BATHTUB INSTALLATION

1. Prepare the site where the bath will be installed by waterproofing the floor and determining the
location of the drain pipe. Please refer to pictures 1, 2, 3 for recommended methods of installation
for this bathtub model.
2. Take (1) adjustable foot [#5] and (1) nut [#3] and screw the nut halfway on foot.
3. Screw the adjustable foot with the nut into the leveling foot.
4. Take (1) retaining screw [#1] and put it through the hole at the top of the foot. Then take (1) washer
[#2] and place it on the screw and secure with (1) nut [#3].
5. Take the assembled leveling foot (#4) and place it into the opening on the bathtub [see diagram].
Once inserted, secure and tighten all the bolts to ensure stability. A wrench may be required.
Repeat steps 2-5 for the other 3 leveling feet.
