V-FloFan
For US only:
For 3~ fans only:
WARNING
To Reduce The Risk of Fire or Electric Shock, Do Not Use This
Fan With Any Solid-State Speed Control Device
For Canada only:
For 3~ fans only:
WARNING
NOT SUITABLE FOR USE WITH SOLID-STATE SPEED CON-
TROLS
AVERTISSEMENT: NE CONVENIENT PAS À DES REGU-
LATEURS DE VITESSE A SEMI-CONDUCTEURS.
5

Commissioning

Before initial start-up verify that:
1. Installation and electrical connection have been properly completed.
2. No foreign material is present within the fan and fan housing.
3. All necessary safety devices such as guards are in place.
Initial start-up
1. Briefly switch on the power supply and check if the impeller rotates in the
correct direction. Correct if necessary:
– For 3~ fans interchange any 2 of the 3 phases of the power supply.
– For 1~ fans contact your supplier.
2. Run the fan and check for quiet (no unusual noises), low vibration opera-
tion. Check that the current draw is within the full load limits as listed on
the rating plate and datasheet.
3. Refer to the troubleshooting section of these instructions if anything
seems out of the ordinary.
Illustration 13: V-FloFan impeller rotation direction
6

Operation

Always be alert when the fan is in operation. Immediately switch off and
isolate the fan from the power supply if anything seems out of the ordinary.
Refer to the troubleshooting section of these instructions if anything seems
out of the ordinary.
INS00003-B Original instructions
NOTICE
The V-FloFan is very susceptible to other airflows that can dis-
rupt a good functioning:
Do not use horizontal airflow fans at the same time as when the
V-FloFan is in operation.
In greenhouses, do not operate the V-FloFan when the window
vents are open.
Infrequent use
If the fan is used less frequently than once per month, run the fan each month
at least 2 hours at full speed to avoid buildup of moisture in the fan motor and
to keep the bearing lubricant in good condition.
DANGER
If the built-in thermal protection is in series with the power sup-
ply and is activated, the fan motor will automatically re-start
after cooling down.
Risk of injury due to unexpected start.
CAUTION
The fan motor can get hot during operation.
Do not touch the fan motor to prevent burns.
7

Maintenance

DANGER
Switch off and completely isolate the fan from the power supply
before commencing maintenance.
WARNING
All moving parts must be at a complete standstill before com-
mencing maintenance.
• All safety and work regulations have to comply with the applicable stand-
ards.
• All maintenance has to be carried out by maintenance personnel.
• When it is necessary for maintenance to remove safety devices such as
guards, install these safety devices again after maintenance and before
operating the fan.
7.1

Maintenance schedule

► Maintenance tasks – TO BE CARRIED OUT EVERY MONTH
1. Examine the fan housing for defects and remove any dirt that has accu-
mulated.
2. Examine the motor and remove any dirt that has accumulated on the
motor and between the motor cooling fins.
3. Examine the impeller for defects and remove any dirt that has accumu-
lated.
4. Examine the condition of the guards (if fitted) and remove any dirt that
has accumulated.
► Maintenance tasks – TO BE CARRIED OUT EVERY 3 MONTHS
1. Check the condition of the bearings.
2. Check the tightness of fasteners and fixings.
ENGLISH | 9
