Summary of Contents for Tekno RC ET410

  • Page 2 Body reamer Disclaimer: Tekno RC is not responsible or liable for any property or personal damage, loss, or injury incurred as a result of using this product. This kit is meant for use by persons 14 years of age or older and in the strict con nes of a legally permitted RC track or facility.
  • Page 3 Bag A TKR6514 Center Di erential (overview) TKR5144 TKR6550 TKR6511 TKR6514 TKR6515 TKR6514 TKR6513X TKR6550 TKR6517 TKR7253 TKR1303 x4 TKR6514 Step Step TKR6550 TKR6550 TKR6517 TKR6514 TKR6513X TKR5144 TKR5113 Grease Note: Apply grease to the recess inside TKR5113, where the o-ring is placed Grease as well as the o-ring itself.
  • Page 4 Bag B TKR6514 Front and Rear Di erential (overview) TKR5144 TKR6550 TKR6511 TKR6514 TKR6515 TKR6514 TKR6513X TKR6550 TKR6517 TKR7221 TKR1303 x4 TKR6514 TKR6550 Step Step TKR6550 Repeat for rear di Repeat for rear di TKR6517 TKR6514 TKR5144 TKR6513X TKR5113 Grease Note: Apply grease to the recess inside TKR5113, Grease...

  • Page 5: Steering Assembly

    Bag C Steering Assembly TKR6627 (overview) TKR6627 TKR6526B TKRBB040725 TKR6526B TKR6207 TKRBB040725 TKR6526B TKR6208 TKRBB040725 TKR6526B *TKR6560A (Option) TKR1402 TKRBB040725 TKR1402 Step TKR6207 TKR6208 TKR6526B *TKR6560A (Option) TKR6208 TKR6627 Note: Push these Step steering rack bushings hard into place until they click into the bellcranks.
  • Page 6 Bag C (assembly from previous page) TKRBB10154 Front Bulkhead Assembly (overview) TKR1402 TKR1602 TKR6597 TKRBB05114 TKRBB05114 TKR6519B TKR7222 TKRBB10154 TKR6547 TKR1301 Step Step TKR1602 Thread Lock TKRBB040725 TKR6629 Note: Use a 5.5mm nut driver to install TKR6597 steering posts. TKRBB05114 TKRBB040725 TKR6519B TKRBB05114...
  • Page 7 Bag D TKR1403 TKR6210 TKR1221 Rear Bulkhead/ Wing Mount TKR6665 TKR1201 Assembly TKR6538 TKR7281 TKR7210 *TKR7282C (overview) (Option) TKR1602 TKRBB10154 TKR1405 TKR6597 TKR6546 TKRBB05114 TKR1405x2pcs TKR6519B TKR7222 TKR6547 TKR1402 TKR1411 TKR1301 4pcs TKR1403 TKR6210 Step Step TKR1602 Thread TKR6597 Lock TKR1221 TKRBB05114 M3x8mm Washer...
  • Page 8 Bag E TKR6610 - 1.5mm Below options sold separately. Rear End *TKR6611 - 1.0mm *TKR6611 - 1.1mm Assembly *TKR6611 - 1.2mm *TKR6611 - 1.3mm *TKR6611 - 1.4mm *TKR6610 - 1.6mm Step *TKR6610 - 1.7mm TKR6547 *TKR6610- 1.8mm *TKR6610- 1.9mm (Option) TKR1601 Note: Do not over-tighten.
  • Page 9 Bag F Rear Hub/CVA Assembly TKR6856 Grease TKR6270R TKR1609 Note: These screws TKR7272 only need to be Thread TKR6545 Step snug. Do not Lock over-tighten. TKR6856 TKR6856 TKRBB10154 TKRBB06124 Rear Hub Orientation TKR5571M TKR1229 *TKR5571A Front *TKR5571 *TKR1654X (+1mm) *TKR1654 (+1mm) Left Right (Option)
  • Page 10 Bag F Rear Camber Links TKR6253 Left/Right x 2pcs Step TKR7250 TKR6253 Build Tip: Use some grease or Chapstick on the threads to help prevent “pop-o ” when adjustments are being made. Actual Size Note: Notch always goes on left side of vehicle. Build Note: Hold the turnbuckle stationary with pliers and push the rod end hard onto the turnbuckle while turning at the same time.
  • Page 11 Bag G TKR6624 - 1.6mm Below options sold separately. Front End *TKR6623 - 1.0mm *TKR6623 - 1.1mm Assembly *TKR6623 - 1.2mm *TKR6623 - 1.3mm TKR6547 *TKR6623 - 1.4mm *TKR6624 - 1.5mm *TKR6624 - 1.7mm *TKR6624- 1.8mm *TKR6624- 1.9mm Step (Option) TKR1601 Note: Do not over-tighten.
  • Page 12 Bag H DO NOT SKIP Step Front CVA / Spindle & THIS STEP! TKR1221 Repeat for Carrier Assembly both sides Note: These are steering stop screws. They provide a mechanical limit to the steering throw and make the car easier to drive by greatly improving the TKR1400 consistency of the steering.
  • Page 13 Bag I TKR6253 Step Front Camber Links TKR6253 & Steering Links TKR6250 TKR6253 TKR6253 Right TKR6250 Left Left TKR6253 TKR6250 Build Tip: Use some grease or Chapstick TKR6250 Right on the threads to help prevent “pop-o ” when TKR6253 adjustments are being made. Build Note: Hold the turnbuckle stationary TKR6253 with pliers and push the rod end hard onto the...
  • Page 14 Bag I TKR7281 Front Tower Assembly *TKR7281C (Option) TKR1405 TKR1405 TKR7210 Step TKR7210 Note: Always press on with T logo visible. Step TKR1409 TKR1403 Note: These screws only need to be snug. Do not over-tighten. TKR1403 M3x10mm Button Head Screw WASHERS TKR1405 M3x14mm Button Head Screw...
  • Page 15 Bag J A Block Inset Front/Center Assembly BLOCK Step BLOCK Note: It is nessesary to slightly loosen both screws holding the A block in place before attaching the front clip to the chassis. This is due to the fact that the A block is now TKR6501B keyed into the front of the chassis.
  • Page 16 Bag J TKR6634 Center/Rear Assembly TKR1402 TKR6634 Step TKRBB10154 Thread Lock TKR6634 TKRBB10154 *TKR6635C (Option) TKR6600 Step Step Install with hole on top, like this. TKR1211 Note: Use both rear braces for the least chassis flex. TKR6538 Use just the long rear for meduim flex and short rear for the most flex.
  • Page 17 Bag K Step Step Step Front Shock Assembly Thread Lock Refer to filling Step TKR1245 instructions on Note: Do not page 19 during over-tighten this step. TKR6705 *TKR6731 *TKR6732 *TKR6735 (Option) TKR6712 Note: 1.7mm *TKR6712A piston with (Option) writing up. TKR6704 *TKR6704T (Option)
  • Page 18 Bag L Step Step Step Rear Shock Thread Assembly Lock Refer to filling TKR1245 Step instructions on Note: Do not page 19 during over-tighten this step. TKR6705 *TKR6731 TKR6712 *TKR6732 *TKR6712A *TKR6735 (Option) (Option) Note: 1.8mm piston with writing up. TKR6757 *TKR6757T (Option)
  • Page 19 Shock Filling Instructions For both front and rear shocks We've found it's easiest to complete steps 1 & 2 on each shock before moving on to step 3. By the time you've finished step 2 on the last shock, the first one will be ready for step 3. Step 1.

  • Page 20: Final Assembly

    TKR1403 Final Assembly IMPORTANT RADIO SETUP TIPS, MUST READ: TKR1221 The Tekno RC ET410 is highly tunable, but can be very Steering servo (not included) aggressive depending on track conditions and tires used. Note: We recommend using a full To help with this, we recommend that you are well informed...
  • Page 21 Bag M Final Assembly TKR1523 Thread Lock TKR1221 TKR1523 TKR1221 Note: MESH SHOULD BE AS TIGHT AS POSSIBLE WITHOUT BINDING. Step Note: Refer to page 20 or 26 for a recommended pinion Pinion/Set screw chart to best suit your motor. Thread (not included) Lock...
  • Page 22 Bag M Note: Servo horn orientation. Step Final Assembly Actual Size TKR6526B 3.00mm *TKR6563A (Option) TKR6207 Note: Always press on with T logo visible. TKR6253 TKR5230 Step Note: Rod end orientation. TKR6253 Step TKR5126 TKR1601 Cap Head Screw (not included) SERVO HORN ALIGNMENT Note: Servo horn should be Step...
  • Page 23 Bag N Final Assembly TKR1403 TKR1403 TKR1402 Thread Lock TKR6634 TKR6634 *TKR6598C *TKR6635C TKR5230 (Option) (Option) Step TKR1402 M3x8mm Button Head Screw TKR1403 M3x10mm Button Head Screw Note: Screw in TKR5230 until 8mm of threads are still visible. TKR5230 M3x18 Threaded Rod Bag O TKR1323 TKR1323...
  • Page 24 Bag O TKR6686 TKR6686 Body/Tires Step TKR6686 TKR6686 Thumb Screw Assembly Step TKR6586 TKR6280 *TKR6503C (Option) TKR5125 Wheels/Tires (not included) BATTERY INSTALLATION Note: Use either TKR1213 Associated o set staduim truck OR Traxxas Slash SC o set wheels/tires. TKR1213 HOOK AND LOOP NOTE: TKR7201 Please note that there is a slight handling di erence between using body clips and using the hook and loop...
  • Page 25 Setup Information The purpose of making adjustments is to make the car go faster around the track, or to make it more controllable, or both if possible. A car that's easier to drive should produce lower, more consistent lap times. It will also inspire more confidence in the driver, which is always good when nerves start getting the best of you.

  • Page 26: Sway Bars

    When setting your mesh you want have it set as (2 cell) 7.5T 17 tooth 18 tooth tight as possible, without any binding. Tekno RC is not 8.5T 18 tooth 19 tooth responsible for damage done to your electronic equip-...
  • Page 27 Please read thoroughly The Tekno RC ET410 is highly tunable, but can be very aggressive depending on track conditions and tires used. To help with this, we recommend that you are well informed about setting up your Steering End Points (EPA), Dual Rate (D/R), Exponential Curves, and Servo Speed.
  • Page 28 Maintenance: Performing regular maintenance will greatly improve your on track consistency and also extend the life of your vehicle. Going through critical areas of the vehicle regularly will also allow you to find possible issues before they become a problem that may cost you a race. Follow the guidelines below for maximum performance. Bearing Maintenance: Bearings should always be smooth and free in order to preform their function.
  • Page 29 TKR6605X - Wing (lightweight, lexan, pre-cut, EB410) Di erential List TKR6611 - Sway Bar Set (rear, bars only, 1.0, 1.1, 1.2, 1.3, 1.4mm, EB410/ET410) TKR5144 - Di erential O-Rings (6pcs) TKR6623 - Sway Bar Kit (complete front, 1.0, 1.1, 1.2, 1.3, 1.4mm, EB410) TKR6511 - Di erential Case (f/c/r, 3pcs, EB410) TKR6635C - Center Di Top Plate and Fan Mount (carbon fiber, EB410)
  • Page 30 Box Setup (starting point) 27mm 27mm -2° -2° Stock Stock 15° 0° Yellow Yellow 11° 2° Emul Emul 0.5° out 1.5° in (per side) (per side) 1.5mm STOCK STOCK...
  • Page 32 Tekno RC 10755 Scripps Poway Pkwy #598 San Diego CA 92131...
