The volume flow rate is then the product of the liquid flow velocity and the tube cross-section: Q = v × S. ELIS PLZEŇ a. s., Luční 425/15, 301 00 Plzeň, Czech Republic, phone.: +420 377 517 711, fax: +420 377 517 722 Es 90678K...
All flowmeter users are obliged to get familiar in detail with these ELIS PLZEŇ a. s., Luční 425/15, 301 00 Plzeň, Czech Republic, phone.: +420 377 517 711, fax: +420 377 517 722 Es 90678K...
Applicable to electromagnetic flowmeters of the FLONET FH30xx type series are representations and certificates referred to in Chapter 17 below, namely: • Representation on CE compliance ELIS PLZEŇ a. s., Luční 425/15, 301 00 Plzeň, Czech Republic, phone.: +420 377 517 711, fax: +420 377 517 722 Es 90678K...
Output functions (binary, frequency, pulse or current outputs, communication interface) are pre-set in production as required in the product order documentation, but the user may subsequently change the setting. ELIS PLZEŇ a. s., Luční 425/15, 301 00 Plzeň, Czech Republic, phone.: +420 377 517 711, fax: +420 377 517 722 Es 90678K...
70°C; • space limitations not permitting application of the compact meter version; ELIS PLZEŇ a. s., Luční 425/15, 301 00 Plzeň, Czech Republic, phone.: +420 377 517 711, fax: +420 377 517 722 Es 90678K...
Page 11
Meter installation in the fluid piping: • Flanged meter version • Wafer meter version (sensor to be fitted between two flanges) ELIS PLZEŇ a. s., Luční 425/15, 301 00 Plzeň, Czech Republic, phone.: +420 377 517 711, fax: +420 377 517 722 Es 90678K...
3E0 according to EN1092-1, such as steel P245GH or P265GH ** available on special request for sensor sizes in excess of DN300 ELIS PLZEŇ a. s., Luční 425/15, 301 00 Plzeň, Czech Republic, phone.: +420 377 517 711, fax: +420 377 517 722 Es 90678K...
Page 13
PS and TS parameters. Pressure vs. temperature classes of flanges according to standard EN 1092-1 Maximum permitted temperature TS (°C) ELIS PLZEŇ a. s., Luční 425/15, 301 00 Plzeň, Czech Republic, phone.: +420 377 517 711, fax: +420 377 517 722 Es 90678K...
Fluid flow velocity in a piping can be calculated using the formula: 0.0003536 × Q (m/s, m /h, m) ELIS PLZEŇ a. s., Luční 425/15, 301 00 Plzeň, Czech Republic, phone.: +420 377 517 711, fax: +420 377 517 722 Es 90678K...
Page 15
Relationship between fluid flow velocity and flow rate for various sensor sizes Provozní rozsahy průtoků a rychlostí v závislosti na dimenzi čidla Flow rate Q (l/s) ELIS PLZEŇ a. s., Luční 425/15, 301 00 Plzeň, Czech Republic, phone.: +420 377 517 711, fax: +420 377 517 722 Es 90678K...
It is recommended to store the meter in complete transport packaging and remove the covers and packaging materials only immediately before installation. ELIS PLZEŇ a. s., Luční 425/15, 301 00 Plzeň, Czech Republic, phone.: +420 377 517 711, fax: +420 377 517 722 Es 90678K...
In cases of bi-directional flow measurement, the basic required length of straight piping sections in front of and behind the flowmeter is 5DN. ELIS PLZEŇ a. s., Luční 425/15, 301 00 Plzeň, Czech Republic, phone.: +420 377 517 711, fax: +420 377 517 722 Es 90678K...
Increased pressure in the piping system will keep the fluid above the saturated vapour pressure and prevent cavitation effects. ELIS PLZEŇ a. s., Luční 425/15, 301 00 Plzeň, Czech Republic, phone.: +420 377 517 711, fax: +420 377 517 722 Es 90678K...
The permitted deviation of the electrode axis from the horizontal plane is 15° in both fluid flow directions. The free discharge point shall be higher by 2DN than the sensor output end. ELIS PLZEŇ a. s., Luční 425/15, 301 00 Plzeň, Czech Republic, phone.: +420 377 517 711, fax: +420 377 517 722 Es 90678K...
• Tighten the bolts along the flange perimeter in a crosswise manner, each in three steps: 50, 80 and 100% of the specified torque. Do not use torque in excess of the recommended/specified value. ELIS PLZEŇ a. s., Luční 425/15, 301 00 Plzeň, Czech Republic, phone.: +420 377 517 711, fax: +420 377 517 722 Es 90678K...
Page 24
• • 1200 Comment: ●… Non-standard sensor sizes; parameters to be specified within the product ordering process ELIS PLZEŇ a. s., Luční 425/15, 301 00 Plzeň, Czech Republic, phone.: +420 377 517 711, fax: +420 377 517 722 Es 90678K...
Page 25
The flange tightening torque for rubber or E-CTFE-lined sensors depends on the seal material and the sensor design version. Consult this issue with the seal supplier. ELIS PLZEŇ a. s., Luční 425/15, 301 00 Plzeň, Czech Republic, phone.: +420 377 517 711, fax: +420 377 517 722 Es 90678K...
The relationship between the measured fluid conductivity and the maximum length of the cables connecting the meter transmitter and sensor is shown in the following graph: ELIS PLZEŇ a. s., Luční 425/15, 301 00 Plzeň, Czech Republic, phone.: +420 377 517 711, fax: +420 377 517 722 Es 90678K...
Page 28
Cable extension or shortening is not permitted. Replacement of a damaged cable shall be arranged with the meter manufacturer. ELIS PLZEŇ a. s., Luční 425/15, 301 00 Plzeň, Czech Republic, phone.: +420 377 517 711, fax: +420 377 517 722 Es 90678K...
This PE terminal is located at the bottom of the terminal box of the instrument box. ELIS PLZEŇ a. s., Luční 425/15, 301 00 Plzeň, Czech Republic, phone.: +420 377 517 711, fax: +420 377 517 722 Es 90678K...
In cases of power cut, the current output will preserve the last value prior to the power failure. ELIS PLZEŇ a. s., Luční 425/15, 301 00 Plzeň, Czech Republic, phone.: +420 377 517 711, fax: +420 377 517 722 Es 90678K...
Page 33
“greater than” or “lower than”. Therefore, the user may select any one of six possible functions of I vs. flow rate Q: ELIS PLZEŇ a. s., Luční 425/15, 301 00 Plzeň, Czech Republic, phone.: +420 377 517 711, fax: +420 377 517 722 Es 90678K...
Page 36
Cu conductor of cross-section 4mm This connection shall not serve the purpose of potential equalisation with any other equipment or devices. ELIS PLZEŇ a. s., Luční 425/15, 301 00 Plzeň, Czech Republic, phone.: +420 377 517 711, fax: +420 377 517 722 Es 90678K...
• Undesirable meter warming by external heat sources; • Excessive temperature stress on cable insulation; • Vibrations and shocks in the piping, and others. ELIS PLZEŇ a. s., Luční 425/15, 301 00 Plzeň, Czech Republic, phone.: +420 377 517 711, fax: +420 377 517 722 Es 90678K...
Detailed description of the meter control procedures is given in the manual: Es 90686K Electromagnetic flowmeters of the type series FLONEX FXx11x and FLONET FH30xx Meter control instructions ELIS PLZEŇ a. s., Luční 425/15, 301 00 Plzeň, Czech Republic, phone.: +420 377 517 711, fax: +420 377 517 722 Es 90678K...
Page 42
Page 42 of 72 Electromagnetic flowmeter FLONET FH30xx ELIS PLZEŇ a. s. FLONET FH30xx control menu structure ELIS PLZEŇ a. s., Luční 425/15, 301 00 Plzeň, Czech Republic, phone.: +420 377 517 711, fax: +420 377 517 722 Es 90678K...
Detailed description of communication via interface RS485 MODBUS RTU is given in the manual: Es 90664K Communication interface RS-485 MODBUS RTU Electromagnetic flowmeters FLONET FH30xx and FLONEX FXx11x ELIS PLZEŇ a. s., Luční 425/15, 301 00 Plzeň, Czech Republic, phone.: +420 377 517 711, fax: +420 377 517 722 Es 90678K...
10 m/s. flow rate for fluid flow velocity at the meter sensor of 0.025 m/s ELIS PLZEŇ a. s., Luční 425/15, 301 00 Plzeň, Czech Republic, phone.: +420 377 517 711, fax: +420 377 517 722 Es 90678K...
EN 1092-1 or ANSI B16.5. Upon agreement with the manufacturer, other types of flanges can be provided. The sensor can also be supplied in all-stainless-steel design. ELIS PLZEŇ a. s., Luční 425/15, 301 00 Plzeň, Czech Republic, phone.: +420 377 517 711, fax: +420 377 517 722 Es 90678K...
Following electrical connection of the meter and closing the terminal compartment on the meter transmitter, the organisation responsible for the meter installation will secure the lid position by a self-adhesive seal. ELIS PLZEŇ a. s., Luční 425/15, 301 00 Plzeň, Czech Republic, phone.: +420 377 517 711, fax: +420 377 517 722 Es 90678K...
Non-standard dimensions; parameters to be specified within the customer order processing The weight data are of informative nature only ELIS PLZEŇ a. s., Luční 425/15, 301 00 Plzeň, Czech Republic, phone.: +420 377 517 711, fax: +420 377 517 722 Es 90678K...
10.5.2.2 Transmitter for remote meter version – sensor protection class IP 67 The signal cable is permanently attached to the transmitter Transmitter including holder: approx. weight 4kg ELIS PLZEŇ a. s., Luční 425/15, 301 00 Plzeň, Czech Republic, phone.: +420 377 517 711, fax: +420 377 517 722 Es 90678K...
Check the tightness of the power supply cable conductor connections in the respective terminals. Switch on the meter power source. ELIS PLZEŇ a. s., Luční 425/15, 301 00 Plzeň, Czech Republic, phone.: +420 377 517 711, fax: +420 377 517 722 Es 90678K...
Page 59
14.7 to 15.3V. Should it not be so, the power supply board is defective and it shall be replaced. ELIS PLZEŇ a. s., Luční 425/15, 301 00 Plzeň, Czech Republic, phone.: +420 377 517 711, fax: +420 377 517 722 Es 90678K...
Page 60
Should you fail to rectify the meter defect using the above procedures, contact the authorised flowmeter service centre or directly the meter manufacturer. ELIS PLZEŇ a. s., Luční 425/15, 301 00 Plzeň, Czech Republic, phone.: +420 377 517 711, fax: +420 377 517 722 Es 90678K...
Post-warranty product service or repair requirements shall be communicated to the manufacturer in writing (by E-mail, fax or registered post). ELIS PLZEŇ a. s., Luční 425/15, 301 00 Plzeň, Czech Republic, phone.: +420 377 517 711, fax: +420 377 517 722 Es 90678K...
Non-standard Electrode and Stainless steel 1.4571 grounding ring Hastelloy C-276 material Titanium Tantalum Platinum and rhodium Non-standard ELIS PLZEŇ a. s., Luční 425/15, 301 00 Plzeň, Czech Republic, phone.: +420 377 517 711, fax: +420 377 517 722 Es 90678K...
Page 64
24V ± 20% (19.2–28.8VDC) Transmitter Standard IP 67 protection class Improved IP 68 MEASURED FLUID Water Type of fluid Non-standard ELIS PLZEŇ a. s., Luční 425/15, 301 00 Plzeň, Czech Republic, phone.: +420 377 517 711, fax: +420 377 517 722 Es 90678K...
Page 66
Fixed current 4 to 20mA (0 to Q = Q for v = 8 m/s) Fixed current 4 to 20mA according to order ELIS PLZEŇ a. s., Luční 425/15, 301 00 Plzeň, Czech Republic, phone.: +420 377 517 711, fax: +420 377 517 722 Es 90678K...
Page 67
, OUT2 = on No error conditions OUT2 = off Permanently closed OUT2 = on OUT2 function Positive Negative ELIS PLZEŇ a. s., Luční 425/15, 301 00 Plzeň, Czech Republic, phone.: +420 377 517 711, fax: +420 377 517 722 Es 90678K...
Page 68
No calibration report issued Higher accuracy, ± 0.5% / ± 0.2%, see Section 9.3.2 Including calibration report Non-standard calibration ELIS PLZEŇ a. s., Luční 425/15, 301 00 Plzeň, Czech Republic, phone.: +420 377 517 711, fax: +420 377 517 722 Es 90678K...
Electromagnetic flowmeters FLONET FH30xx and FLONEX FXx11x Es 90686K Electromagnetic flowmeters of the type series FLONEX FXx11x and FLONET FH30xx Meter control instructions ELIS PLZEŇ a. s., Luční 425/15, 301 00 Plzeň, Czech Republic, phone.: +420 377 517 711, fax: +420 377 517 722 Es 90678K...
Provided the above safety precautions are observed and the recommended protective equipment used, the flowmeter handling will not constitute any risk to health or environment. Date Place Signature ELIS PLZEŇ a. s., Luční 425/15, 301 00 Plzeň, Czech Republic, phone.: +420 377 517 711, fax: +420 377 517 722 Es 90678K...
