Table Of Contents - Tru-Turf RS48-11D Manual

Contents
Revised 06/June/2013
Important ................................................................1
Machine Information Record ...............................2
Safety Information.................................................3
Warranty ..................................................................4
CE Declaration ........................................................5
Assembly .................................................................7
Operation ..............................................................10
Maintenance .........................................................12
Fault Finding .........................................................14
Machine Components ............................................. 15
Operating Positions .............................................15
Upper Body Assembly .........................................16
Honda Engine Mounting Assembly .................17
Seat Assembly ......................................................18
Adjusting Seat Base .............................................19
Power Train General Assembly .........................20
Transmission Assembly & Pipe Fittings............21
Transmission Assembly & Cooling Fan ............22
Transmission, Chain & Tension Assembly .......23
Transmission Pipes & Reservoir .........................24
Transmission Hydraulic Reservoir & Fittings ..25
Yoke & Strut Assembly ........................................26
Under body ...........................................................27
Brake Assembly ....................................................28
Foot Pedal Assembly ...........................................29
Joystick & Steering Assembly .............................30
Steering & Tie Rod Assembly .............................31
Smoothing Head Assembly ...............................32
Smoothing Roller Assembly Exploded ............33
Drive Roller ............................................................34
*Slicer Frame Assembly ......................................35
TRU-TURF RS48-11D USA Roll 'n' Spike & RS48-11DB Golf Greens Roller Manual
The products detailed in this manual conform to the following standards:
Machinery Directive 2006/EC Annex VIII,
EMC Directive 2004/108/EC / Article 10.1 & EN ISO 4254-1:2009.
CE Declaration is available on the Tru-turf website.
*Slicer Assembly ...................................................36
Trailer Assembly ...................................................37
Hub Complete Assembly ....................................38
LED Light Kit (Optional) ......................................39
*Brush Kit (Optional) .......................................... 40
Labels .....................................................................42
Sample Forms .......................................................43
Notes & Bulletins ..................................................45
Note: Separate Engine Owners Manual Included
Th is manual covers 2 models,
RS48-11D Serial Number range 12000 to 12948
& RS48-11DB serial number range RDB0001 to
RDB0033 inclusive for both.
Th e RS48-11DB is a basic version of the
RS48-11D, both models are identical with the
following exceptions.
Th e RS48-11DB has all components relating to the
Slicer/Spiker excluded.
Th e pages in this manual that cover the
Slicer/Spiker components are not applicable to
the RS48-11DB model, these are identifi ed with
an asterisk * next to the each page in the contents
list above and against each item detailed on the
following pages.
Should the owner wish to add the excluded Slicer/
Spiker components to the machine these are
available as a kit. Th e kit can be purchased through
your nearest dealer / Service agent.
