- Page 1 Router Table ProFence Instructions Effective September 2019 Review full instructions prior to use for important safety information. Always check Rockler.com to confirm that you are using the most recent version of instructions for your product.
- Page 2 Instructions and safety warnings for your product (see the • Keep children and bystanders away from the tool Instructions link on the product page at Rockler.com). operating area; • Do NOT use power tools in explosive environments, or in >...
- Page 3 PRODUCT SPECIFIC SAFETY WARNINGS > To avoid serious injury, keep hands and fingers away from the spinning router bit. Maintain awareness of the bit at all times. AVOID THIS SITUATION! Fence > NEVER FEED YOUR WORKPIECE BETWEEN THE BIT AND THE FENCE. Because of the direction of the Workpiece bit’s rotation, the bit could “grab”...
- Page 4 PARTS LIST Quantity Quantity Aluminum Fence Knob Spacer 3/8-16 x 2 ⁄ " Hex Bolt Adjustable MDF Fence Faces 10 3/8-16 x 2 ⁄ " Carriage Bolt Use with Bit Safety Guard ProPhenolic Router Table) Dust Port 11 3/8" Nylon Washer 3/8"-16 T-Knobs 12 Joint Bars 5/16"-18 x 1...
- Page 5 Router bit guide bushing Outfeed subfence Infeed subfence Feed Direction Router Bit Infeed subfence adjusted to zero clearance 5. Fit the bottom of the 3/8"-16 x 2 ⁄ " Hex Bolts (9) or In some cases, you might want “zero-clearance” support to deliver 3/8"-16 x 2 ⁄...
- Page 6 Use in slots 1 and 3 for 1/16" cuts Use in slots 2 and 4 for 1/32" cuts Jointing Bar Attachment Using the Jointing Bars THESE WARNINGS PERTAIN TO ALL REMAINING STEPS: > To avoid serious injury, keep hands and fingers away from the spinning router bit. Maintain awareness of the bit at all times.
- Page 7 Adjustable Fence Face (2) in matching slots -- either the second and fourth slots (to remove 1/32" of material) or Check Rockler.com for updates. If you have further questions, please the first and third slots (to remove 1/16" of material).
- Page 8 47905 Distributed by Rockler Companies, Inc. 1-800-279-4441 Rev 09/19 4365 Willow Dr. Medina, MN 55340 www.rockler.com...
