- Page 1 PM2.5 HEPA AIR PURIFIER WITH AIR QUALITY SENSOR Thank you for choosing electriQ Please read this user manual before using this innovative Air Purifier and keep it safe for future reference. Visit our page www.electriQ.co.uk for our entire range of Intelligent Electricals...
-
Page 2: Table Of Contents
CONTENTS SAFETY ENERGY SAVING INDOOR POLLUTANT INFORMATION PRODUCT OVERVIEW OPERATING INSTRUCTIONS ADDITIONAL FUNCTIONS FILTER REPLACEMENT CARE AND MAINTENANCE TECHNICAL SPECIFICATION TROUBLESHOOTING SUPPORT... -
Page 3: Safety
SAFETY INSTRUCTIONS • Carefully read the instructions before operating the unit. • This appliance is for indoor use only. • This unit must only be connected to a 220-240V / 50Hz earthed outlet. • Installation must be in accordance with regulations of the country where the unit is used. - Page 4 • A damaged power supply should be replaced by the manufacturer. Never extend or attempt to change the power supply lead. • Any service other than regular cleaning or filter replacement should be performed by an authorised service representative. Failure to comply could result in a voided warranty.
-
Page 5: Energy Saving
ENERGY SAVING AND UNIT SAFETY PROTECTION TIPS • Do not cover or restrict the airflow from the outlet or inlet grills. • For maximum performance and safety, the minimum distance from a wall or objects should be 30cm. Keep away from other electrical appliances. -
Page 6: Product Overview
PRODUCT OVERVIEW Control panel/ Display Air outlet Carry handle Sensor Front panel ON/OFF Air inlet (Back Auto Mode Speed panel) Timer Function Sleep NOTE: The centre button on the remote control is reserved for other functions not in use for this model. -
Page 7: Operating Instructions
OPERATING INSTRUCTIONS SLEEP TIMER FAN SPEED ON/OFF These functions are accessible by using the remote control or the units control panel. SLEEP: Press the SLEEP button to enter sleep mode. During sleep mode the display will be inactive and the fan will run at speed number 1. TIMER: The timer can be set to either turn the appliance on or off. -
Page 8: Additional Functions
ADDITIONAL FUNCTIONS IONISER Ions are designed to turn on while the unit is in operation. The ioniser sterilises the air further and removes mould spores and allergens from the air. (Can be activated or deactivated by using the FUNCTIONS button on the remote control). -
Page 9: Filter Replacement
FILTER REPLACEMENT When the filter indicator light turns red, the filter needs to be replaced. Turn off the unit then unplug the unit from the mains. Open the filter cover by gently pulling the back-air inlet panel away from the unit as shown. -
Page 10: Care And Maintenance
CARE AND MAINTENANCE • Always shut off the unit and unplug from the mains before cleaning or performing any maintenance. • When the unit is not in use for long periods, it is advisable to remove the plug from the power socket. •... -
Page 11: Technical Specification
TECHNICAL SPECIFICATION MODEL EAP260HC-PM 2.5 DIMENSION 510×330×170mm GENERAL WEIGHT 6.0kg RATED POWER RATED VOLTAGE 220V~/50Hz ≤61dB(A) NOISE LEVEL TROUBLESHOOTING ISSUE CHECK Check that the power adapter is connected and is the correct rating. Not working Ensure the front panel is correctly fitted and that the peg on the rear of the panel is undamaged. -
Page 12: Support
UK SUPPORT www.electriQ.co.uk/support Please, for your own convenience, check the troubleshooting guide before calling the service line. If the unit still fails to operate call: 0871 620 1057 or complete the online form Office hours: 9AM - 5PM Monday to Friday www.electriQ.co.uk...
