Rowlinson Garden Products SS457 Assembly Instructions

Before assembly

•
We recommend that time is taken to read the
instructions before starting assembly, then
follow the easy step by step guide.
The instruction sheet is only a guide to
the assembly. Certain items may not be
shown to scale.
•
Check all components prior to assembly
•
This product should be assembled by no
less than two people.
•
Never attempt to erect the assembly in
high winds.
x 2

Recommended tools for assembly

•
Spirit level
•
Step ladder
•
Alan key (provided)
Caution
When connecting
components that use
the spring button.
Please ensure the
button is properly
located in the hole.
No. Components
1 Front left/right back leg
2 Front right leg
3 Back left leg
4 Front left outer rafter half
5 Front right outer rafter half
6 Back right outer rafter half
7 Back left outer rafter half
8 Centre track and pulley mechanism
9 Front left/back right outer track half
10 Front right/back left outer track half
11 Centre rafter half with coupling
12 Centre rafter half
13 fixed canopy tubes
14 Canopy tubes
15 Foot plates
16 Polyester canopy
17 Runner
No. Fixing Kit
18 15mm long barrel bolts
19 15mm bolts
20 35mm bolt
21 85mm bolt
22 Plastic bolt caps
23 Foot pegs
24 Allen key
Latina Canopy (GREY)
Assembly Instructions
Qty.
2
1
1
9
1
1
1
1
1
2
2
4
4
2
8
4
1
8
Qty.
32
44
4
8
56
1
16
2
10
14
17
8
11
2
English SS457
