This product conforms to UL962, certified to CAN/CSA C22.2 No. 203
When using an electrical furnishing, basic precautions should always be followed, including the following:
Read all instructions before using this table.
DANGER
- To reduce the risk of electric shock:
1. Always unplug this furnishing from the electrical outlet before cleaning.
WARNING
- TO REDUCE THE RISK OF BURNS, FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS:
1.
Unplug from outlet before putting on or taking off parts.
2.
Close supervision is necessary when this furnishing is used by, or near children, invalids, or disabled persons.
3.
Use this furnishing only for its intended use as described in these instructions. Do not use attachments not
recommended by the manufacturer.
4.
Never operate this furnishing if it has a damaged cord or plug, if it is not working properly, if it has been dropped or
damaged, or dropped into water. Return the furnishing to a service center for examination and repair.
5.
Keep the cord away from heated surfaces.
6.
Do not use outdoors.
7.
Do not operate where aerosol (spray) products are being used or where oxygen is being administered.
8.
To disconnect, turn all controls to the off position, then remove plug from outlet.
WARNING
9.
GROUNDED OUTLET ONLY.
The 120VAC power outlet accessory must be grounded. If it should malfunction or breakdown, grounding provides a path
of least resistance for electric current to reduce the risk of electrical shock. The 120VAC power outlet accessory is equipped
with a cord having an equipment grounding conductor and a grounded plug. The plug must be plugged into an
appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances.
DANGER
- Improper connection of the equipment grounding conductor can result in a risk of electric
shock. Check with a qualified electrician if you are in doubt as to whether the product is properly grounded. Do not
modify the plug provided with the product. If the plug will not fit the outlet, have a proper outlet installed by a
qualified electrician. No plug adapter should be used with this product. See illustration below of 120VAC power
outlet accessory plug and proper supply outlet configuration.
5VDC 20 Watt USB charger outlet accessory has a class 2 transformer. The plug configuration is shown below. The USB
charger accessory should be plugged into supply outlet configuration shown above.
CUSTOMER SERVICE PHONE: 1-800-426-8562

IMPORTANT SAFETY INSTRUCTIONS

For use with Beside Pantry
For Comercial Use Only
: RISK OF ELECTRICAL SHOCK. CONNECT 120 VAC POWER OUTLET TO A PROPERLY
SAVE THESE INSTRUCTIONS
GROUNDED
PIN
E.C.O. No:
450-150
GROUNDED
OUTLET
GROUNDED
OUTLET BOX
GROUNDED
OUTLET
or
1 of 6
Page:
Part No:
Rev:
4
7029-9983

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Beside and is the answer not in the manual?

Questions and answers

Summary of Contents for Haworth Beside

  • Page 1 IMPORTANT SAFETY INSTRUCTIONS For use with Beside Pantry For Comercial Use Only This product conforms to UL962, certified to CAN/CSA C22.2 No. 203 When using an electrical furnishing, basic precautions should always be followed, including the following: Read all instructions before using this table.
  • Page 2 BESIDE® Storage Pantry - Desk Height Installation Instructions Tools Required #1 & #2 1/8" #8 x 1/2" Screw Metal Screw #10 x 5/8" Pan Head Screw M5 X 25mm Washer Head Screw TRANSFORMER INSTALLATION (OPTIONAL) IMPORTANT! OPEN FULLY BEFORE CONNECTING WIRING #8 x 1/2"...
  • Page 3 WHEEL ADJUSTMENT Stop 1/2 way Level Unit Loosen screws Remove Screw Tighten Screws Install Screw Adjust glide to touch cabinet 0.0” Adjust #10 x 5/8" Truss, Serrated Screw CUSTOMER SERVICE PHONE: 1-800-426-8562 E.C.O. No: Rev: 450-150 Page: 3 of 6 Part No: 7029-9983...
  • Page 4 #10 x 5/8" Pan Head Screw #8 x 1/2" Screw Metal Screw BEND ALL 4 SIDES OUT M5 X 25mm Washer Head Screw CUSTOMER SERVICE PHONE: 1-800-426-8562 E.C.O. No: 450-150 4 of 6 Rev: Page: Part No: 7029-9983...
  • Page 5 OPTIONAL - REMOVAL/INSTALLATION CUSTOMER SERVICE PHONE: 1-800-426-8562 E.C.O. No: Rev: 450-150 Page: 5 of 6 Part No: 7029-9983...
  • Page 6 FRONT EDGE OF WORKSURFACE 1/2” 8-5/8” 1/8" 5-5/8” Drill (8.63) (5.63) 24” DEEP UNIT - FRONT PILOT HOLE LOCATION LEFT SIDE RIGHT SIDE 30” DEEP UNIT - FRONT PILOT HOLE LOCATION 1-5/8” (1.63) 1-5/8” (1.63) CUSTOMER SERVICE PHONE: 1-800-426-8562 E.C.O. No: Rev: 450-150 Page:...
