
LUG RT-ANG #10/10-12
BRIDGE SUPPORT DIODE 15"
CAP END ROTOR 390MM
ASSY BRIDGE RECTIFIER
SLEEVING UL #0 .330 ID (3" LG)
TIE WRAP UL 3.9" X .10" BLK
TIE WRAP UL 17.7 X .35 BLK HT
REAR BEARING CARRIER CPL
SCREW HHC M12-1.75 X 60 G10.9
MOUNT CT'S 5.4L & 6.8L
BUSHING SNAP SB-2.5-31
BEARING BALL 6212 SEALED
