IMPORTANT
CLS-M
Cargo Lift Scale
Scale Installation
Requirements On
Con-way Forklifts
October 2011
126696

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CLS-M and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Rice Lake CLS-M

  • Page 1 IMPORTANT CLS-M Cargo Lift Scale Scale Installation Requirements On Con-way Forklifts October 2011 126696...
  • Page 2 Introduction The CLS-M Cargo Lift Scale is designed to fit on most forklifts. However when a forklift has been in use for a while some of the basic components may become worn or damaged through everyday use and may inhibit the installation process.
  • Page 3 Figure 3. Welded Washer to Prevent Side Shifting A washer has been welded to the mast of the forklift (Figure 3) to provide protection from side shifting of Note unit. More coverage of the scale would be preferred. CLS-M Installation Manual...
  • Page 4 Not all forklift carriages have the same gaps for the centering pin, based on year/model, service work Note performed or years of wear from usage. CLS-M Installation Manual...
  • Page 5 Top Cleats Designed to securely hold the CLS-M Cargo Lift Scale on the mast of a Class II forklift with a 16” carriage. Figure 5. Top View of Rice Lake Weighing Scale Installed • Check that the installation location of the cleats on the forklift carriage mast is smooth and clear of any excess material or debris.
  • Page 6 • If forklift carriage is not flat, may cause increased gap and improper installation. • If bottom cleat and forklift carriage rub, it may cause mechanical interference and inaccurate weighing. PN 126696 10/2011 CLS-M Installation Manual...
