Assembly
Initial Assembly
When you receive the crate, the machine will be broken
down into components ready for assembly. If you run into
any problems during assembly, please feel free to call your
local distributor or agent.
List of Components
QTY
Description
1
Operation, Maintenance and Parts Manual
1
Machine Frame/Body
1
Drivers Seat
2
Armrests
4
5/16" x ³/4" UNC Bolts
2
Tires mounted on Wheel Rim
1
Steering Joystick
1
Dampener Strut
(attached to main body end)
1
Left-side Trailer Arm
1
Right-side Trailer Arm
2
30mm External Circlips
1
Drawbar Coupling Assembly
2
2¹/2" x 3/8" UNF Hex Head Bolts
2
³/8" UNF Nyloc Nuts
7
TRU-TURF RS48-11D USA Roll 'n' Spike & RS48-11DB Golf Greens Roller Manual
