1. Description

The EX-1309-T are plug & play high-speed USB 2.0 to Serial module. It converts USB
2.0 to one RS-232/422/485 ports. It is the optimal solution for connection with different
devices (e.g. Modem, Plotter etc.). The USB to Serial module design utilizes the Chip-
Set FTDI with 16C550 UART. The EX-1309-T is Hot Plug & Play compatible. It is not
possible to change the address or IRQ settings manually, they will be obtained auto-
matically by the operating system. The various types of transmission to the serial ports
can be set by using the dip-switches at the bottom of the EX-1309-T.
Features:
•
1x RS-232/422/485 via USB 2.0
•
5 Pin Terminal Block
•
Support RS-232, RS-422, RS-485 2-wire and RS-485 4-wire
•
Support Windows 9.x ME/ 2000/ XP/ Vista/ 7/ 8.x/ 10/ Server 20xx/ Linux/ MAC
•
Certificates for

2. Extent of Delivery

Before you connect the EX-1309-T to your PC, you should first check the contents of
the delivery:
•
EX-1309-T
•
Driver CD
•
Manual
