ECHO-COMSTOCK PELLET E.I. II
Pellet Heater Owner's Manual
Installation and Operating Instructions
Please read this entire manual before installation and use of the pellet fuel-burning room heater. Failure to follow these instructions
▪ HEATER MUST BE PROPERLY INSTALLED AND MAINTAINED OR A HOUSE FIRE MAY
RESULT.
▪ FOR YOUR SAFETY, FOLLOW THE INSTALLATION INSTRUCTIONS.
▪ CONTACT LOCAL BUILDING OFFICIALS ABOUT RESTRICTIONS AND INSTALLATION
INSPECTION AND PERMIT REQUIREMENTS.
▪ FAILURE TO COMPLY WITH OWNER'S MANUAL INSTRUCTIONS WILL VOID
WARRANTY AND COULD RESULT IN PROPERTY DAMAGE, BODILY INJURY OR EVEN
DEATH.
could result in property damage, bodily injury or even death.
PLEASE LEAVE THIS MANUAL WITH THE OWNER!!
SAFETY NOTICE
Echo-Comstock Pellet Ins Man Rev c 2020
Made in the USA by:
Advertisement
Table of Contents
Related Manuals for Thelin ECHO-COMSTOCK PELLET E.I. II
Summary of Contents for Thelin ECHO-COMSTOCK PELLET E.I. II
- Page 1 ECHO-COMSTOCK PELLET E.I. II Pellet Heater Owner's Manual Installation and Operating Instructions Made in the USA by: Please read this entire manual before installation and use of the pellet fuel-burning room heater. Failure to follow these instructions could result in property damage, bodily injury or even death.
-
Page 2: Table Of Contents
ECHO PELLET E.I. II PELLET HEATER INDEX OF CONTENTS Appendix A, 25 Installation, 7 Appendix B, 26 battery, 16 Appendix C, 27 clean out tee, 7 Appendix D, 28 distance to openings, 7 Battery floor protection, 7 installation, 16 pipe configuration, 7 operation, 16 pipe connections, 11 Battery Light, 16... - Page 3 ECHO PELLET E.I. II PELLET HEATER FIGURES Figure 1 - Overall Dimensions..........................7 Figure 2 ................................... 7 Figure 3 ................................... 8 Figure 4 ................................... 9 Figure 5 ................................. 10 Figure 6 ................................. 11 Figure 7 ................................. 12 Figure 8 ................................. 14 Figure 9 .................................
- Page 4 ECHO PELLET E.I. II PELLET HEATER LABORATORY LISTING LABEL...
-
Page 5: Laboratory Listing Label
ECHO PELLET E.I. II PELLET HEATER WARNINGS PELLETS OF HIGHEST BTU OUTPUT AND LOWEST % OF ASH CONTENT ONLY. HOT SURFACES! HOT GLASS WILL CAUSE Burning biomass fuels in other forms or poor BURNS. SURFACES AND GLASS ARE HOT quality pellet fuel is not permitted and will void DURING OPERATION AND DURING COOL- your warranty and/or could cause a burn back or DOWN PERIOD. -
Page 6: Introduction And Safety Information
ECHO PELLET E.I. II PELLET HEATER Provide adequate clearances around air openings into the combustion chamber and provide adequate accessibility clearance for servicing and proper operation. Never obstruct the front opening of the heater. THE ECHO REQUIRES OUTSIDE COMBUSTION AIR ON ALL INSTALLATIONS. NO EXCEPTIONS! (See Figure 2.) CAUTION: Do not connect this unit to a chimney flue serving another appliance. -
Page 7: Clearances
ECHO PELLET E.I. II PELLET HEATER CLEARANCES CHECK WITH LOCAL BUILDING OFFICIALS FOR SPECIFIC CODE REQUIREMENTS. A LISTED, TYPE "L" PELLET VENT PIPE IS MANDATORY ON ALL INSTALLATIONS. Clearance to Combustibles Unit to Sidewall........5" (125 mm) Unit to Backwall........3" ( 75 mm) Unit to Diagonal Wall ......3.5"... -
Page 8: Clean Out Tee
ECHO PELLET E.I. II PELLET HEATER INSTALLATION 5. Keep front door of appliance thirty-six (36) inches from combustibles (drapery, furniture). 1. When deciding on the location of your heater 6. When installing the exhaust vent into an and vent pipe, try to minimize the alteration and existing chimney, a clean out tee must be reframing of structural components of the installed behind the heater before going up into... -
Page 9: Figure 4
ECHO PELLET E.I. II PELLET HEATER FIGURE 4... -
Page 10: Figure 5
ECHO PELLET E.I. II PELLET HEATER FIGURE 5... -
Page 11: Figure 6
ECHO PELLET E.I. II PELLET HEATER FIGURE 6... -
Page 12: Pipe Connections
Installation per Figure 7 requires 4” pellet pipe. allow the gases to exit. The tee must have a 10. Outside Air Hook-up: Thelin Hearth Products clean out cap for inspection and regular recommends using a Dura Vent Wall Thimble cleaning (see Figure 4). -
Page 13: Wall & Remote Thermostat
If a remote thermostat is used you All Thelin Gas, Pellet, and Wood heaters are will have to mount the “receiver” to the bottom finished with high temperature paint that when of the stove with Velcro and then hook up properly cured provides years of service. -
Page 14: Figure 8
ECHO PELLET E.I. II PELLET HEATER FIGURE 8... -
Page 15: Filling
ECHO PELLET E.I. II PELLET HEATER SAFETY SWITCH TURNS OFF PELLET FEED MOTOR WHEN PELLET HOPPER DOOR IS OPEN FIGURE 9 FIGURE 10 START-UP AND OPERATION IMPORTANT: The quality of pellet varies from brand to brand. This will affect the efficiency of your heater. -
Page 16: Control Functions
ECHO PELLET E.I. II PELLET HEATER high the igniter will come on and in one minute the C. Control Functions feed motor will activate and begin feeding pellets. The control functions on the Echo are as follows: In three or four minutes you should see flame and in OFF, FAN, LOW, MED, HIGH, and CLEAN (see six minutes the igniter will shut off. -
Page 17: Operation
(available from your dealer or left of the fan button that will blink red if the flue Thelin Hearth Products) pipe becomes obstructed or there is a high wind 3. To hook up the battery and engage the 12-volt condition, creating a back draft. -
Page 18: Fly Ash Removal
7. The automatic ignition feature will not work on DC power only. The stove can be lit manually with an approved starter material. Call Thelin Hearth Products if you need help with manual lighting. -
Page 19: Fan Guard
ECHO PELLET E.I. II PELLET HEATER d. Remove fire pot by lifting up and out. It results, run the fan in the "Clean" position with may be brushed out or vacuumed. Fire pot the door open for approximately 45 seconds or should be cleaned regularly. - Page 20 ECHO PELLET E.I. II PELLET HEATER 2. Problem: The heater was lit and burning properly, have the air/fuel settings readjusted by your then suddenly it stopped feeding pellets. dealer. It is normal to have the glass cloud up after several hours of burning, but it should Solution: Check pellet supply in hopper.
- Page 21 ECHO PELLET E.I. II PELLET HEATER 7. Problem: I turned off the switch and the heater continued running. Solution: This is normal. The exhaust blower will keep running until it cools down and then it will automatically turn off. This can vary by the temperature the exhaust has reached and the temperature of the cooling air.
-
Page 22: Replacement Parts List
ECHO PELLET E.I. II PELLET HEATER FIGURE 13 – REPLACEMENT PARTS LIST... -
Page 23: Circuit Board Diagram
ECHO PELLET E.I. II PELLET HEATER FIGURE 14 - CIRCUIT BOARD DIAGRAM 19.4 Type 1 – Thermo On/Off Type 2 – Thermo Hi/Lo... -
Page 24: Electrical Schematic
ECHO PELLET E.I. II PELLET HEATER FIGURE 15 - ELECTRICAL SCHEMATIC/WIRING DIAGRAM... -
Page 25: Routine Maintenance
ECHO PELLET E.I. II PELLET HEATER FIGURE 16 – ROUTINE STOVE CLEAN OUT AND MAINTENANCE The following is a step-by-step procedure to clean out and maintain your pellet stove. Stove must be shut off and completely cold before performing this maintenance. -
Page 26: Wind Warning
(see Figure 2). Your Thelin Pellet Stove is equipped with a blocked flue/high temp safety sensor that will shut the stove off if there is a down draft, blocked flue, or high temperature condition. -
Page 27: Firepot Assembly
ECHO PELLET E.I. II PELLET HEATER APPENDIX B – E.I. FIREPOT ASSEMBLY... -
Page 28: Fine Tuning
ECHO PELLET E.I. II PELLET HEATER APPENDIX C – FINE TUNING Because of the variability of pellets (i.e., length run of pipe (over 10’) then as the pipe thickness, density, quality of sawdust), you warms up the draw can be intense enough to might have to—from time to time—fine tune suck more heat out of the stove than is your heater to compensate for pellet quality. -
Page 29: Igniter Removal
ECHO PELLET E.I. II PELLET HEATER APPENDIX D – IGNITER REMOVAL... -
Page 30: Warranty Information
THELIN LIMITED FIVE, THREE, ONE, YEAR LIMITED WARRANTY Thelin Hearth Products (THP), warrants to the original consumer this stove will be free of defective materials and workmanship for the following periods: Five Years-Outer structure excluding gold or nickel plating, Three Years-Interior metal construction, One Year- Electrical, gold or nickel plated rings &... - Page 31 ECHO PELLET E.I. II PELLET HEATER 775-241-2586...
