Caravan roof mount air conditioner, includes electric heat kit
Hide thumbs
Table of Contents

Advertisement

Quick Links

ROOF MOUNT AIR CONDITIONER
-IMPORTANT INSTRUCTIONS
MUST STAY WITH
OWNER-READCAREFULLY.
WICHTIGE HINWEISE, DIE SICH IM BESITZ
DES WOHNWAGENINHABERS BEFINDEN
MUSSEN - BITTE SORGFALTIG DURCHLE-
LE CONTENU DE CETTE NOTICE EST TRES
IMPORTANT, AUSSI L'UTILISATEUR DE
L'APPAREIL DOIT-IL EN POSSEDER
UN EXEMPLAIRE ET LE LIRE
ATTENTIVEMENT.
VIKTIGA ANVISNINGAR.
SKALL ALLTID MEDFOLJA AGGREGATET
OCH NOGGRANT LASAS AV AGAREN.
Form No. 3104963.024 6/93
1 9 9 2 , 1993 The Dometic Corp.
LaGrange, IN 46761
CARAVAN
MODEL CAL136.302
INCLUDES ELECTRIC HEAT KIT
