Connection with the mains

Connect the last tube to the controller, making sure that the poles are correct. The maximum load of the
device is 1000 W.
Connect the device to the mains with the power plug. Make sure that the outlet is in a dry area.
The occupation of the connection cables is as follows:
Cable Pin
Brown Live
Blue Neutral
Yellow/Green Earth
Attention! The earth has to be connected!
If the device will be directly connected with the local power supply network, a disconnection switch with a
minimum opening of 3 mm at every pole has to be included in the permanent electrical installation.
The device must only be connected with an electric installation carried out in compliance with the IEC
standards. The electric installation must be equipped with a Residual Current Device (RCD) with a maximum
fault current of 30 mA.
Please note: The lighting chain must never be covered with any object.

OPERATION

After you connected the device to the mains, the Controller Pro for LED Neon Flex 230V EC RGB is ready
for use.
Via the power switch you can turn the device on and off.
10 internal programs are selectable via the left decade switch (Function):
0. - Combination
1. - Fading Color (Red-Yellow-Green-Turquoise-Blue-Violet)
2. - Strobe 1 (all blink simultaneously)
3. - Switching Color 1 (Red-Green-Blue-White)
4. - Strobe 1 (Red-Green-Blue blink three times one after the other)
5. - Fading Color (Red-Yellow-Green-Turquoise-Blue-Violet)
6. - Switching Color 2 (Red-Green-Blue-Yellow-Turquoise-Violett-White)
7. - Switching Color 3 (Turquoise-Violet-Yellow)
8. - Color change and fade without colormix (Red-Green-Blue)
9. - Switching Color 4 (Red-Green-Blue)
Program speed is adjustable via the right decade switch (Speed) (1...7, decreasing speed).

CLEANING AND MAINTENANCE

We recommend a frequent cleaning of the device. Please use a soft lint-free and moistened cloth. Never use
alcohol or solvents!
International
L
N
DANGER TO LIFE!
Disconnect from mains before starting maintenance operation!
11/12 00053574, Version 1.2
