- Page 2 CAUTION: SAFETY WARNING: Never let children climb on product or play with product. Do not sit or stand on product. Do not fasten a TV that is heavier than the recommended load rating to the mount. Using suitable concrete wall or wood stud wall. Improper installation may cause property damage and/or personal injury, so the installation must be done by two qualified contractors.
- Page 3 Step 1 ： Disassemble Wall Plate Unit into Two Pieces. Wall plate A1 TV plate A2 Figure 1 Step 2 ： Pls remove the plaster board on the surface of concrete wall when assembling mount on the concrete wall.Hold wall plate (A1) against wall at desired position on concrete wall, then using a pencil mark 3 hole locations .
- Page 4 Step 3: Attach TV plate (A2) to the back of TV, choose corresponding bolt, washer and spacer to fix the holes of TV rear. If the back of TV is not flat, or the bolts used to assemble TV are too long, or there is interfere between TV bracket and cable inlets, we highly recommend you to use spacers .
- Page 5 Step 5: Make sure the TV unit is horizontal, you can adjust the TV plate (360 degrees) to level the TV by loosening the nut with open-end wrench , and tighten the figure 6 nut after adjustment. ( Adjust the tilting angle (from +15° to -15°) with open-end wrench Hold the bottom of TV and adjust the TV to your desired position, tighten the nut with open-end wrench figure 6...
