Installation Guide
Mono basin & bidet mixer with pop-up waste
This instruction booklet covers model:
MET-100
MET-100 & MET-110.
MET-110
Vado
Wedmore Road, Cheddar, Somerset, England BS27 3EB
tel 01934 744466.
fax 01934 744345
aftersales@vado.com
www.vado.com
Keep for future reference
Version 1, 1-12-17
Advertisement
Table of Contents
Related Manuals for VADO Metiz MET-100
Summary of Contents for VADO Metiz MET-100
- Page 1 Installation Guide Mono basin & bidet mixer with pop-up waste This instruction booklet covers model: MET-100 MET-100 & MET-110. MET-110 Vado Wedmore Road, Cheddar, Somerset, England BS27 3EB tel 01934 744466. fax 01934 744345 aftersales@vado.com www.vado.com Keep for future reference...
- Page 2 Guarantee Please read these instructions carefully before starting installation and keep for All VADO V products come with a 2 year guarantee as standard. Within this guarantee future reference. period VADO will provide replacement parts needed to complete the product repair.
- Page 3 Installation - Pop-up waste Operation: Dissemble the pop-up waste and reassemble onto the basin. (see Fig 1) Insert the vertical control rod down through the hole in the back of the mixer body. Slide the bearing (lip nearest the ball) over the short end of the horizontal control rod, push into the waste and clamp in position by screwing on the ball joint retainer.
- Page 4 Installation - Quick guide Installation MET-110 Control Before installing your new mixer, flush MET-110 handle through the pipework to ensure removal of debris, turn off the water supply. Place the seal in the slot on the underside of the base. Max - 5 Bar Min - 1 Bar Position the mixer on the basin.
- Page 5 Installation MET-100 Installation - Quick guide Control Before installing your new mixer, flush handle through the pipework to ensure removal of debris, turn off the water supply. Place the O-ring in the slot on the underside of the base ring, position the base ring onto the bottom of the mixer.
- Page 6 Dimensions - MET-100 Installation - MET-110 45mm 42mm 100mm 106mm 90mm 42mm 47mm 50mm 1/2” 1/2” Operating Specifications Operating Specifications Operating Pressure Operating Pressure Minimum operating pressure 1 bar Minimum operating pressure 1 bar Maximum operating pressure 5 bar Maximum operating pressure 5 bar...
