Collar options for MGG Maxi and 023B Dog Fence Systems
Collar
Mans to USB
Charging Lead
Test Light
Longer Probes for Extra
Furry Dogs
The MGG "DFC MAXI RC" Re-chargeable and waterproof collars for the MGG Maxi and 023B Dog Fence Systems are
suitable for those systems purchased from MGG after January 2013.
Please charge for a minimum of 8 hours for the first 2 times. After that 1.5 to 2 hours will be sufficient. Charging
longer than 3 to 5 hours at a time will reduce the life of the battery. When charging, the light will be red and when
fully charged the light will be green. If in daily use it is a good idea to charge it once every one or two weeks. To
maintain the collar's moisture seal, please ensure that the rubber bung for the charging port is re-inserted
completely after charging.
The indicator light will flash whilst the collar is being activated by the boundary wire.
You can charge from your computer with the usb cable provided or use the usb mains adapter provided.
When charged, the receiver is always in standby mode so it will always be using some power. If the collar is tested
and the indicator light is red, then the collar needs re-charging.
There is just the one pre-set level of static shock which will suits all dogs over 7Kgs bodyweight
The Regular MGG Maxi Collar (Battery Type)
Preparing the MGG Maxi Receiver Collar. Please read all the steps before setting
correction levels.
The MGG Maxi Re-chargeable and Waterproof Collar
Mains to USB
Charging Adapter
Re-chargeable
Receiver
The Collar goes through these
loops and around the back of the
receiver box
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for MGG Maxi
Summary of Contents for MGG Maxi
- Page 1 The MGG “DFC MAXI RC” Re-chargeable and waterproof collars for the MGG Maxi and 023B Dog Fence Systems are suitable for those systems purchased from MGG after January 2013. Please charge for a minimum of 8 hours for the first 2 times. After that 1.5 to 2 hours will be sufficient. Charging longer than 3 to 5 hours at a time will reduce the life of the battery.
- Page 2 Your Receiver Collar comes with short contact points installed. Use the long contact points for dogs with long or thick hair. Tighten the contact points with pliers one half of a turn beyond finger tight. Please check the tightness weekly. If leaving another collar on your dog DO NOT have it on the same side of the receiver box that has the rubber button or the rubber button will be destroyed.
- Page 3 In the case of an apparent malfunction we suggest you re-test by performing the short loop test as per page 18 of the Maxi instruction manual. This will determine whether it is the collar or the transmitter or the boundary wire is causing the problem.
- Page 4 The MGG 337B Re-chargeable collar is the smallest of the 4 options for the MGG Maxi and 023B Dog Fence systems. It is suitable for dogs of 3Kg and over. It is fully weatherproof but not submersible in water. Charge by usb or with the adapter included. One static impulse setting for all dogs and the collar is equipped with a motion sensor which turns it on when it detects movement and off if there is no movement.
