  • Page 1 MV-801 INTEGRATED MULTIVIEWER User Manual RMY3 MV-801-UM Issue 1 Revision 1 2020-10-21...

  • Page 2: Fcc Compliance

    USA, LLC, or one of its affiliates or subsidiaries. All other intellectual property rights are owned by GVBB Holdings SARL, Grass Valley USA, LLC, or one of its affiliates or subsidiaries. All third party intellectual property rights (including logos or icons) remain the property of their respective owners.

  • Page 3: Read Me First

    This MV-801 user manual describes how to install, configure and operate the MV-801 multiviewer in the Sirius 830, 840 and 850 routers. Refer to the MV-8 Series Core Multiviewer User Manual for information about the MV-801’s core multiviewer features, control screens, ‘getting going’ instructions, and maintenance.
  • Page 4 The presence of this symbol in or on Grass Valley equipment means that it has been tested and certified as complying with applicable Underwriters Laboratory (UL) regulations and recommendations for USA.
  • Page 5 MV-801 User Manual The presence of this symbol in or on Grass Valley product means that it complies with all applicable European Union (CE) directives. The presence of this symbol in or on Grass Valley product means that it complies with safety of laser product applicable standards.

  • Page 6: Battery Handling

    Replace the battery only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer’s instructions. Before disposing of your Grass Valley equipment, please review the Disposal and Recycling Information at: http://www.grassvalley.com/assets/media/5692/Take-Back_Instructions.pdf...
  • Page 7 MV-801 User Manual Mesures de sécurité et avis importants La présente section fournit des consignes de sécurité importantes pour les opérateurs et le personnel de service. Des avertissements ou mises en garde spécifiques figurent dans le manuel, dans les sections où ils s’appliquent. Prenez le temps de bien lire les consignes et assurez-vous de les respecter, en particulier celles qui sont destinées à...
  • Page 8 électrique, de compatibilité électromagnétique et de conformité environnementale. Le symbole ci-contre sur un appareil Grass Valley ou à l’intérieur de l’appareil indique qu’il est conforme aux normes applicables en matière de sécurité laser. Avertissements Les avertissements signalent des conditions ou des pratiques susceptibles d’occasionner des blessures graves, voire fatales.
  • Page 9 MV-801 User Manual • Les produits qui n'ont pas d’interrupteur marche-arrêt et qui disposent d’une source d’alimentation externe doivent être installés à proximité d'une prise de courant facile d’accès. • Si l’équipement n’est pas pourvu d’un modules d’alimentation auto-adaptables, vérifiez la configuration de chacun des modules d'alimentation avant de les mettre sous tension.
  • Page 10 Grass Valley believes this environmental information to be correct but cannot guarantee its completeness or accuracy since it is based on data received from sources outside our company. All specifications are subject to change without notice.

  • Page 11: Further Safety Information

    Lithium Batteries Battery Warning Your Grass Valley equipment usually comes with at least one button battery located on the main printed circuit board. The batteries are used for backup and should not need to be replaced during the lifetime of the equipment.
  • Page 12 Notices 3 Gently remove the battery from its holder using a blunt instrument for leverage such as a screwdriver if necessary. In some cases the battery will need to be desoldered from the PCB. 4 Dispose of the battery and equipment according to your local environmental laws and guidelines.
  • Page 13 Sirius Router Power Requirements Before adding an MV-801 to a Sirius 800 router frame, check that the power supplies fitted to the router frame can supply sufficient power to the router and MV-801. See the Sirius 800 User Manual for router power requirements and contact Grass Valley Support for advice.

  • Page 14: Safety And Emc Standards

    Notices Safety and EMC Standards This equipment complies with the following standards: Safety Standards Information Technology Equipment - Safety Part 1 EN60950-1: 2006 Safety of Information Technology Equipment Including Electrical Business Equipment. UL1419 (4 Edition) Standard for Safety – Professional Video and Audio equipment (UL file number E193966) EMC Standards This unit conforms to the following standards: EN55032:2015 (Class A)
  • Page 15 EMC Performance of Cables and Connectors Grass Valley products are designed to meet or exceed the requirements of the appropriate European EMC standards. In order to achieve this performance in real installations it is essential to use cables and connectors with good EMC characteristics.
  • Page 16 Notices...

  • Page 17: Document History

    MV-801 User Manual Document History Publication Document Document Notes Date Part Number Issue and Revision 2020-10-21 RMY3 MV-801-UM Issue 1 Revision 1 First issue of the user manual. xvii...
  • Page 18 Notices xviii...

  • Page 19: Table Of Contents

    1.11 MV-801 Integrated Multiviewer H.264 Streaming Out ......10 2 MV-801 Hardware Modules ....... . . 11 2.1 MV-801 Multiviewer Front Module (FGAMV MV-801).
  • Page 20 4.2.2 Sirius Router Module Addresses ..........41 Appendix A MV-801 Specification ......45 A.1 Physical/Electrical .

  • Page 21: Product Overview

    The MV-801 is available from Grass Valley as an option on a new Sirius 800 router from the factory, or as an option to be installed in the field. A single MV-801 can drive up to 12 head display monitors.

  • Page 22: Mv-801 Integrated Multiviewer Benefits

    Documents, on page iii.) 1.2 Typical User Applications The MV-801 Integrated Multiviewer is ideal for any user application that requires single or multiple displays. For example: Play out control rooms, multi-channel play out, studio galleries, OB trucks, post-production suites, and signal lines monitoring areas.
  • Page 23 Low-bandwidth video and audio signatures streamed. Applications include: Lip sync, Channel mapping detection, Confidence Monitoring. Identification and comparison. • HDR support. Up to 12 head display outputs per MV-801, connections to monitor display screens: • 3G 1080p, HD 720p. • High image quality: De-interlacing, scaling.

  • Page 24: Integration Into Sirius 800 Routers

    MV-801 Hardware Installation chapter, for slot information.) The Sirius 800 internal router architecture allows the MV-801 to tap into the signal flow within the router at the input signals, just before the main router crosspoint. Figure 2 shows a Sirius 800 router block diagram which includes up to three MV-801 Integrated Multiviewer units.

  • Page 25: Mv-801 Main Input And Output Connections

    MV-801 User Manual 1.5 MV-801 Main Input and Output Connections Figure 3 shows the MV-801 Integrated Multiviewer with its core MV-8 Series Core Multiviewer and its main inputs and outputs, comprising: • 48 video inputs (internal to the router): Selected from all router inputs via the MV Crosspoint module.

  • Page 26: Mv-801 Components

    Sirius 800 router frame. The multiviewer may be purchased already fitted into a new Sirius 800 router from Grass Valley or bought separately as a hardware upgrade option, to be fitted to an existing Sirius 800 router. One or more MV-801’s may be fitted to a router.
  • Page 27 MV-801 User Manual Table 2 List of Front Modules and Rear Panels etc required for an MV-801 router installation Sirius Router Part Comment FGAMV MV-801  (MV-801 Main Module) 1 or 2-off 1, 2 or 3-off 1 or 2-off FGAMV MV-801 and FGAEY 1312 are ordered together in complementary pairs (i.e.

  • Page 28: Order Codes

    MV-801 Integrated Multiviewer main module, includes license for 4 display outputs. (Display outputs 1 to 4.) Grass Valley module number FGAMV MV-801. FGAMV MV-800-RP Multiviewer Rear Panel used for MV-801, with SFP cages for accepting SFP video output modules. (Grass Valley module number 1312.) Note: This rear panel item is used on MV-801 and on MV-800.

  • Page 29: Multiviewer Terminology

    Specification, Table 14 on page 49, for default IP addresses on all network ports. Initial configuration and set up of the MV-801 multiviewer is done via Grass Valley’s RollCall Control Panel application. See the ‘MV-8 Series Core Multiviewer’ user manual, in the section about RollCall templates and “Getting Started”.

  • Page 30: Configuration Screens (Rollcall Templates)

    An MV-801 has a license option which enables streaming out of H.264-encoded copies of the input video signals going to the multiviewer block on the MV-801. Streaming is done over Ethernet interfaces 1 or 2. The license option can be added later to MV-801 modules in the field.

  • Page 31: Mv-801 Hardware Modules

    2 MV-801 Hardware Modules MV-801 hardware primarily comprises: • Main front horizontal module (FGAMV MV-801). (MV-801 Multiviewer Front Module (FGAMV MV-801), on page 12.) • Rear panel horizontal module (1312). (MV-800-RP Multiviewer Rear Panel (1312) (Used MV-800/MV-801), on page 15.) These modules are described in this section.

  • Page 32: Mv-801 Multiviewer Front Module (Fgamv Mv-801)

    It is a single-height module, occupying one horizontal slot in the router frame. The top-side of the module is mostly covered with gray metal heat plates. More than one MV-801 may be fitted to a router, see Table 1 on page 2. Module’s motherboard mating connectors Module ...

  • Page 33: Front Module Status Led Indicators

    MV-801 User Manual 2.1.1 Front Module Status LED Indicators Table 4 shows the LED color codes for the MV-801 module, and Figure 5 shows the front edge of the module. LEDs on main board, under module Connectors for Engineering Use Only...

  • Page 34: Dip Switches

    MV-801 User Manual 2.1.2 DIP switches The four DIP switches are not used. Check that all four switches are in the “up” position. 2.1.3 Engineering connectors There are two other connectors on the front edge of the module, see Figure 5. These are for Engineering use only and should not be used.

  • Page 35: Mv-800-Rp Multiviewer Rear Panel (1312) (Used On Mv-800/Mv-801)

    1 output per HDMI SFP video module. The Multiviewer display outputs come from SFP modules fitted into the SFP cages on the MV-801 Rear Panel module’s rear plate. SFP blanking plugs must be fitted if an SFP is not fitted into any of the cages.

  • Page 36: Connectors

    MV-801 User Manual 2.2.1 Connectors Table 5 describes each connector type. Table 5 MV-801 Integrated Multiviewer 1312 Rear panel Connectors Connector Description Display Outputs 1 to 12 Multiviewer video wall display outputs. [See note 1] 6-off SFP cages for SFP modules •...

  • Page 37: Rear Panel Leds

    Multiviewer Head Display Outputs Status LEDs (Table 6) Ethernet Link Status LEDs (Table 7) Figure 7 MV-801 Rear Panel LEDs: a) Multiviewer Head Display Outputs; b) Ethernet Ports 2.2.2.1 Multiviewer Head Display Outputs One status LED per output. Table 6 describes the LED function.

  • Page 38: 2Ethernet Outputs

    MV-801 User Manual 2.2.2.2 Ethernet Outputs Two status LEDs per port. Table 7 describes the LED function. Table 7 Ethernet Port Status LEDs Color LEDs Status Green / Off Ethernet link established Green Solid / Flashing Activity on Ethernet link Off / Off Establishing link, or unconnected.

  • Page 39: Ltc And Gpio Connector Pin-Outs

    GPI 2 GPI 3 GPI 4 LTC- Note: ‘nc’ denotes a “not connected” connector pin. Note: MV-801 GPI outputs - Open collector outputs. Require external pull-up Ω Ω. Each output can sink resistors of value between 10 k and 100 k up to 100 mA.

  • Page 40: Example: Driving Leds From The Gpi Outputs

    MV-801 User Manual 2.2.4 Example: Driving LEDs from the GPI Outputs MV-801 GPI outputs have open collector drivers. There is a +5 V DC pin on the GPIO connector to provide the power needed to drive LEDs or relays. The following schematic is an example of the circuit needed to drive an LED by each GPI output.

  • Page 41: Mv-801 Hardware Installation

    MV-801 hardware must be identified. Slot identification is part of the MV-801 hardware installation instructions contained in this section. An MV-801 Quick Setup Guide is shipped with the module and is also available as a download from Grass Valley.

  • Page 42: Initial Checks And Actions

    One or more MV-801 modules may be fitted into a Sirius 800 router. 3.2.2 Router Frame Check The MV-801 modules must only be fitted into a Mark 3 type Sirius 800 router frame.  This router frame type has a blue fan rack (see Sirius 800 User Manual, section 3.12.1, Table 5).
  • Page 43 Note the orientation of the SFPs in this figure. Figure 12 SFP orientation for fitting into 1312 Rear Panel SFP cages Insert the SFP video modules into the SFP cages on the MV-800/MV-801 Rear Panel (1312).  The modules slide in until there is an audible click.

  • Page 44: Identifying Modules And Slots In The Sirius Router

    MV-801 hardware installation, and to avoid the risk of disruption to the router and its operation. To help locate the relevant slots for the MV-801 option, please refer to the Sirius 800 User Manual (“Module Location” section) and also to the figures in this section.
  • Page 45 MV-801 option Sirius 850 Sirius 840 Sirius 830  Figure 14 Sirius 800 sections of the router frame for MV-801 option installation, a) front Multiviewer Fan Doors and b) Rear Panel Section Issue 1 Revision 1 Page 25...
  • Page 46 MV-801 User Manual Step 2. Locate and identify the relevant router frame slots relating to the MV-801 Integrated Multiviewer option. These are all horizontal slots. Refer to Figure 15, Figure 16 or Figure 17 for Sirius 830, 840 and 850 respectively for slot locations in a router frame.
  • Page 47 Or Blanking Panel FGAMV MV-801 Main Module (2) 1312 Rear Panel 5902 Multiviewer Crosspoint Module * Possible second MV-801. Otherwise, fit Blanking Rear Panel. Figure 15 Sirius 830 - Relevant Module Positions for MV-801 modules Issue 1 Revision 1 Page 27...
  • Page 48 1312 Rear Panel 5902 Multiviewer Crosspoint Module Possible second MV-801, otherwise fit a Blanking Rear Panel. Possible third MV-801, otherwise fit Blanking Rear Panel. (Note: only 44 inputs.) Figure 16 Sirius 840 - Relevant Module Positions for MV-801 modules Issue 1 Revision 1...
  • Page 49 Or Blanking panel FGAMV MV-801 Main Module (2) 1312 Rear Panel 5902 Multiviewer Crosspoint Module Possible second MV-801, or fit a Blanking Rear Panel. Figure 17 Sirius 850 - Relevant Module Positions for MV-801 modules Issue 1 Revision 1 Page 29...
  • Page 50 Table 10, in the columns headed “Before fitting MV-801” column. Step 4. The types of modules that are required for your MV-801 installation are listed in the right-hand side columns of the record sheet in Table 10, in the columns headed “After fitting MV-801”...
  • Page 51 MV-801 User Manual  Table 10 Record Sheet: Modules and Rear Panels, Before and After MV-801 Installation:  a) Sirius 830 router frame,  b) Sirius 840 router frame,  c) Sirius 850 router frame. Where (1), (2), etc. refer to slot labels in Figure 15, Figure 16 and Figure 17.

  • Page 52: Removal And Then Fitting Of Modules

    This avoids any interim incompatibility between front and rear modules during fitting, which may damage the modules and the router. Note: Fit the 1312 MV-800/MV-801 Rear Panel(s) before fitting the front MV-801 main module(s). Note: The fan door assemblies should be returned to the closed position as soon as possible after opening.

  • Page 53: Module Removal Procedure

    MV-801 User Manual Relevant router frame slots for MV-801 installation are Slot (1) through to Slot (4) in Figure 15, Figure 16 and Figure 17. Front modules plug into the router’s internal motherboard and connect to their respective rear modules. This front-and-rear slot arrangement and the slot labeling is restated in the diagram in Figure 18, which is a side view of the card arrangement.

  • Page 54: Fitting Preliminaries

    MV-801 User Manual Now move to the front of the router. Unlock and open the router front door and open the relevant internal fan door (refer to Figure 14). Front module removal: Remove all front modules from front slots that need to be emptied.
  • Page 55 MV-801 User Manual Note: When inserting a rear module into a rear slot: • Check the module is the correct one for the slot. • Check there are no obstructions at the module connectors. • Check for any high components on the top- or under-side of the module.

  • Page 56: Module Fitting Procedure

    Go to the rear of the router frame. The procedure continues with the fitting of rear modules: Rear Slot (2): Insert a1312 MV-800/MV-801 Rear Panel module into rear Slot (2). Check the orientation of the rear module, see Figure 20.
  • Page 57 Front Slot (3): Fit a second FGAMV MV-801 Main Module to front Slot (3) or leave empty. Front Slot (4): Fit a third FGAMV MV-801 Main Module (Sirius 840 only) to front Slot (4) or leave empty. 10. Close and secure the front fan door assembly, making sure not to trap any wires.

  • Page 58: Connecting Cables

    IT network.  See the ‘MV-8 Series Multiviewer’ user manual for more information. Connect the MV-801 directly to a computer network port via 1G Ethernet port 1  (see Figure 23) using a standard CAT 5e Ethernet cable.

  • Page 59: Sirius 800 Router Configuration

    Specifying Module Configuration - Specifying what modules are fitted in which router module slots. Using Grass Valley Workbench, Pull the router’s configuration from the router, modify it and Push it back to the router. Contact Grass Valley support for help and advice.

  • Page 60: Matrix Output Ports

    Note 2: Different slot numbering used for Router Destinations of a Sirius 850 frame. Note: There are normally 48 inputs for a MV-801 module from the host Sirius 800 router frame.  However, for a third, ‘upper-slot’ MV-801 module (i.e. top slot in router frame), only 44 inputs are available to the MV-801.

  • Page 61: Module Configuration

    There is a difference in the module address number sequence for the Sirius 850 router frame. Corresponding router frame slot locations are found in the Grass Valley ‘Workbench User Manual’ (see Appendix C, Sirius 800 Routers) and are shown in figures below: •...
  • Page 62 MV-801 User Manual Rear of Router Frame Front of Router Frame Figure 24 Sirius 830 Modules Figure 25 Sirius 830 Module Addresses Issue 1 Revision 1 Page 42...
  • Page 63 MV-801 User Manual Rear of Router Frame Front of Router Frame Figure 26 Sirius 840 Modules Front of Router Frame Figure 27 Sirius 840 Module Addresses Issue 1 Revision 1 Page 43...
  • Page 64 MV-801 User Manual Rear of Router Frame Front of Router Frame Figure 28 Sirius 850 Modules Figure 29 Sirius 850 Module Addresses Issue 1 Revision 1 Page 44...

  • Page 65: Appendix A Mv-801 Specification

    Weight: Front Module 3.5 kg Rear Panel 0.75 kg Note 1: The MV-801 operating temperature range is lower than that of a Sirius 800 host router. Refer to the Sirius 800 User Manual for the router frame operating temperature range.

  • Page 66: Head Display Outputs

    A.3 Head Display Outputs Signal Multiviewer Head Display From 4-off up to 12-off outputs: Outputs • Outputs 1 to 4 on standard MV-801. • Outputs 5 to 12 requires licenses. (Licensed in pairs.) SDI HD-BNC or fiber via SFP. Video standards Video standard: •...

  • Page 67: Input Video Standards

    MV-801 User Manual A.4 Input Video Standards Input Video Standard 3G-SDI: 1080p 59.94Hz SMPTE 424M/Level A 2.97Gbps  1080p 60Hz SMPTE 424M/Level A 1080p 50Hz SMPTE 424M/Level A HD-SDI: 1080i 60Hz (ANSI/SMPTE-274M(4) 292M(D)) 1.485 Gbps 1080i 59.94Hz (ANSI/SMPTE-274M(5) 292M(E)) 1080i...

  • Page 68: Streamed 'Input-Copy' Outputs

    Applications include: confidence monitoring, compliance monitoring. A.6 Rear Panel Connectors The MV-800-RP Rear Panel is used on MV-801 and the module number is 1312. See Figure 6 on page 15 for an illustration of the Rear Panel connectors. Connectors Multiviewer Display 6-off SFP cages.

  • Page 69: Monitoring And Alarms

    10.54.31.234 Note 1: Up to three MV-801’s may be fitted to a Sirius 800 router. MV-801 default IP addresses ship with default IP addresses of either a), b) or c). Note 2: ‡ 10G interfaces are not used. A.7 Monitoring and Alarms For specification of the multiviewer engine and all video wall capabilities, please refer to the ‘MV-8 Series Multiviewer’...
  • Page 70 MV-801 User Manual User Notes: Issue 1 Revision 1 Page 50...

  • Page 71: Contact Us

    MV-801 User Manual Contact Us Grass Valley Technical Support For details of our Regional Customer Support Offices please visit the Grass Valley web site and navigate to Support/Customer Support Contacts. https://www.grassvalley.com/contact/support/ Customers with a support contract should call their personalized number, which can be found in their contract, and be ready to provide their contract number and details.
