Xantrex GT5.0-NA Owner's Manual

Grid tie solar inverter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Grid Tie Solar Inverter
GT5.0-NA
Owner's Manual
Xantrex Grid Tie
Solar Inverter

Advertisement

Table of Contents
loading

Related Manuals for Xantrex GT5.0-NA

Summary of Contents for Xantrex GT5.0-NA

  • Page 1 Grid Tie Solar Inverter GT5.0-NA Owner’s Manual Xantrex Grid Tie Solar Inverter...
  • Page 3 Xantrex Grid Tie Solar Inverter Owner’s Manual...
  • Page 4 About Xantrex Xantrex Technology Inc. is a world-leading supplier of advanced power electronics and controls with products from 50 watt mobile units to one MW utility-scale systems for wind, solar, batteries, fuel cells, microturbines, and backup power applications in both grid-connected and stand-alone systems. Xantrex products include inverters, battery chargers, programmable power supplies, and variable speed drives that convert, supply, control, clean, and distribute electrical power.

  • Page 5: About This Manual

    About This Manual The purpose of this Owner’s Manual is to provide explanations and procedures for installing, operating, maintaining, and troubleshooting the Xantrex Grid Tie Solar Inverter™. Scope The manual provides safety guidelines, detailed planning and setup information. It provides procedures for installing the inverter and information about operating and troubleshooting the unit.

  • Page 6: Conventions Used

    About This Manual Conventions Used The following conventions are used in this guide. WARNING Warnings identify conditions that could result in personal injury or loss of life. CAUTION Cautions identify conditions or practices that could result in damage to the unit or other equipment.

  • Page 7: Symbols Used

       5 min. Related Information You can find more information about Xantrex Technology Inc. as well as its products and services at www.xantrex.com. 975-0320-01-01 Ground In this guide: Important information, warnings, or cautions. On the product: Important information, warnings or cautions with further explanation in the product guide.

  • Page 9: Important Safety Instructions

    Important Safety Instructions SAVE THESE INSTRUCTIONS—This manual contains important instructions that shall be followed during the installation and maintenance of the Xantrex Grid Tie Solar Inverter. WARNING The following warnings identify conditions or practices that could result in personal injury or loss of life. 1.

  • Page 10: Location Of Safety And Data Labels

    Safety Location of Safety and Data Labels The figure below shows the location of the safety label and the data label with model, serial and part number information. Safety Label FCC Information to the User This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.

  • Page 11: Table Of Contents

    Contents Important Safety Instructions - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - vii Location of Safety and Data Labels - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - viii FCC Information to the User - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - viii 1 Introduction About the Xantrex Grid Tie Solar Inverter - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 1–1...
  • Page 12 Contents 4 Starting the Inverter Startup Procedure - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4–1 Checking the PV Array DC Voltage - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4–2 Checking the AC Utility Voltage - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4–2 Replacing the Wiring/Disconnect Box Cover - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4–2...
  • Page 13 Mechanical Specifications - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - A–5 Regulatory Approvals - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - A–5 Warranty and Return Information - - - - - - - - - - - - - - - - - - - - - - - - - - - - -WA–1 Index - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -IX–1...

  • Page 15: Introduction

    Chapter 1 contains information about the features and functions of the Xantrex Grid Tie Solar Inverter. About the Xantrex Grid Tie Solar Inverter The Xantrex Grid Tie Solar Inverter (GT Inverter) is designed to convert solar electric (photovoltaic or PV) power into utility-grade electricity that can be used by the home or sold to the local power company.

  • Page 16: Standard Features

    Introduction PV compatibility The GT Inverter is designed to take advantage of solar modules configured as high voltage PV string arrays—single crystalline, poly crystalline, or thin film—with a 240 to 550 Vdc input voltage Maximum Power Point range. Maximum Power The GT Inverter uses Xantrex proprietary Maximum Power Point Tracking Point Tracking (MPPT) technology to harvest the maximum amount of energy from the solar...

  • Page 17: Front Panel Features

    Front Panel Features Grid Tie Solar Inverter Figure 1-2 Main Features of the GT Inverter Wiring/Disconnect Box The wiring/disconnect box is standard for all North American models of the GT Inverter. The wiring/disconnect box provides a location for making AC, DC and ground connections.
  • Page 18 1–4...

  • Page 19: Installation

    Chapter 2 provides information about installing the GT Inverter. It contains information on determining a suitable location for installation, PV array requirements, and procedures for mounting the unit. Installation Options The GT Inverter may be installed as a single inverter for a single PV array of one to three PV strings (an external fuse box is required when three PV strings are connected), or in a multiple inverter configuration for multiple PV arrays.
  • Page 20 Installation Inverter failure due to improper installation will void the inverter warranty. Consider the following when determining where to install the inverter. Indoor/ Outdoor Orientation Temperature • Ground Clearance Distance Debris free 2–2 • The GT Inverter uses a Type 3R-rated enclosure (vertical mount only) that can be mounted indoors or outdoors.

  • Page 21: Pv Array Voltage And Mppt Requirements

    PV Array Voltage and MPPT Requirements WARNING: Shock hazard Whenever a PV array is exposed to sunlight, a shock hazard exists at the output wires or exposed terminals. To reduce the risk of shock during installation, cover the array with an opaque (dark) material before making any connections, and always test for voltage before touching exposed wiring or devices.
  • Page 22 Installation Guidelines for Matching PV Array Size to Xantrex Grid Tie Solar Inverter Input • Consider the expected V panel manufacturer provides a V does not exceed 600 Vdc. Panel voltage increases in cold temperatures—the panel manufacturer should be able to provide a coefficient of voltage increase per degree.

  • Page 23: Mounting The Inverter

    Mounting the Inverter Dimensions and Knockout Locations The dimensions of the inverter and the mounting bracket and some of the knockout locations on the wiring/disconnect box are shown in Figure 2-1 and Figure 2-2. Four 27 or 35 mm (1 or 1-3/8 inch) dual knockouts are provided on the back and bottom of the unit to accommodate wiring.

  • Page 24: Installing The Mounting Bracket

    Installation Installing the Mounting Bracket The mounting bracket is designed to be affixed to the vertical structure or surface to which the GT Inverter will be mounted. The GT Inverter mounting hooks attach to the flanges on the mounting bracket. If mounting more than one inverter, install each mounting bracket at least 15 cm (6 inches) apart to provide enough space for the inverters to hang side by side.
  • Page 25 Clearance Requirements For optimal and safe operation, ensure there is adequate clearance around the inverter. If the minimum clearances in Table 2-2 are are not met, rated power may not be achieved. Table 2-2 Inverter Clearance Requirements Location Above Below: •...

  • Page 26: Mounting The Inverter On The Bracket

    Installation Mounting the Inverter on the Bracket Place the inverter’s mounting hooks over the flanges on the bracket. Ensure the inverter is seated properly, then secure the bottom of the inverter with appropriate screws or anchors through the mounting slots. Flange with mounting slots Figure 2-3 Placing the Inverter on the Mounting Bracket...

  • Page 27: Wiring The Inverter

    Chapter 3 provides information about DC and AC wiring, and grounding the GT Inverter and the PV array. This chapter does not provide sufficient information for anyone but a qualified installer to install this product. Installers should be electricians or technicians fully educated on the hazards of installing electrical equipment.
  • Page 28 Wiring the Inverter Ground bar Knockouts for ground conductors Figure 3-1 Ground Conductor Knockouts The ground bar accepts wires up to #4 AWG. Torque ground wires as specified in Table 3-1. Table 3-1 Torque Values for Ground Wiring Wire Size 14–10 6–4 Important:...

  • Page 29: Ground Fault Fuse

    PV1 String #1 Figure 3-2 Grounding Diagram Ground Fault Fuse The GT Inverter is equipped with a 600 volt, 1 amp ground fault protection fuse (replace with Littelfuse KLKD 1 or equivalent). WARNING: Shock hazard Do not attempt to service the ground fault protection fuse yourself. This should only be done by qualified service personnel, such as certified electricians or technicians.

  • Page 30: Wiring Requirements

    Wiring the Inverter Wiring Requirements WARNING: Shock hazard Check for existing electrical or plumbing prior to drilling holes in the walls. The AC and DC terminal blocks in the GT Inverter accept wire sizes from #14 AWG to #6 AWG. Undersized wiring can result in significant power losses and reduction in system efficiency.

  • Page 31: Accessing The Wiring Terminals

    WARNING: Shock hazard Do not remove the wiring/disconnect box. The 600 volt DC/AC disconnect in the wiring box meets NEC Article 690. It is a non-serviceable component and shall remain in place. Removal can expose energized conductors. Use caution when working around sources of DC power. Although the DC/AC disconnect switch disconnects the inverter from DC power, hazardous voltages from paralleled PV strings will still be present upstream of the switch and inside the wiring box.
  • Page 32 Wiring the Inverter Figure 3-4 Insulating Barrier Location (PV-) Figure 3-5 AC and DC Terminal Block Location 3–6 Lift bottom edge of barrier to access wiring terminals. (PV+) (AC L1) (AC L2) (NEUT) (GND) 975-0320-01-01...

  • Page 33: Connecting The Dc Wiring

    Connecting the DC Wiring WARNING: Shock hazard Use caution when working around sources of DC power. Although the DC/AC disconnect switch disconnects the inverter from DC power, hazardous voltages from paralleled PV strings will still be present upstream of the switch and inside the wiring box. To reduce the risk of shock during installation, cover the array with an opaque (dark) material before making any connections, ensure the DC/AC Disconnect Switch is set to OFF (see Figure 3-6), and always test for voltage before touching exposed wiring or devices.
  • Page 34 Wiring the Inverter Figure 3-7 DC Connections for Multiple PV Strings Important: box may be required. This fusing and combiner box are to be provided by the installer. Important: local codes before installation. 3–8 PV1 String #1 PV1 String #2 –...

  • Page 35: Dc Wiring For Multiple Inverters

    DC Wiring for Multiple Inverters For installations with multiple GT Inverters, separate solar arrays are required for each unit. The output of each GT Inverter feeds a separate dual-pole 30-amp circuit breaker (L1 and L2) in the main utility service panel. For such installations, complete the wiring and perform the commissioning procedure for each inverter one at a time.

  • Page 36: Connecting The Ac Wiring

    Wiring the Inverter Connecting the AC Wiring WARNING: Shock hazard Before wiring the GT Inverter, ensure the main breaker in the primary utility breaker box is switched OFF. Switch this breaker ON only after all wiring is completed as instructed in the procedures.

  • Page 37: Dc And Ac Wiring For Multiple Inverters

    DC and AC Wiring for Multiple Inverters DC and AC wiring for multiple inverters is illustrated in Figure 3-10. If there will be more than one PV array, label the positive and negative wire pairs appropriately (for example: PV1 POS, PV1 NEG, PV1 GND, PV2 POS, etc.). If required by the AHJ, a DC grounding conductor may be connected to each inverter’s ground bar.

  • Page 38: Communications Wiring For Multiple Inverters

    Wiring the Inverter Communications Wiring for Multiple Inverters Communications wiring between multiple GT Inverters allows information about each inverter and its associated PV array to be communicated between all of the inverters in the system. Information about the entire system can be displayed on any inverter LCD in the system.
  • Page 39 Terminators The male network terminator supplied with each GT Inverter (Figure 3-12) is required at each end of the network to ensure the communication signal quality on the network. Figure 3-12 Male Network Terminator GT Inverter Xanbus Two RJ45 ports are provided in the GT Inverter, accessible from the wiring box. Ports See Figure 3-13 for the location of these ports.
  • Page 40 Wiring the Inverter Table 3-2 T568A Standard Wiring Pin Number Conductor Name Figure 3-14 RJ45 Connector Purchasing Network Components Consult your system designer to determine what network components will be needed for your specific installation. Table 3-3 provides a partial list of network components and part numbers.

  • Page 41: Guidelines For Routing The Network Cables

    Guidelines for Routing the Network Cables WARNING: Shock hazard Do not route the network cables in the same conduit or panel as the AC and DC power cabling. The cables should run on top of the insulation barrier inside the wiring/disconnect box and out the side conduit hole, avoiding any contact with the AC and DC wiring.
  • Page 42 Wiring the Inverter RS-232 cable To connect your computer to the GT Inverter, you must use a serial DB9 “straight requirements through” cable. The RS-232 connector on the GT is configured as follows: • Pin 2: transmit • Pin 3: received •...

  • Page 43: Starting The Inverter

    Chapter 4 contains information on starting up the Xantrex Grid Tie Solar Inverter and performing a functional test. The topics in this chapter are organized as follows: • “Startup Procedure” on page 4–1 • “Commissioning Multiple Inverters” on page 4–3 •...

  • Page 44: Checking The Pv Array Dc Voltage

    Starting the Inverter Checking the PV Array DC Voltage To check the PV array DC voltage: 1. Uncover the PV arrays and expose them to full sunlight. The sunlight must be intense enough to produce the required output voltage. 2. Measure the PV array open circuit DC voltage across the DC positive (+) and negative (–) terminals.

  • Page 45: Starting Up The Gt Inverter

    Starting up the GT Inverter To start up the inverter: 1. Switch the DC/AC disconnect switch to the ON position (see Figure 4-1). 2. Check the GT Inverter LCD. The startup screens (see Table 5-1 on page 5–2) should appear for five seconds each, and then the “Reconnecting in sss seconds”...
  • Page 46 Starting the Inverter If the inverter stops operating after the input current has risen above 1 A, turn the unit off, remove DC power, and have a certified electrician or technician inspect the ground fault protection fuse. If the fuse has blown, a DC wiring problem may exist.

  • Page 47: Disconnect Test

    Disconnect Test The disconnect test is designed to verify correct operation of the GT Inverter both on initial operation and periodically through its life as required by the utilities. This test ensures that the Xantrex Grid Tie Solar Inverter does not send electricity to the utility grid when the local utility has shut off the grid for repairs, or when the utility wiring is damaged.
  • Page 48 4–6...

  • Page 49: Monitoring The Inverter

    Chapter 5 contains information for understanding the LCD screens and the LED indicators. Monitoring the Front Panel Display During startup During startup, the inverter’s front panel LCD (see Figure 5-1) shows the screens described in Table 5-1, “Startup Screens on GT Inverter Front Panel Display” on page 5–2.

  • Page 50: Front Panel Display Screens And What They Mean

    Monitoring the Inverter Viewing more Additional screens of information about the performance of the GT Inverter can be information displayed by tapping the Xantrex logo on the inverter front panel. This causes the LCD to cycle through a series of information screens in Normal Operation, Offline or Fault modes.
  • Page 51 Table 5-1 Startup Screens on GT Inverter Front Panel Display Vph= Clr t < 1.00s Vpl= Clr t < 2.00s Clr t < 0.16s Clr t < 0.16s Reconnect Delay * The voltage and frequency thresholds, clear times and reconnect delay in †...

  • Page 52: Normal Operation Mode

    Monitoring the Inverter Normal Operation Mode The LCD on the GT Inverter is refreshed every two seconds, so all readings are current to within two seconds. There is a default display available at all times, and a series of additional screens that can be displayed by tapping the Xantrex logo near the LCD to change the display.
  • Page 53 Table 5-3 Normal Operation Screens for All GT Inverter Units 1st time 2nd time 3rd time 4th time 5th time * In a multiple unit system with network cables properly installed, the system Additional screens In addition to the normal system message screens, additional screens specific to for multiple units each GT Inverter unit can be displayed when the unit is networked to other GT Inverters.

  • Page 54: Offline Mode

    Monitoring the Inverter Offline Mode Offline default At night and when no power is being produced by the PV array (offline mode), the display GT Inverter displays the screen shown in Table 5-5. Table 5-5 Offline Mode Default Display Offline messages Additional message screens can be viewed when the system is offline by tapping for all systems the Xantrex logo near the LCD.
  • Page 55 Table 5-7 Additional Offline Mode Screens for Each GT Inverter Unit in a Multiple Unit System 5th time 6th time 975-0320-01-01 Front Panel Display Screens and What They Mean Display Unit 0W Power being produced by this unit now. Today 1.25kWh Cumulative energy produced by this unit today.

  • Page 56: Fault Mode

    Monitoring the Inverter Fault Mode When a fault state is detected, the appropriate fault message appears on the front panel display at the next screen refresh (within 2 seconds). The GT Inverter fault message screens are shown in Table 5-8. Fault Mode causes These message screens only appear when there is a fault, and then flash alternately with the Inverter Offline default screen (Table 5-5) until the fault is...
  • Page 57 * It is normal to receive this fault during low light conditions at dawn or dusk. At † Grid fault. When this fault is cleared the protection timer will begin its Additional Fault Additional message screens can be viewed in fault mode by tapping the Xantrex messages for all logo near the LCD.

  • Page 58: Special Screens

    Monitoring the Inverter Special Screens Special message screens are displayed in specific situations that are not considered fault situations. They can appear in any mode of operation. These screens are described in Table 5-10. Table 5-10 Special Message Screens Reconnecting in sss seconds System *3500W Today 15.56kWh...

  • Page 59: Status Indicator Lights

    Status Indicator Lights The GT Inverter has two status indicator lights (LEDs) located below the front panel LCD (Figure 5-2). These LEDs indicate the inverter’s status (Table 5-11) and assist in troubleshooting the performance of the unit. Only one indicator light will be lit at any time. Table 5-11 Status Indicator LEDs LED on GREEN...
  • Page 60 5–12...

  • Page 61: Maintenance And Troubleshooting

    Chapter 6 contains information about how to provide general maintenance for the Xantrex Grid Tie Solar Inverter. It also provides information about troubleshooting the unit. The topics in this chapter are organized as follows: • “Factors Affecting GT Inverter Performance” on page 6–1 •...

  • Page 62: Other Factors

    Maintenance and Troubleshooting Important: circuits from overheating and possible damage in high heat conditions. For maximum output in hot climates, mount the GT Inverter in a shaded location with good air flow. Angle of the sun The angle of the sun in relation to the PV array surface—the array orientation—can dramatically affect the PV array output.

  • Page 63: Performing General Maintenance

    Performing General Maintenance Follow these simple routines to ensure many years of service and optimal performance of your solar energy system. 1. Keep the heat sink clear of dust and debris. WARNING: Shock and fire hazard Do not use a pressure washer to clean the GT Inverter, or use other cleaning methods that could allow water to enter the unit.

  • Page 64: Replacing The Ground Fault Protection Fuse

    Maintenance and Troubleshooting Replacing the Ground Fault Protection Fuse WARNING: Shock and fire hazard Fuses should only be replaced by qualified service personnel, such as a certified electrician or technician. For continued protection against risk of fire, replace only with same type and ratings of fuse.
  • Page 65 Ground Fault Protection Fuse (“-POS” models) Figure 6-1 Location of Fuse, Front Panel Cover Removed Figure 6-2 Display Front Panel Assembly 975-0320-01-01 Ground Fault Protection Fuse Replacing Parts 6–5...

  • Page 66: Replacing The Inverter

    Maintenance and Troubleshooting Replacing the Inverter If your GT Inverter requires servicing, you can replace it with another inverter, leaving the existing wiring box in place. This means that you do not have to disturb wiring connections in the wiring/disconnect box. However, you do have to disconnect wiring between the inverter and the wiring/disconnect box.
  • Page 67 3. Using an insulated screwdriver, disconnect the PV NEGATIVE (–) wire from the terminal block inside the inverter. Cap the wire immediately with a wire nut. 4. Disconnect the remaining AC, DC and network cables between the inverter and the wiring box, inside the inverter. Cap all disconnected AC and DC wires with wire nuts.
  • Page 68 Maintenance and Troubleshooting Figure 6-4 Inverter and Wiring/Disconnect Box Sections To replace the inverter on the wiring box: 1. If it has not already been removed, remove the display front panel cover on the inverter. 2. Mount the inverter on the upper mounting bracket above the wiring/disconnect box, ensuring that the inverter’s lower flange goes behind the wiring/disconnect box.

  • Page 69: Identifying Error/Fault Conditions And Solutions

    Identifying Error/Fault Conditions and Solutions Most error or fault conditions will be identified by fault message screens on the GT Inverter front panel LCD. These are described in the “Fault Mode” section on page 5–8 of this manual. Most of these fault conditions are self-correcting and require no user action to remedy.
  • Page 70 6–10...

  • Page 71: Specifications

    Appendix A contains information about the specifications of the Xantrex Grid Tie Solar Inverter. The topics in this appendix are organized as follows: • “Electrical Specifications” on page A–2 • “Output Power Versus Ambient Temperature” on page A–3 • “Efficiency” on page A–4 •...

  • Page 72: Electrical Specifications

    Specifications Electrical Specifications Input Input voltage, Maximum Power Point range Absolute maximum array open circuit voltage Maximum input current Maximum array short circuit current Reverse polarity protection Ground fault protection Output Maximum output power Nominal output voltage Operating range, utility voltage* Nominal output frequency Operating range, utility frequency* Startup current...

  • Page 73: Adjustable Voltage, Frequency And Reconnection Settings

    Adjustable Voltage, Frequency and Reconnection Settings Utility disconnect settings can be adjusted using the GTConfigLite software tool. Permission of the utility must be granted before adjusting any of these settings. For more information about installing and using GTConfigLite, see the GTConfigLite User’s Guide (p/n 976-0260-01-01), available on the software CD.

  • Page 74: Efficiency

    Specifications Efficiency Maximum efficiency CEC efficiency Night-time tare loss Figure A-2 Typical Efficiency Environmental Specifications Operating temperature range Storage temperature range Power derating Tolerable relative humidity limit User Display Type Size A–4 96.2% 95.5% GT5- Efficiency vs Output Power 98.00 97.00 96.00 95.00...

  • Page 75: Display Accuracy

    Display Accuracy Instantaneous Power Voltage Current System Lifetime energy Mechanical Specifications Outdoor enclosure Inverter dimensions (H × W × D) Shipping dimensions (H × W × D) Inverter weight Shipping weight Input and output terminals Disconnect switch Regulatory Approvals The GT Inverter has complete on-board over-current, over-temperature and anti-islanding protection, and meets U.S., Canadian and international safety operating standards and code requirements: •...
  • Page 76 A–6...

  • Page 77: Warranty And Return Information

    The dated dealer invoice or purchase receipt showing original equipment manufacturer (OEM) status, or • The dated invoice or purchase receipt showing the product exchanged under warranty 975-0320-01-01 This Limited Warranty is provided by Xantrex Technology Inc. ("Xantrex") In any warranty claim, dated proof of purchase must accompany the WA–1...
  • Page 78 Warranty and Return What does this warranty not cover? product or costs related to the removal, installation, or troubleshooting of the customer's electrical systems. This warranty does not apply to and Xantrex will not be responsible for any defect in or damage to: a) the product if it has been misused, neglected, improperly installed, physically damaged or altered, either inter- nally or externally, or damaged from improper use or use in an unsuitable environment;...

  • Page 79: Return Material Authorization Policy

    Include the following: • The RMA number supplied by Xantrex Technology Inc. clearly marked on the outside of the box. • A return address where the unit can be shipped. Post office boxes are not acceptable.

  • Page 80: Information About Your System

    Warranty and Return Information About Your System As soon as you open your Xantrex Grid Tie Solar Inverter package, record the following information and be sure to keep your proof of purchase. Product Number 864-0118 Your Model Number ___________________________________________________ Serial Number ___________________________________________________ Purchased From ___________________________________________________...

  • Page 81: Index

    Index abbreviations and acronyms 3–4 AC circuit breaker requirements 3–1 AC grounding requirements A–2 AC output voltage ratings 3–10 AC wiring instructions A–5 acceptable wire sizes 3–5 accessing AC and DC terminals adjusting utility disconnect settings 4–2 checking AC utility voltage 4–2 checking PV array DC voltage communication between multiple inverters...
  • Page 82 Index 2–1 configuration 5–5 messages in normal operation 5–6 messages in offline mode operation 6–1 factors affecting performance 4–3 inverter startup 5–2 messages at startup 4–2 reassembling the unit 4–1 startup procedure parallel configuration communication between inverters 3–15 communications wiring A–4 power derating WA–4...
  • Page 84 Xantrex Technology Inc. 1 800 670 0707 Tel toll free NA 1 360 925 5097 Tel direct 1 360 925 5143 Fax direct customerservice@xantrex.com www.xantrex.com 975-0320-01-01 Printed in China...
