2.8 Connector Pinouts

Table 4 shows an overview of all connectors assembled on the Mars PM3 Board. A more detailed
description of each connector can be found further below in this section.
Connector Description
J200 Mars Module Connector
J400 USB 2.0 Micro-B Connector
J500 USB 3.0 B Connector
J501 USB 2.0 A Connector
J700 RJ45 Ethernet Port (1G or 2x 100M)
J800 FPGA JTAG Connector
J801 FX3 Connector
J802 SD-Card holder (on bottom side)
J1000 HDMI / PCIe Port
J1100 FMC LPC Connector
J1101 Extension Connector (not assembled)
J1300 External Power Jack (12V DC,
2.1x5.5mm)
J1301 Internal Power Connector
J1302 Fan Connector
J1303 Battery Holder (on bottom side)
2.8.1 J200 – Mars Module Connector
2 Function Signal
nd
VCC_5V
VCC_5V
VCC_5V
VCC_5V
23/04/2019

Table 4: Connector overview

Connector Pin
1 2
3 4
5 6
7 8
13 / 43
Connected to
Mars FPGA module
USB 2.0 UART Device (U401)
Cypress FX3 USB 3.0 controller (U301)
and Mars Module Connector
Mars Module Connector
Mars Module Connector
Mars Module Connector
Cypress FX3 USB 3.0 Controller (U301)
and System Monitor
Mars Module Connector (shared with
FX3 FIFO interface)
Mars Module Connector
Mars Module Connector
Mars Module Connector
Power Supplies
Power supplies
System Monitor
Mars Module Connector (RTC)
Signal
GND
FMC_CLK1_M2C_P
FMC_CLK1_M2C_N
GND
2 Function
nd
