2. Insert wooden dowels (D) into the holes on the pedestal (C).Place the table top (A) to the

pedestal (C), place spring washers (G), followed by flat washers (F) onto the hexagonal bolts

(E), then insert the hexagonal bolts (E,F&G) through the holes of the bridge(A) into the insert

nut in the pedestal (C). Tighten with wrench (H) as shown in fig 4, picture 2.

Figure 3

STEP 3 :

3a. If extension leaf is going to be used, please ensure to unlock the leaf-lock before opening the

table top. Grip both table ends and pull to open.

3b.Insert extension leaf (B) into position, make sure the leaf pins match with the corresponding

holes.

3c.Slide/close both ends simultaneously until leaves are securely in place. Lock the leaf-lock.

Figure 5

F R O N T G A T E

BORDEAUX DINING TABLE

Figure 4

Picture.2

Picture.3
