Communications system queued call console (130 pages)
Summary of Contents for AT&T MLS-34D
Page 1
Personal Speed Dial Numbers To dial a Personal Speed Dial number: Press [ ] followed by the 2-digit Dial Code. Feature See panel 4 for programming instructions. Your premises equipment may also be programmed with System Speed Dial numbers (Dial Codes 20-79), which are similar to Personal Speed Dial Numbers except anyone on the system can dial them.
Making a Conference Call To add parties to a call (max. 4 parties plus you): 1. Call the first party (can use Speed Dial or Auto Dial buttons). 2. Press [ ] in the place of a switchhook flash in your Centrex Conf Conf instructions and then follow your Centrex instructions for conferencing.
Page 3
Press either button to place an intercom call to another extension using the extension jack number. (Intercom calls do not tie up primary lines.) Normally you just use MLS-34D, MLS-12D, MLS-12, and MLS-6 are trademarks of AT&T. the Centrex extension number to dial an inside call.
Page 4
Programming To Program Buttons Store dialings sequences or features on programmable buttons (see diagram, panels 2–3). Then simply press the button to dial or access the feature automatically. Press [ ] to enter program mode. Feature Press a programmable button. Press the buttons you normally press to dial an extension, outside number, or †...
Equipment Features You cant use an equipment feature in either of two ways: Dial it manually (except for Do Not Disturb and Privacy, which require programming on buttons with lights). Press a button programmed with the feature (see “Programming” on panel 4). To Use On a To Dial Equipment Feature...
Page 6
Equipment Feature Using Intercom To Dial To Use On Equipment Feature a Button Manually Message Light On Dial [ Press the button + Feature Turns on the message light on an MLS- or + Ext. Jack Number MLC- model phone. Ext.
Answering a Call Ringing at Another Extension For an extension in a Pickup Group:* At any extension in the Pickup Group: 1. Press [ Intercom Intercom 2. Lift handset. Group Number 3. Dial [ 4. Dial the group number of the Pickup Group for the extension. On a line not assigned to When a line is not assigned to your extension: your extension:...
Page 8
Lights Red (top) light shows activity at another extenstion. Green (buttom) light shows activity at your extension. Steady on: Line is busy. Off (off continuously): Line is idle, available for use. Flash (long on, long off): Call is ringing on the line. Alternating Red/Green Flash: (red on, green on, red on, green on): Appears at all extensions in a joined call.
Making a Call Outside: To call an outside party on a line assigned to your phone: Phone Number 1. Lift the handset to dial out on your primary line. 2. Dial telephone number. Inside: To call an inside party (another extension): Centrex Extension 1.
