CINMAR ITEM NUMBER: 167126A MIN & 167126B MIN & 167126A NAL & 167126B NAL
PRODUCT DIMENSION: 132"W X 42"D X 30.5"H
CINMAR ITEM DESCRIPTION: Alden Rectangular Expandable Dining Table Top & Base
NO
A
B
C
D
E
F
G
H
I
J
K
Note: When unpacking, lay the parts on a padded clean surface. Be sure to locate all
hardware before throwing away any packaging.
PARTS INCLUDED
ITEM
"PRODUCTS ARE NOT INTENDEND FOR COMMERCIAL USE"
DESCRIPTION
Top
Base
Extension Leaf
Connecting Bar
Curved Washer
Nut
Wood Peg
Wrench
Bolt
Flat Washer
Alley Key
QTY.
1 pc
2 pcs
2 pcs
1 pc
2 pcs
2 pcs
4 pcs
1 pc
4 pcs
4 pcs
1 pc
Page 1 / 3
Advertisement
Table of Contents
Related Manuals for Frontgate Alden 167126A MIN
Summary of Contents for Frontgate Alden 167126A MIN
- Page 1 CINMAR ITEM NUMBER: 167126A MIN & 167126B MIN & 167126A NAL & 167126B NAL PRODUCT DIMENSION: 132"W X 42"D X 30.5"H CINMAR ITEM DESCRIPTION: Alden Rectangular Expandable Dining Table Top & Base PARTS INCLUDED ITEM DESCRIPTION QTY. 1 pc Base 2 pcs Extension Leaf 2 pcs...
- Page 2 ASSEMBLY INSTRUCTIONS Step 1. Insert Wood Pegs [G] into the holes on the bases [B]. Step 2. Attach the connecting bar [D] to the bases. Place the Curved Washer [E] and Nut [F] through the holes, and tighten with Wrench [H]. Step 3.
- Page 3 Keep away the table from high temperature. Avoid direct sunshine, this table is only used indoor. Frontgate: Please contact one of our Product Specialists for assembly assistance or questions at 1-800-537-8484 or email ps@frontgate.com. Specialists are available weekdays 8:00am to 8:00pm EST or Saturday 9:30am to 6:00pm.
