- Page 2 Introduction Thank you for purchasing the Tekno RC EB48 1/8th Electric 4WD Competition Buggy. The EB48 represents the state-of-the-art in 1/8th Electric Buggy technology. We hope you have as much fun driving your new vehicle as we did developing it. We are always working on new projects, so please check our website (www.teknorc.com) regularly for the latest news, parts, and kits.
- Page 3 Bag A Center Differential (overview) TKR5112 *TKR5112X (Option) TKR5113 TKR5143 TKR5140 TKR5141 TKR5140 TKR5237 *TKR5115 (Option) TKR5112 *TKR5112X (Option) Step Step TKR5145 TKR5144 TKR5146 x4 Grease TKRBB08165 TKR1222 13x16x0.1mm Diff Shim TKR1325 Grease M3x14mm Flat Head Screw Step Grease TKR5144 Differential 0-rings Step TKR1222 x6...
- Page 4 Bag B Front/Rear Differential (overview) TKR5114 *TKR5114X (Option) TKR5111 TKR5140 TKR5143 TKR5141 TKR5140 TKR5113 TKR5114 *TKR5114X (Option) Step TKR5145 Note: Repeat for rear di Step TKR5144 Note: Repeat for rear di TKR5146 x4 Grease TKRBB08165 TKR1325 M3x14mm Flat Head Screw Step Grease Note: Repeat for rear di...
- Page 5 Bag C Front Gearbox TKR5012 TKR5028 TKR1603 (overview) TKRBB05114 TKR1222 TKR5075 TKR5110 TKR5012 Step TKR1603 Front TKRBB05114 TKRBB05114 Note: The front and rear of the car use di erent inner Thread TKR1226 bulkheads. The front is angled Lock whereas the rear is straight. Rear Note: TKR1222 and TKR1226 Shims - The gear mesh should be tight without any binding.
- Page 6 Bag D Rear Gearbox TKR1603 TKR5029 (overview) TKRBB05114 TKR1222 TKR5026 TKR5110 TKR5075 TKR5016 TKR5016 TKR1603 TKRBB05114 Front Step TKRBB05114 Note: The front and rear of the car use di erent inner TKR1226 bulkheads. The front is angled Thread Lock whereas the rear is straight. Rear Note: TKR1222 and TKR1226 Shims - The gear mesh should be tight without any binding.
- Page 7 Bag E Middle hole is stock position Wing Mount Most least downforce downforce TKR1524 TKR5026 Step TKR1524 Step TKR1221 TKR1529 TKR1221 TKR1201 TKR1201 M3 Lock Nut Black TKR1529 TKR1529 TKR1221 M3x8mm Washer TKR1524 M3x12mm Cap Head Screw TKR1529 M3x20mm Cap Head Screw...
- Page 8 Bag f Rear Suspension (overview) TKR5021 TKR1333 TKR5021 TKR5013 TKR5013 TKR5021 TKR5020 TKR1327 TKR5030 TKR5033 TKR1402 TKR5059 TKR5079 TKR5049 *TKR5079A (option) *TKR5049A TKR1525 (option) Step TKR1402 TKR1327 M3x16mm Flat Head Screw TKR1525 TKR1443 TKR1333 M3x40mm Flat Head Screw Step TKR1402 M3x8mm Button Head Screw TKR1333 TKR1333...
- Page 9 Bag f Rear Sway Bar TKR5082 - 2.4mm (Option) TKR5086 *TKR5080 - 2.2mm *TKR5081 - 2.3mm *TKR5083 - 2.5mm *TKR5084 - 2.6mm *TKR5085 - 2.8mm *TKR5087 - 3.0mm Step TKR1601 Note: Do not over-tighten 30.2 TKR1601 Step Thread Lock TKR5086 TKR1522 TKR1522 TKR1522...
- Page 10 Bag G Rear Hub/CVA Assembly TKR5072 TKR5073 TKR5070 Note: notch on pin TKR5040 needs to line up with set screw. TKR5073 Step TKRBB08165 TKR5071 Grease *TKR5071X (Option) TKRBB13194 TKR1603 Thread Lock Step Note: TKR5040 hubs are left/right interchangeable TKR1201 TKR1201 TKR5034 M3 Locknut Black TKR1201...
- Page 11 Bag G Rear Camber Links This side mounts on shock tower TKR5051 Note: ange TKR5052 This side mounts on hub TKR5051 *TKR5052A Note: no ange (Option) Left Right TKR5053 *TKR5053A (Option) TKR5053 *TKR5053A (Option) TKR5050 TKR5050 TKR5051 Step This side mounts on shock tower Note: ange This side mounts on hub TKR5051...
-
Page 12: Front Suspension
Bag H TKR5020 TKR5021 Front Suspension (overview) TKR1327 TKR5017 TKR5021 TKR5079 TKR5059 TKR5049 *TKR5049A (Option) TKR1333 TKR1525 TKR5017 TKR5036 TKR1443 TKR1525 Step TKR1443 Step Stock Position TKR1327 M3x16mm Flat Head Screw TKR1327 TKR1327 TKR1333 M3x40mm Flat Head Screw TKR1443 M4x10mm Button Head Screw TKR1525 M3x14mm Cap Head Screw TKR1333... - Page 13 Bag H Front Sway Bar TKR5081 - 2.3mm (Option) TKR5086 *TKR5080 - 2.2mm *TKR5082 - 2.4mm *TKR5083 - 2.5mm *TKR5084 - 2.6mm *TKR5085 - 2.8mm *TKR5087 - 3.0mm Step TKR1601 Note: Do not over-tighten 30.2 TKR1601 Step TKR1601 Thread TKR5086 Lock TKR1522 TKR1601...
-
Page 14: Front Steering
Bag I Front Steering TKR1445 TKR5042 Note: notch on pin TKR5073 needs to line up TKR5070 TKR5054 with set screw. *TKR5054A TKR5072 (Option) TKRBB13194 TKR5041 Step TKR5073 Grease TKR5071 *TKR5071X (Option) TKR5071 *TKR5071X TKR5054 (Option) *TKR5054A (Option) TKRBB08144 M3 x6mm button TKR1603 head screw can be used a steering stop if desired. - Page 15 Bag I Front Camber Links This side mounts on shock tower TKR5051 Note: ange This side mounts on hub TKR5052 TKR5051 Note: no ange *TKR5052A (Option) Left Right TKR5053 *TKR5053A TKR5053 (Option) *TKR5053A (Option) TKR5050 TKR5050 TKR5052 This side mounts on shock tower TKR5051 *TKR5052A Note: ange...
- Page 16 Bag J TKR5100 TKR5056 Steering Assembly TKR5056 (overview) TKR5056 TKR5123 TKR5123 TKR5052 *TKR5052A TKR5056 (Option) TKR5052 TKR5104 *TKR5052A (Option) TKR5052 *TKR5052A TKR5104 (Option) TKR5122 TKR5104 TKR5231 TKR5231 TKRBB06103 Thread TKR1323 Lock Step Step TKRBB050825 Note: Apply a small drop of oil for TKRBB050825 easy installation.
- Page 17 TKR1443 Bag K Front End Assembly Thread Lock Step Step TKR5121 TKR5107 Note Step K-2: Line up the bottom of the steering posts (TKR5102) with the corresponding recess TKR5102 cut in the chassis. *TKR5102A TKR1323 (Option) TKR1443 Step Note: Inititial bumpsteer setting is two washers above and below the steering ball link.
- Page 18 Bag L TKR1522 Center/Rear Assembly Thread Lock TKR5107 TKR5210 Step Note: If running Traktion Drive or Electri-Clutch slipper systems, reverse di direction as shown above. TKR5107 *TKR5217 (Option) (Direct drive - Mod 1 pinion) TKR5078 TKR1443 *TKR5077 (Option) Step TKR5062 TKR1344 Thread TKR1343 x5...
- Page 19 For both front and rear shocks The following steps and information will provide you with the proper way to ll and bleed your Tekno RC EB48 shocks. After thorough testing, we've found it's easiest to complete steps 1 through 3 on each shock before moving onto step 4.
- Page 20 Bag M Step Front Shock Assembly Note: front shocks use shorter shock bodies - TKR6002, Note: shorter shock shafts - TKR6004, TKR1200 shaft guide TKR6015 shorter springs - TKR6037 orientation TKR6008 and shorter shock boots - TKR6023 TKR6008 TKR6009 TKR6003 *TKR6018 (Option) TKR6002...
-
Page 21: Rear Shock Assembly
Bag N Step Rear Shock Assembly Note: rear shocks use Note: longer shock bodies - TKR6016, TKR1200 shaft guide longer shock shafts - TKR6017, TKR6015 orientation longer springs - TKR6032 TKR6008 and longer shock boots - TKR6023 TKR6008 TKR6009 TKR6003 *TKR6018 (Option) TKR6016... -
Page 22: Final Assembly
Bag O ESC (not included) TKR1525 Final Assembly TKR1221 Step double sided tape Steering servo (not included) TKR5060 TKR5065 Step TKR5125 TKR5065 Note: CA glue 3 black o-rings (TKR5125) to the bottom legs of the ESC tray. Step TKR1525 TKR1525 TKR1221 RX (not included) Note: Install ESC tray... - Page 23 TKR1322 M3x8mm Flat Head Screw TKR1445 Step TKR1341 Note: Install MOD1 M4x6mm Flat Head Screw pinion (TKR4171-4190) or Tekno RC Traktion TKR1227 Drive / Elektri-Clutch slipper system (TKR4301X) at this TKR1343 M4x10mm Flat Head Screw step. Adjust gear mesh and tighten screws Thread (TKR1445) well.
- Page 24 Bag P TKR5058 Final Assembly TKR5056 Step TKR5230 .5mm TKR5056 TKR5058 TKR1201 TKR1327 Step TKR1327 Step TKR1201 M3 Lock Nut Black TKR1327 M3x16mm Flat Head Screw TKR5058 Pivot Ball M3x5.8mm No Flange TKR5230 Note: O set servo arm so it is parallel with the connecting arm at neutral or zero servo position. M3x18 Threaded Rod...
- Page 25 Bag Q TKR1220 TKR1325 TKR5026 Wing/Wheels/Body TKR1220 TKR5026 Step TKR5237 TKR1201 Step TKR5116 Step TKR1201 M3 Lock Nut Black TKR1223 TKR1325 M3x14mm Flat Head Screw TKR1223 Body Clip TKR1223 TKR5116 Wheel Nut...
- Page 26 TKR5111 – Di erential Ring Gear (40t) TKR5000 Spare Parts List TKR5112 – Di erential Outdrives (center) TKR5000 - EB48 Electric 1/8th Scale 4WD Buggy Kit TKR5000F – Chassis (7075, hard anodized) TKR5112X – Di erential Outdrives (center, lightened) TKR5010 – Battery Tray, Mud Guard (left side) TKR5113 –...
- Page 27 SETUP SHEET Name: Date: Event: Track Conditions: Outdoor Open Loose/Loamy Dusty High Bite Low Bite Rough Indoor Tight Smooth Hard Packed Med Bite Blue Groove BUMPSTEER/ACKERMANN/SERVO SAVER SHOCKS Front Rear Piston FRONT SUSPENSION Front Rear Bladder Ride Height Spring Camber Length/ Droop TIRES...
- Page 28 Tekno RC 10755 Scripps Poway Pkwy #598 San Diego CA 92131 www.teknorc.com...
