- Page 1 7600 Operators Guide Page 1 of 8 665 North Reservoir Street Lancaster PA 17602 P: 800.233.0473 717.295.6935 sales@pascale.com Manual 7600OG2020REV1 For Tech Support Manuals and How To Videos go to: pascale.com/resource-library/ or email us at: sales@pascale.com...
- Page 2 7600 Operators Guide Page 2 of 8 Unpacking and Startup Unpack the Scale • DO NOT LIFT SCALE BY THE TOP SPIDER OR SUB PLATFORM! • Remove the molded foam top from the carton. On 2 lb. and 5 lb. capacity scales the platform is packaged on top of this foam.
- Page 3 7600 Operators Guide Page 3 of 8 Basic Counting Operation ✓ If a container will be used to hold items being counted, place it on the platform. ✓ Press the SAMPLE SET button, press repeatedly to scroll to the desired sample size. OR key in the sample size and press ENTER ✓...
- Page 4 7600 Operators Guide Page 4 of 8 7600 Advanced Operation. See the 7600 Technical Manual for detailed configuration and setup information Advanced Counting Operations • Auto Sample Update (In CAL 10, EnH 15 CFG 50 YPR 57 select and in...
- Page 5 7600 Operators Guide Page 5 of 8 KEYPAD SAMPLE TARE • the scale, Press the button, key in the tare weight and press the button and remove a sample quantity from the container. Key in the number of pieces and press the button.
- Page 6 1000 pieces for all the boxes. Additionally, when using a printer in the above scenario an individual box label showing a quantity of 100 and a pallet label showing 10 boxes of 100 for a total of 1000. The 7600 can be set up for: CAL 1, ACC o Manual Accumulation press the button to accumulate.
- Page 7 7600 Operators Guide Page 7 of 8 SPECIFICATIONS • LOAD CELL A/D CONVERTER • TYPE: 24-bit delta sigma (1:16,777,216) • EXCITATION: 5 VDC, 120 mA max. • SIGNAL INPUT: 16 mv • SENSITIVITY: 0.1 Uv/grad • UPDATE RATE: 30 update/second •...
- Page 8 7600 Operators Guide Page 8 of 8 Connections: RS‑232 PIN ASSIGNMENTS AND IMPLEMENTED FUNCTIONS Connection to the Serial Port is made via a DB‑9 female connector found in the access area under the scale. Internal Instrument connection is on the main board, TB2-1,2,3.
