Multifan V-FloFan Installation Instructions Operating Instructions page 4

1. Article number VV
2. Serial number
3. Wiring diagram
4. Voltage (V)
5. Frequency (Hz)
6. Nominal current (A)
7. Rotation speed (RPM)
8. Power (kW or PK)
9. Cos phi
10. Service factor
11. Service factor ampere
12. Full load ampere
13. Capacitor (µF/V)
14. Max. ambient temperature °C
15. Min. ambient temperature °C
16. IE2
4 | ENGLISH
Explanation type plates
25. Drip proof
26. IP class
27. Insulation class
28. TEAO (Totally Enclosed Air Over)
29. Number of phases
30. Manufacturers name
31. Manufacturers address
32. Manufacturers country
33. cURrus logo
34. CE-logo
35. CSA-logo
36. W333 bin
37. Tester code
38. Work order date
39. Fan type
40. Imax (A)
49. µ At optimum
50. Static pressure (0 Pa)
51. Air volume at 0 Pa (m
52. Static pressure (x Pa)
3
53. Air volume at x Pa (m
54. PSE-logo
55. Fan current (A)
56. Pressure at 0 inwg.
57. Air volume at 0 inwg.CFM
58. Pressure at –x- inwg.
59. Air volume at –x- inwg.
60. Max. ambient temperature °F
61. Min. ambient temperature °F
62. Order
63. CCC-logo
64. Motor data. For.....
Original instructions
V-FloFan
3
/h)
/h)
