Rowlinson Garden Products Overlap Patio Chest Assembly Instructions

4. Roofing felt
Lay the felt over the lid ensuring that there is an equal overhang all round. Fold the felt over the front of the lid and secure
to the lid framing using 12 x 13mm felt nails evenly spaced. Tension the felt over the back edge of the lid, fold down and
secure using 12 x 13mm felt nails evenly spaced to the frame of the lid. Neatly fold the felt down on each side of the lid
and secure using 6 x 13mm felt nails evenly spaced per side. Once the felt is fully secured trim off any excess felt. with a
sharp knife.
13mm
Felt
nails
9. Bargeboards
Attach a short bargeboard to each side ensure the top and front edges are flush with the roof line and secure each board
in place using 3 x 30mm nails. Attach the long bargeboard to the front of the roof make sure it is flush to the roof line use
4 x 30mm nails as shown.
30mm
Important information
Timber Information.
As timber is a natural material, there are certain weather conditions that may affect the materials properties. In times of excessive dry
spells the material may lose some of its internal moisture causing a certain degree of shrinkage on a panel and in periods of excessive rain
there will be a certain amount of swelling throughout the wooden panels. This process can not be avoided. If you have problems with
certain boards shrinking in dry spells try to decrease the amount of direct sunlight on the building or the amount of air passing over the
building. During hot spells spray water directly onto the panels with the aid of a garden hose.
If in doubt of any aspect regarding the assembly, use or safety of your Patio Chest please contact us :
Help Line: (Normal Office Hours) 01829 261 121
Email: support@rowgar.co.uk
ROWLINSON GARDEN PRODUCTS LIMITED
Green Lane
Wardle Nr. Nantwich
Cheshire
CW5 6BN
www.rowgar.co.uk
13mm
Felt
nails
13mm
Felt
nails
13mm
Felt
nails
30mm
We constantly improve the quality of our products, occasionally the
components may differ from the components shown and are only
correct at time of printing. We reserve the right to change the spec-
ification of our products without prior notice.
2018 © Rowlinson Garden Products Ltd
Overlap Patio Chest
Assembly Instructions
Before assembly
•
We recommend that time is taken to
read the instructions before starting
assembly, then follow the easy step by
step guide. The instruction sheet is only
a guide to the assembly.
Certain items may not be shown
to scale.
•
Check all components prior to assembly
•
This product should be assembled
by no less than two people
•
Drill all components where indicated
x 2
Drill
English SS427
