- Page 1 User Manual...
-
Page 2: Table Of Contents
TABLE OF CONTENTS BEFORE YOU BEGIN ....................3 LIST OF COMPONENTS ................. 3 REVOLVER INSTALLATION 95-97 Trucks ..............4 REVOLVER INSTALLATION 98-03 Trucks ..............7 SWITCH INSTALLATION ..................12 SAFETY WARNING & CAUTION ................14 SAFETY GUIDELINES ....................15 LIMITED 1 YEAR WARRANTY ..................16 VEHICLE WARRANTY INFO ..................18... -
Page 3: Before You Begin
BEFORE YOU BEGIN LIST OF COMPONENTS SWITCH SCOTCH-BRITE PAD SWITCH HARNESS ALCOHOL PREP PAD Iso- propyl REVOLVER PCM COVER STICKER... -
Page 4: Revolver Installation 95-97 Trucks
- Screw driver 1 Remove the keys from the ignition and disconnect both batteries. Failure to do so may cause damage to the PCM and Revolver. 2 Remove the driver’s side kick panel. 3 Remove the emergency brake bracket by removing the (3) 13mm nuts from the... - Page 5 4 Remove the plastic cap to expose the terminal. 5 With the provided Scotch-Brite pad clean the rubberized protective coating off of the terminal contacts. Both sides of the terminal need to be cleaned. It is important that the contacts are sufficiently clean to avoid any connection issues. CAUTION: Be careful when cleaning the connector to not damage the contact with excessive force.
- Page 6 INSTALLATION CONTINUED 7 Connect the Switch harness to the Revolver and slide the Revolver into the PCM. NOTE: Make sure the connector clips together before installing or the harness could slide out. 8 Cover the opening with the provided PCM cover sticker.
-
Page 7: Revolver Installation 98-03 Trucks
- Screw driver 1 Remove the keys from the ignition and disconnect both batteries. Failure to do so may cause damage to the PCM and Revolver. 2 Locate the wiring harness on the fire wall in the engine compartment that connects to the PCM. - Page 8 INSTALLATION CONTINUED 3 From inside the cab remove the (2) 7mm bolt holding the computer in place. For manual trucks this will be a 10mm bolt holding the top and a 10mm nut on the bottom. 4 Remove the PCM from the truck by sliding it out slowly.
- Page 9 5 Remove the PCM from the plastic housing and remove the plastic cap exposing the terminal. 6 With the provided Scotch-Brite pad clean the rubberized protective coating off of the terminal contacts. Both sides of the terminal need to be cleaned. It is important that the contacts are sufficiently clean to avoid any connection issues.
- Page 10 INSTALLATION CONTINUED 8 Connect the Switch harness to the Revolver and slide the Revolver into the PCM. NOTE: Make sure the connector clips together before installing or the harness could slide out. 9 Cover the opening with the provided PCM cover sticker.
- Page 11 11 Replace the bolts or nuts removed earlier holding the PCM in place. 12 Reconnect the wiring harness in the engine compartment going through the firewall and tighten the 10mm bolt. Continue to the Switch installation section.
-
Page 12: Switch Installation
SWITCH INSTALLATION Required Tools - 3/8” Drill bit - Allen wrench 1 Route the Switch harness from the PCM to the desired mounting location of the Switch. 2 With a 3/8” drill bit, drill a hole to mount the Switch in. 3 Align and adhere the level indicator label around the hole as desired. - Page 13 5 Rotate the Switch fully counter-clockwise. Then align the knob and tighten the set screw, with the indicator pointing to level 1 with the Allen wrench. NOTE: Loosen the set screw before installing the knob 6 Reconnect the batteries and start the truck.
-
Page 14: Safety Warning & Caution
CAUTION: indicates a condition that could cause damage to your vehicle. It is important to install and operate your Edge Products product in conformance with instructions in this Manual. Caution alerts you to particularly important things that will keep your vehicle operating properly. -
Page 15: Safety Guidelines
3. “Stacking” performance-enhancing devices or other improper installation can cause power train failure on the road. Other products may have features incompatible with your Edge Products device. Follow all installation and operating instructions, and do not stack products. 4. Some modifications may affect other parts of your vehicle. For example, if you remove/adjust the speed limiter in your vehicle, be sure your tires and other components are rated for the increased speeds they will have to withstand. -
Page 16: Limited 1 Year Warranty
Powerteq, LLC, (hereafter “SELLER”), subject to the conditions and limitations set forth herein, warrants to the original consumer purchaser only that each Revolver product sold by SELLER (the “Product”) through an authorized dealer will be free from defects in material and workmanship under normal operating conditions for one (1) year after the date of purchase. - Page 17 Limitation of Liability The terms of this Limited Warranty constitute the entire agreement between the parties with respect to the Product. The original consumer purchaser’s exclusive remedy shall be limited to the repair or replacement of the defective product. EXCLUDING THE LIMITED WARRANTY PROVIDED ABOVE, SELLER, TO THE MAXIMUM EXTENT PERMITTED BY LAW, MAKES NO WARRANTIES, EXPRESSED OR IMPLIED, AND DISCLAIMS ALL WARRANTIES, DUEITES AND CONDITIONS, WHETHER EXPRESS, IMPLIED, OR STATUTORY, WITH...
-
Page 18: Vehicle Warranty Info
VEHICLE WARRANTY INFO Many of our customers ask, “Will your product void my vehicle’s manufacturer’s warranty?” Powerteq is committed to providing quality products that are safe to use. Our products do not cause damage to a vehicle when used as intended in accordance with the User Manual and should not void your vehicle’s manufacturer’s warranty. - Page 19 whatever modifications you have added to your vehicle actually caused the problem in question. In order to understand your rights under the Federal Magnuson-Moss Warranty Act, Powerteq recommends that you contact qualified legal counsel.
- Page 20 Copyright© 2017 Rev 00 For additional questions not found in the user guide call: Edge Products Technical Support: (801)-476-3343 6:00 am - 6:00 pm MST To expedite your support call, please have your Vehicle Information, Part Number, and Serial Number ready prior to calling Technical Support.
