System Sensor i3 Series Installation And Maintenance Instructions page 4

Connection diagrams with DSC Power 832 Panels
Figure 7. Connecting 4WTA-B, 4WTAR-B, and 4WITAR-B smoke detectors
to DSC Power 832 controls using RRS-MOD module with PGM output:
UL LISTED
ALARM
CONTROL
PANEL
DSC POWER 832
PURPLE
PGM 1
BROWN
YELLOW
AUX (+)
ORANGE
PGM 2
WHITE
5.6
K *
RED
AUX +
BLACK
AUX –
+
ZONE
–
ZONE (COM)
*NOTE: 5.6K resistor must be rated for 1/4W or greater. Must be present for panel to reset.
Figure 8. Connecting 2WTA-B smoke detectors to DSC Power 832 con-
trols using RRS-MOD module with PGM output:
UL LISTED
ALARM
CONTROL
PANEL
DSC POWER 832
PURPLE
PGM 1
YELLOW
AUX (+)
ORANGE
PGM 2
5.6
K *
RED
+
AUX
BLACK
AUX –
*NOTE: 5.6K resistor must be rated for 1/4W or greater. Must be present for panel to reset.
Testing
Before testing, notify the proper authorities that the system is
undergoing maintenance and will temporarily be out of service.
Test in accordance with NFPA 72 test methods, inspections,
and testing frequency.
1. Confirm that all smoke detectors connected to the RRS-
MOD module(s) contain a sounder and the sounders are
activated upon power reversal.
System Sensor warrants its enclosed product to be free from defects in
materials and workmanship under normal use and service for a period
of three years from date of manufacture. System Sensor makes no other
express warranty for the enclosed product. No agent, representative,
dealer, or employee of the Company has the authority to increase or alter
the obligations or limitations of this Warranty. The Company's obliga-
tion of this Warranty shall be limited to the replacement of any part of
the product which is found to be defective in materials or workman-
ship under normal use and service during the three year period com-
mencing with the date of manufacture. After phoning System Sensor's
toll free number 800-SENSOR2 (736-7672) for a Return Authorization
number, send defective units postage prepaid to: System Sensor, Returns
D500-44-00
1 + IN
2 + OUT
3 - IN/OUT
4 N.O.
5 C
BROWN
1 + IN
2 + OUT
3 - IN/OUT
WHITE
4 N.O.
5 C
Three-Year Limited Warranty
All smoke detectors on the 4-wire fire
zone will be synchronized in alarm
and will sound 1 sec ON, 1 sec OFF
only from a fire alarm event.
NOTE:
EOL RELAY
(SHOWN ENERGIZED) • Program zone section attributes
1 + IN
• PGM2 must be programmed for
2 + OUT
3 - IN/OUT
4 N.O. • PGM1 must be programmed as
5 C
• RRS-MOD switch must be set to
EOL
S0107-02
All smoke detectors on the 2-wire fire
zone will be synchronized in alarm,
and will sound 1 sec ON, 1 sec OFF
only from a fire alarm event.
NOTE:
EOL
• Program zone section attributes
• PGM2 must be programmed for
1 + IN
2 + OUT
3 - IN/OUT
4 N.O.
• PGM1 must be programmed as
5 C
S0108-02
• RRS-MOD switch must be set to
2. Initiate an alarm with one of the smoke detectors con-
nected to the RRS-MOD module using any approved test
method. In the alarm state, all the detectors connected to
the RRS-MOD module must be sounding their sounders.
3. Reset the system from the control panel. All smoke de-
tector sounders should be silent.
4. If the fire alarm panel also functions in burglary, initiate a bur-
glary alarm and ensure the smoke detectors do not sound.
Department, RA #__________, 3825 Ohio Avenue, St. Charles, IL 60174.
Please include a note describing the malfunction and suspected cause
of failure. The Company shall not be obligated to replace units which
are found to be defective because of damage, unreasonable use, modi-
fications, or alterations occurring after the date of manufacture. In no
case shall the Company be liable for any consequential or incidental
damages for breach of this or any other Warranty, expressed or implied
whatsoever, even if the loss or damage is caused by the Company's
negligence or fault. Some states do not allow the exclusion or limita-
tion of incidental or consequential damages, so the above limitation or
exclusion may not apply to you. This Warranty gives you specific legal
rights, and you may also have other rights which vary from state to state.
4
for bell output to be pulsing.
sensor reset.
Burglary and Fire Bell Output (01)
with ON, ON, OFF attributes.
OFF (factory default setting).
for bell output to be pulsing.
2-wire smoke zone (04). Jumper
J1 on the main board must be
removed.
Burglary and Fire Bell Output (01)
with ON, ON, OFF attributes.
OFF (factory default setting).
I56-2203-003
© System Sensor 2006
