RG-EG2100-P V2 Hardware Installation and Reference Guide
Featured with global-leading semiconductor technologies and communication control technologies, Ruijie EG series
breakout gateway is a data communication product developed by Ruijie Networks with independent intellectual property
right. The EG series breakout gateway is designed according to international standards, similar to the mainstream breakout
gateway products in the international market. By reading this manual, a network administrator familiar with mainstream
breakout gateway configuration commands can use this device without training.
RG-EG2100-P V2

Specifications

Model
Storage
I/O Setup
BYPASS
Power Module
PoE Consumption
Hardware
Expansion Module
Expansion Module
Hot-swapping
Interface Standard
Dimension (without
rubber pads)
(W x H x D)
Voltage
Power Consumption
Working
Temperature

Product Overview

RG-EG2100-P V2
DDR3 SDRAM: 512MB
eMMC: 4GB
BOOTROM: 2MB
WAN port:
One 10/100/1000M self-adaptive fast Ethernet copper port, automatic recognition of network
cables and cross-over cables.
LAN1 supports WAN/LAN switchover.
LAN port:
Seven 10/100/1000M self-adaptive fast Ethernet copper ports, automatic recognition of
network cables and cross-over cables.
LAN1 supports WAN/LAN switchover.
No management port
One Console port
One USB2.0 port
Not supported
Built-in 150W power module
≤
135W
Not supported
Not supported
Not supported
Ethernet: 10Base-T/100Base-TX/1000Base-TX
Console port: RS-232
200 mm × 43.6 mm × 200 mm (7.87 in. x 1.72 in. x 7.87 in.)
100V to 240V~, 50Hz to 60Hz, 1.5A max
<
150W (With PoE)
0° C to 45° C (32° F to 113° F)
Product Overview
