Rowlinson Garden Products Garden Chest Assembly Instructions

7. Roofing felt

Lay the felt over the lid ensuring that there is an equal overhang all round. Fold the felt over the front of the lid and
secure to the lid framing using 15 x 13mm felt nails evenly spaced. Tension the felt over the back edge of the lid, fold
down and secure using 15 x 13mm felt nails evenly spaced to the frame of the lid. Neatly fold the felt down on each side
of the lid and secure using 10 x 13mm felt nails evenly spaced per side. Once the felt is fully secured trim off any excess
felt. with a sharp knife.
13mm
Felt
nails
8.Bargeboard
Position the bargeboard against the front edge of the lid, ensure it is flush along the top edge and ends. Secure in place
using 5 x 38mm nails as shown.
38mm

Important information

Shiplap buildings come ready stained but this is only a preparatory treatment. To VALIDATE the guarantee, the building must be
properly treated with a recognised external wood preserver WITHIN 3 MONTHS of assembly and RE-TREATED ANNUALLY
thereafter.The building must also be erected on 50mm x 50mm treated wooden or similar bearers (These are not supplied with the kit.)
ground contact must be avoided.

Timber Information.

As timber is a natural material, there are certain weather conditions that may affect the materials properties. In times of excessive dry
spells the material may lose some of its internal moisture causing a certain degree of shrinkage on a panel and in periods of excessive
rain there will be a certain amount of swelling throughout the wooden panels. This process can not be avoided. If you have problems
with certain boards shrinking in dry spells try to decrease the amount of direct sunlight on the building or the amount of air passing
over the building. During hot spells spray water directly onto the panels with the aid of a garden hose.
If in doubt of any aspect regarding the assembly, use or safety of your garden chest please contact us :
Help Line (Normal Office Hours) 01829 261 121
ROWLINSON GARDEN PRODUCTS LIMITED
Unit 2 Green Lane
Wardle Nr. Nantwich
Cheshire
CW5 6BN
Tel : 01829 262 080
Fax : 01829 262 089
13mm
Felt
nails
13mm
Felt
nails
13mm
Felt
nails
We constantly improve the quality of our products, occasionally the
components may differ from the components shown and are only
correct at time of printing. We reserve the right to change the
specification of our products without prior notice.
2006 © Rowlinson Garden Products Ltd
Garden Chest
Assembly Instructions
Before Assembly
•
We recommend that time is taken to
read the instructions before starting
assembly, then follow the easy step by
step guide.The instruction sheet is only
a guide to the assembly.
Certain items may not be shown
to scale.
•
Check all components prior to assembly
•
This product should be assembled
by no less than 2 people
•
Drill all components where indicated
x 2
pre-drill

Recommended tools for assembly

•
Cross head screw driver
•
Hammer
•
Spirit level
•
Sharp knife
•
Drill
•
4mm drill bit
No. Components Qty.
1 Floor 1
2 Back panel 1
3 Left panel 1
4 Right panel 1
5 Front boards 2
6 removable front panel 1
7 Lid 1
8 Felt 1
9 Stay bar 1
10 Bargeboard 1
No. Fixing kit Qty.
11 T-hinges 2
12 Hook and eye set 1
13 50mm screws 5
14 25mm screws 14
15 38mm nails 27
16 13mm felt nails 50
English SS019G
8
11
12
9
3
2
1
6
5
7
10
4
