Victor 606B-II User Manual

USER'S MANUAL
1.
SUMMARIZE
This meter is a handheld automatic range digital multiemter which
driven by battery. It can be used to measure such parameters as DCV,
ACV, ACA, Resistance, Continuity Buzzer, Diode, Frequency,
Temperature, etc.
2.
GENERAL
Displaying：Max. displaying:4000，
Sampling rate: approx. 3 times/second.
Polarity indication：Automatic negative polarity indication
Over range indication：" OL" shown on the LCD
Low battery indication:"
Operation environment：0℃～40℃，R.H.< 75%.
Storage environment：-10℃～50℃，R.H.<80%.
Power supply： （Size AAA）1.5V×2
Size：193×73×37mm
Weight：about 220g.
Accessories：user's manual，battery，testleads，temperature probes。
3.
TECHNICAL CHARACTERISTIC
Accuracy:±(a%×rdg＋d)
3-1.ACV（V～）
RANGE
4V/40V/400V
600V
Input impedance：10MΩ
Frequency response：SIN wave and triangular wave is 40Hz～1kHz,
other wave is 40Hz～200Hz
3-2.DCV（
）
RANGE ACCURACY
400mV
4V
±(0.5%+7d)
40V
400V
600V
±(1.0%+6d)
Input
impedance：10MΩ
3-3.RESISTANCE （auto range）
RANGE ACCURACY
400Ω
4kΩ
±(1.0%+5d)
40kΩ
400kΩ
40MΩ ±(1.2%+10d)
3-4.ACA A auto range）
～(
" appears
Temperature:(23±5)℃，R.H.<75%
ACCURACY
±(0.8%+10d)
±(1.0%+10d)
RESOLUTION
0.1mV
1mV
10mV
100mV
1V
RESOLUTION
0.1Ω
1Ω
10Ω
100Ω
10kΩ
RANGE ACCURACY
4A
40A
±(4.0%+10d)
400A
600A
Frequency response：50～60Hz
3-5.FREQUENCY Hz auto range）
(
RANGE ACCURACY
1Hz
10Hz
100Hz
±(0.3%+3d)
1kHz
10kHz
100kHz
1MHz
10MHz
Shows zero when the signal is less than 3Hz；sensitivity：1V RMS
3-6.CAPACITANCE auto range)
(
RANGE ACCURACY
4nF
±(5.0%+40d)
40nF
400nF
±(5.0%+10d)
4uF
40uF
1000uF
3-7.TEMPERATURE ℃/℉
RANGE
-20℃～400℃
-4℉～752℉
4.
FRONT PANEL DESCRIPTION
Data Hold Key（HOLD/BL）
4-1.
When press the key, the "HOLD" symbol and the last reading of the
meter will be shown on the LCD, the symbol will disappear until
press the key again or turn the function switch, and the readings
comes back. Press "HOLD/BL"key to turn on the meter, the "APO"
symbol disappear, the auto power off function canceled. If turn on the
meter by switch as usual, the auto power off function is on, the meter
will turn off in 15 minutes if without any operation. This key got a
backlight function, press this key for 3 seconds, the backlight on; if
press this key again for more than 3 seconds, the backlight off.
4-2.Select Key（SELECT）
Turn switch to or
function you wish.
℃/℉
Turn to range , and press the key can transform the unit
℃/℉.
between
4-3.Range Select Key（RANGE）
ACV, DCV, ACA, RESISTANCE, etc. can be changed to auto range or
manual range by pressing the key. When it is under auto range, press
the key, then the "AUTO" symbol disappear. Then press the key for
RESOLUTION
0.001A
0.01A
0.1A
1A
RESOLUTION
0.01Hz
0.1Hz
1Hz
10Hz
100Hz
1kHz
10kHz
100kHz
RESOLUTION
1pF
10pF
100pF
1nF
10nF
1uF
ACCURACY
±(3.0%+2d)
range, press the key can choose the
