Owner's Guide
FreedomX1000120VAC12VDC  8 17-1000
Freedom X Inverter
FreedomX2000120VAC12VDC  8 17-2000
FreedomX3000120VAC12VDC  8 17-3000
FreedomX2000120VAC24VDC  8 17-2000-21

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Freedom X 1000 120VAC 12VDC and is the answer not in the manual?

Questions and answers

Brad Churchill
April 8, 2025

What adjustment do I need to make after my AGM battery installation? XANTREX 1200 92612008701277

1 comments:
Mr. Anderson
April 9, 2025

After installing an AGM battery with the Xantrex Freedom X 1000 120VAC 12VDC, you need to configure the inverter settings to match the AGM battery type.

This answer is automatically generated

Summary of Contents for Xantrex Freedom X 1000 120VAC 12VDC

  • Page 1 Owner’s Guide FreedomX1000120VAC12VDC  8 17-1000 Freedom X Inverter FreedomX2000120VAC12VDC  8 17-2000 FreedomX3000120VAC12VDC  8 17-3000 FreedomX2000120VAC24VDC  8 17-2000-21...
  • Page 2 Copyright © 2019 Xantrex LLC. All Rights Reserved. All trademarks are owned by Xantrex LLC and its affiliates. Exclusion for Documentation UNLESS SPECIFICALLY AGREED TO IN WRITING, SELLER (A) MAKES NO WARRANTY AS TO THE ACCURACY, SUFFICIENCY OR SUITABILITY OF ANY TECHNICAL OR OTHER INFORMATION PROVIDED IN ITS MANUALS OR OTHER DOCUMENTATION;...
  • Page 3 Information About Your System As soon as you open your product, record the following information and be sure to keep your proof of purchase. Serial Number ____________________________ Product Number ____________________________ Purchased From ____________________________ Purchase Date ____________________________ To view, download, or print the latest revision, visit the website shown under Contact Information. 975-0787-01-01...
  • Page 4 Analyzing and reducing the hazards involved in performing Volts DC electrical work. Watts Selecting and using Personal Protective Equipment (PPE). Abbreviations and Acronyms Related Information You can find more information about Xantrex products and Amps services at http://www.xantrex.com/. Freedom X Owner's Guide...
  • Page 5: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS ’ READ AND SAVE THIS WNER UIDE FOR FUTURE DANGER REFERENCE DANGER indicates a hazardous situation which, if not avoided, will result in This guide contains important safety instructions for the Freedom death or serious injury. X that must be followed during installation, operation, maintenance, and troubleshooting.
  • Page 6: Product Safety Information

    Product Safety Information Turning the inverter to Standby mode using the Power button Product Safety Information on the front panel will not reduce an electrical shock hazard. 1. Before using the inverter, read all instructions and cautionary 8. The inverter must be provided with an equipment-grounding markings on the unit, the batteries, and all appropriate conductor connected to the AC input ground.
  • Page 7 Product Safety Information DANGER DANGER ELECTRICAL SHOCK AND FIRE HAZARD HAZARD OF ELECTRIC SHOCK, EXPLOSION, BURN, OR ARC FLASH Installation must be done by qualified personnel to ensure Apply appropriate personal protective equipment (PPE) and compliance with all applicable installation and electrical codes and follow safe electrical work practices.
  • Page 8 Product Safety Information WARNING CAUTION ELECTRICAL SHOCK HAZARD ELECTRICAL SHOCK AND FIRE HAZARD Replace the wiring compartment cover before turning on Do not open. No serviceable parts inside. Provided with power to this equipment. integral protection against overloads. Bonding between Use a torque screwdriver to tighten the captive nut panel conduit connections is not automatic and must be provided screw to 5 in-lb torque to ensure a proper ground connection...
  • Page 9 Product Safety Information NOTES: CAUTION Follow these instructions and those published by the battery manufacturer and the manufacturer of any equipment you intend to use in the vicinity of the battery. Review cautionary PHYSICAL INJURY HAZARD markings on these products and on the engine. This Freedom X Inverter is not intended for use by persons Freedom X Inverter products are designed for deep cycle (including children) with reduced physical, sensory, or mental...
  • Page 10: Precautions When Working With Batteries

    Precautions When Working With Batteries Precautions When Working With NOTES: 1. Mount and place the Freedom X Inverter unit away from Batteries batteries in a well ventilated compartment. 2. Always have someone within range of your voice or close IMPORTANT: Battery work and maintenance must be done by enough to come to your aid when you work near a lead-acid qualified personnel knowledgeable about batteries to ensure battery.
  • Page 11: Precautions When Placing The Inverter

    Precautions When Placing the inverter Precautions When Placing the NOTICE Inverter RISK OF INVERTER DAMAGE Never allow battery acid to drip on the inverter when reading WARNING gravity, or filling battery. Never place the Freedom X unit directly above batteries; FIRE HAZARD gases from a battery will corrode and damage the inverter.
  • Page 12: Fcc Information To The User

    Reorient or relocate the receiving antenna. up in the landfill. Increase the separation between the equipment and For more information on disposal, contact Xantrex. receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
  • Page 13: Table Of Contents

    CONTENTS Important Safety Instructions Features Product Safety Information Default Settings Precautions When Working With Batteries AC/DC and GFCI Panel Precautions When Placing the inverter Display Panel Regulatory Side Panel Installation FCC Information to the User End of Life Disposal Before You Begin the Installation Contents xiii Installation Codes...
  • Page 14 Marine Installation Transitioning from Grid Mode to Battery Mode Drip Shield Installation Transitioning from Battery Mode to Grid Mode Operation Operating Limits Freedom X Display Panel Power Output Status LED Indicators Input Voltage Function Buttons Overload Conditions LCD Screen High Surge Loads LCD Screen Icons Over-temperature Conditions Viewing Information During Battery Mode...
  • Page 15: Introduction

    INTRODUCTION The Freedom X Inverter is designed with integrated inverting functions and power management features suitable for marine, recreational, and commercial/fleet vehicle installations. Please read this section to familiarize yourself with the main performance and protection features of the Freedom X. This section includes: Materials List Key Features...
  • Page 16: Materials List

    Figure 1 What’s In The Box independent power source that supplies utility grade AC power to NOTE: If any of the items are missing, contact Xantrex or any your loads. authorized Xantrex dealer for replacement. See Contact Information on page ii.
  • Page 17: Configurable Ac Transfer Speed

    Materials List Comprehensive Protection Overload Alarm and Shutdown The Freedom X’s built-in protection features safeguard your During Battery Mode (also called Inverter Mode), the Freedom X batteries (from unnecessary drain) such as the low battery voltage automatically alerts you if the loads that are connected and alarm and shutdown and protect equipment such as a configurable drawing power from the unit are close to approaching the AC transfer speed.
  • Page 18: Configurable Ac Output Frequency And Voltage

    Materials List Configurable AC Output Frequency and Voltage The Freedom X is factory set to 60 Hz AC output frequency and 120 V AC output voltage. It can be configured to 50 Hz for use in regions outside the USA and Canada. The AC voltage setting can also be configured to either of three settings: 108, 110, or 120 volts.
  • Page 19: Features

    FEATURES This section identifies the default settings and the hardware features of the Freedom X Inverter. This section includes: Default Settings AC/DC and GFCI Panel Display Panel Side Panel 975-0787-01-01...
  • Page 20: Default Settings

    Default Settings Default Settings Table 1 lists the default settings for the Freedom X system. You may record your settings in the right-hand column after you have configured the Freedom X. Table 1 Freedom X Default Values Program Item Default Setting Setting Inverter ignition control Low battery cutoff (LBCO) voltage (12VDC...
  • Page 21 Default Settings Program Item Default Setting Setting Inverter power limit Freedom X 1000 120VAC 12VDC 1 kW Freedom X 2000 120VAC 12VDC/24VDC 2 kW Freedom X 3000 120VAC 12VDC 3 kW 300 seconds 300 Inverter power limit timer Transfer mode Appliance...
  • Page 22: Ac/Dc And Gfci Panel

    AC/DC and GFCI Panel AC/DC and GFCI Panel WARNING ELECTRICAL SHOCK HAZARD Use a torque screwdriver to tighten the captive nut panel screw to 5 in-lb torque of force to ensure a proper ground connection and a required tool access to the wiring compartment. Failure to follow these instructions can result in death, serious injury, or equipment damage.
  • Page 23 AC/DC and GFCI Panel Feature Description Feature Description Grounding lug provides a ground path for the Ventilation grille (openings) must not be obstructed Freedom X chassis to the DC system ground. See for the proper operation of the cooling fan and WARNING.
  • Page 24: Display Panel

    Display Panel Display Panel Table 3 Display Panel Features Feature Description Display panel displays status information on the screen. It is comprised of a display screen, LEDs, select and power buttons. Multi-function LCD screen shows status information and error codes. INPUTBATTTEMP OUTPUTBATTLOAD ERROR Status LEDs indicate the mode of operation.
  • Page 25: Side Panel

    Side Panel Side Panel Table 4 Side Panel Features Feature Description Captive nut panel screw holds the wiring compartment cover in place. See WARNING above. Wiring compartment cover protects the wiring compartment from debris and keeps the cables secure. Using the captive nut panel screw, the cover can be opened and lifted out during wiring.
  • Page 26 This page is intentionally left blank.
  • Page 27: Installation

    INSTALLATION Please read this section for safety information and installation instructions regarding your Freedom X. This section includes: Before You Begin the Installation Installation Codes Installation Tools and Materials Basic Installation Procedures Step 1: Designing the Installation Step 2: Choosing a Location for the Unit Step 3: Mounting the Unit Step 4: Connecting the AC Input Wires Step 5: Connecting AC Output to an Existing AC Circuit...
  • Page 28: Before You Begin The Installation

    Before You Begin the Installation Before You Begin the WARNING Installation ELECTRICAL SHOCK AND FIRE HAZARD Before beginning your installation: All wiring should be done by qualified personnel to ensure Read this entire Installation section so you can plan the compliance with all applicable installation codes and installation from beginning to end.
  • Page 29: Installation Codes

    Installation Codes Installation Codes Installation Tools and Materials Governing installation codes vary depending on the specific You will need the following to install the Freedom X: location and application of the installation. Some examples Wire stripper include the following: Mounting (#2) screws or bolts The U.S.
  • Page 30: Basic Installation Procedures

    Basic Installation Procedures Basic Installation Procedures This section provides sample installation information as a guide for your installation. For your convenience, the overall procedure is divided into these main steps: Step 1: Designing the Installation Step 2: Choosing a Location for the Unit Step 3: Mounting the Unit Step 4: Connecting the AC Input Wires Step 5: Connecting AC Output to an Existing AC Circuit 31...
  • Page 31: Step 1: Designing The Installation

    Basic Installation Procedures Figure 5 Typical Recreational Vehicle and Fleet Vehicle Step 1: Designing the Installation Installation Most Freedom X installations share common components, and some of these are briefly described in Step 1: Designing the Installation. Figure 5 shows some components and their relationship to each other in a typical recreational vehicle or fleet vehicle installation.
  • Page 32 Basic Installation Procedures AC Shore Power AC Input The circuit breaker or fuse (connected through hard wiring) that is used to supply the Freedom X A source of 120 volts AC 60Hz sine wave alternating current must be rated at no more than 30A and must be provides energy to pass power through to AC loads.
  • Page 33 Basic Installation Procedures AC Distribution Panels Disconnect Each system requires a method of disconnecting the AC circuits. If the over- Devices Most systems incorporate distribution centers both ahead of the current protection devices are circuit breakers, Freedom X (the AC source panel) and between the Freedom X they will also serve as the disconnects.
  • Page 34 Basic Installation Procedures solid or stranded, overall size of the conductors, and type and AC Output Neutral Bonding temperature rating of the insulation around the wire. The neutral conductor of the Freedom X’s AC output circuit (that AC breakers and fuses must be sized to adequately protect the is, AC Output Neutral) is automatically connected to the safety wiring that is installed on the input and output AC circuits of the ground during inverter operation.
  • Page 35 Basic Installation Procedures DC Cabling Table 6 Required Cable Sizes This includes all the cables and connectors between the batteries, Cable Length: Minimum Maximum the DC disconnect and over-current protection device, and the Inverter Battery to Inverter Cable battery Freedom X. Most mobile installations require multi-strand (one way) Size Fuse Size...
  • Page 36 Basic Installation Procedures small the voltage drop from this surge will result in a voltage at the Ground Fault Circuit Interrupters (GFCIs) Freedom X terminals that is too low for the Freedom X to operate A GFCI is a device that de-energizes a circuit when a current to correctly.
  • Page 37: Step 2: Choosing A Location For The Unit

    Basic Installation Procedures Ventilated. Allow at least 5 inches of clearance at the fan Step 2: Choosing a Location for the end of the Freedom X for air flow, 1 inch on each side, and 2 Unit inches at the wiring access (AC and DC) end. The more clearance for ventilation around the unit, the better the performance.
  • Page 38: Step 3: Mounting The Unit

    Basic Installation Procedures Figure 6 Approved Mounting Orientations Step 3: Mounting the Unit To mount the Freedom X: 1. Remove the Freedom X from its shipping container, verify that all components are present, and record relevant product information on “Information About Your System” in the Owner’s Guide.
  • Page 39 Basic Installation Procedures Connecting the Equipment Ground Grounding Locations You must connect the equipment ground lug to a grounding point—usually the vehicle’s chassis or DC negative bus ground— WARNING using recommended copper wire (if insulated then green insulation with or without one or more yellow stripes) or larger. ELECTRIC SHOCK HAZARD Make sure to tighten the bolt on the DC ground lug to a torque of Never operate the Freedom X without properly connecting the...
  • Page 40: Step 4: Connecting The Ac Input Wires

    Basic Installation Procedures For recommended equipment ground cable size, see below. Step 4: Connecting the AC Input Wires Table 7 Equipment DC ground cable size WARNING Minimum equipment ground cable Application size (Stranded copper cable is ELECTRIC SHOCK AND FIRE HAZARDS required) Make sure wiring is disconnected from all electrical sources before handling.
  • Page 41 Basic Installation Procedures AC Wiring and GFCIs Table 8 Required AC wire size vs. required breaker rating You can plug loads of up to 20 amps directly into the GFCI Required Breaker Required Wire receptacle on the front panel of the Freedom X. If installed, you Size (amps) Size can also connect the inverter to an existing AC installation and...
  • Page 42 Basic Installation Procedures Make sure to seal the open ½" trade-size holes with the supplied Table 9 Color codes for typical AC wiring knockout plugs by placing the plugs and firmly pressing them into Color AC Wire the holes. Black/Red/Brown Line NOTICE White/light blue Neutral...
  • Page 43 Basic Installation Procedures Figure 8 Loosening the captive nut panel screw Figure 9 Routing the wires Captive nut panel screw 4. Strip a single AC input wire, as appropriate. Strip 10 mm off the ends of each of the three the wires (tin the exposed copper wire with lead-free solder using a soldering iron).
  • Page 44 Basic Installation Procedures 8. Connect each AC wire into its corresponding terminal on the no-tool cage clamp terminal block. WARNING a. Lift the terminal lever (as shown in the previous figure). ELECTRICAL SHOCK HAZARD b. Insert the wire fully into the open slot. c.
  • Page 45: Step 5: Connecting Ac Output To An Existing Ac Circuit

    Basic Installation Procedures Step 5: Connecting AC Output to an NOTICE Existing AC Circuit EQUIPMENT DAMAGE Do not connect any AC source (such as a generator or WARNING utility power) to the AC output wiring of the Freedom X. The Freedom X will not operate if its output is connected to ELECTRIC SHOCK AND FIRE HAZARDS AC voltage from another source, and potentially hazardous or damaging conditions may occur.
  • Page 46 Basic Installation Procedures 2. Install the required circuit breaker in the inverter distribution AC Output Connections panel receiving AC power from the inverter. Figure 10 Routing the wires 3. Remove the wiring compartment cover, if not already done from AC Output Connections on page 32. WARNING ELECTRIC SHOCK HAZARD Use a screwdriver to loosen the captive nut panel screw.
  • Page 47: Step 6: Connecting The Dc Cables

    Basic Installation Procedures the Neutral (N), Ground (G), and Line (L) connections. Step 6: Connecting the DC Cables NOTICE REVERSE POLARITY Check cable polarity at both the battery and the Freedom X before making the final DC connection. Positive must be connected to positive;...
  • Page 48 Basic Installation Procedures possible and large enough to handle the required current, in To make the DC connections: accordance with the electrical codes or regulations applicable to 1. Make sure the inverter is off and no AC or DC is connected to the unit.
  • Page 49 Basic Installation Procedures 6. Strip ½" (13 mm) to ¾" (19 mm) of insulation from each cable end that will be connected to the inverter cable. The WARNING amount stripped off will depend on the terminals chosen. 7. Attach the cable ring lug that will join the cable to the inverter ELECTRICAL SHOCK HAZARD DC terminal.
  • Page 50 Basic Installation Procedures Figure 12 DC Cable Connections WARNING FIRE HAZARD Do not complete the next step if flammable fumes are present. Explosion or fire may result if the disconnect/battery selector switch is not in the off position. Thoroughly ventilate the battery compartment before making this connection.
  • Page 51 Basic Installation Procedures Recreational Vehicle WARNING Use 8AWG minimum-sized, stranded copper wire and connect it between the Chassis Ground lug and the vehicle’s DC grounding ELECTRICAL SHOCK HAZARD point (usually the vehicle chassis or a dedicated DC ground bus). Use a torque screwdriver to tighten the captive nut panel screw to See regulatory references below.
  • Page 52 Basic Installation Procedures 7. Pull the screwdriver out to engage the spring clamp and Connecting to ACC Signal secure the wire to the terminal. To enable ignition control: Description of Ignition Control Features 1. Ensure that AC and DC power are both OFF. For information about the features and instructions on changing 2.
  • Page 53: Step 7: Connecting To Port(S) On The Freedom

    Basic Installation Procedures Step 7: Connecting to Port(s) on the Step 8: Testing Your Installation Freedom X WARNING Connecting to the Remote Port ELECTRIC SHOCK HAZARD The Freedom X can accommodate the Freedom X Remote Panel Pressing the Power button to turn the Freedom X inverter to with cable (PN: 808-0817-01) (sold separately;...
  • Page 54 Basic Installation Procedures Testing in Battery Mode If the Power button on the Freedom X is turned ON and shore power voltage is too low (less than 90 volts AC), the unit will To test the Freedom X: transfer to inverter power to continue running your appliances. 1.
  • Page 55: Marine Installation

    Marine Installation Marine Installation Figure 14 Typical Marine Installation Figure 14 illustrates a typical marine installation with the following components: 20-pin harness accessory Not applicable for this product. Equipment ground – Engine negative bus / DC ground bus Freedom X DC fuse/disconnect/DC circuit breaker 12V/24V (as applicable) deep cycle battery bank and protected by a DC fuse in the positive cable...
  • Page 56: Drip Shield Installation

    Marine Installation Drip Shield Installation Figure 15 Drip shields To install the drip shields: The drip shields help to protect the unit from dripping or splashing 1. Gather the four screws needed liquids, which will cause a shock hazard when moisture comes in to fasten a single drip shield to a contact with electrical circuits in the unit.
  • Page 57: Operation

    OPERATION This section includes descriptions of the different modes and Operating Several Loads at Once settings of the Freedom X Inverter. Turning the Audible Alarm ON or OFF This section includes: Operating During Transition Between Grid Mode and Freedom X Display Panel Battery Mode Status LED Indicators Transitioning from Grid Mode to Battery Mode...
  • Page 58: Freedom X Display Panel

    Freedom X Display Panel Freedom X Display Panel Status LED Indicators Figure 17 Display Panel Indicator Definition Solid green. Indicates grid mode in which shore power is available and passing INPUTBATTTEMP OUTPUTBATTLOAD    through to the loads. ERROR BYPASS OVERLOAD 100% Solid green.
  • Page 59: Function Buttons

    Freedom X Display Panel Function Buttons LCD Screen The LCD Screen changes depending on the operating mode of the Button Definition inverter. Figure 18 Parts of the LCD Screen Return to default screen or exit setting mode Next screen or next selection Press and hold for three seconds to go back one step INPUTBATTTEMP...
  • Page 60: Lcd Screen Icons

    Freedom X Display Panel LCD Screen Icons Icon Definition Icon Definition The load icon is displayed if there is voltage available at the AC output. AC input and output indicator. The bar represents load consumption The wrench icon underneath a number is levels.
  • Page 61: Viewing Information During Battery Mode

    Viewing Information During Battery Mode Viewing Information During Info and Setting LCD Screen Battery Mode The LCD screen displays information related to battery mode operation. Screen 2 of 4 - Press the Scroll button to move from screen to screen. AC Output Press and hold for three seconds to go back one step.
  • Page 62 Viewing Information During Battery Mode Info and Setting LCD Screen Screen 4 of 4 - Firmware version Firmware version = U1 1.01 Freedom X Owner's Guide...
  • Page 63: Viewing Information During Grid Mode

    Viewing Information During Grid Mode Viewing Information During Grid Info and LCD Screen Mode Setting 1. The LCD screen displays information related to AC bypass operation. 2. Press the Scroll button to move from screen to screen. Screen 2 of 4 - Press and hold for three seconds to go back one step.
  • Page 64 Viewing Information During Grid Mode Info and LCD Screen Setting Screen 4 of 4 - Firmware version Firmware version = U1 1.01 Freedom X Owner's Guide...
  • Page 65: Adjusting Feature Settings In Configuration Mode

    Adjusting Feature Settings in Configuration Mode Adjusting Feature Settings in To change the default value to a different value: 1. Press and hold the button for three seconds to enter the Configuration Mode feature settings mode. 2. Press the Scroll button to move through the different , Scroll , and...
  • Page 66: Settings

    Adjusting Feature Settings in Configuration Mode Settings Setting Default Range of Setting Name Description Number Value Values Inverter Ignition Control See Description of Ignition Control Features on page 38. LBCO Voltage (12VDC 10.5 10.0 to 12.8 The voltage setting value can be adjusted by 0.1 increments. The models) inverter is able to recover automatically at LBCO voltage + LBCO Voltage (24VDC...
  • Page 67 Adjusting Feature Settings in Configuration Mode Setting Default Range of Setting Name Description Number Value Values The range is from LBCO voltage + 0.2 to 16, adjusted by 0.1 increments. Selecting OFF or a higher value than the battery’s LBCO Recovery Voltage 10.2 to 16.0 13.1 actual fully-charged voltage level will disable the auto-recovery...
  • Page 68 Adjusting Feature Settings in Configuration Mode Setting Default Range of Setting Name Description Number Value Values Inverter Output Power 0.1 to 1.0 Limit (Freedom X 1000 120VAC 12VDC) Inverter Output Power The wattage setting value can be adjusted by 100-watt Limit (Freedom X 2000 increments.
  • Page 69 Adjusting Feature Settings in Configuration Mode Setting Default Range of Setting Name Description Number Value Values Selecting APL- appliance sets the transfer time from line to battery to 20 ms. Selecting UPS (uninterruptible power supply) sets the APL(appliance) Transfer Mode transfer time from line to battery to 10 ms. NOTE: Do not connect UPS (UPS) motor loads when in UPS transfer mode.
  • Page 70: Operating In Battery Mode

    Operating in Battery Mode Operating in Battery Mode Turning Inverter Operation ON and OFF There are two ways to operate the Freedom X’s inverter. The Freedom X is in Battery Mode (also called Inverter Mode) 1. Press the Power button to a down position (it is in Standby when all the following conditions exist: mode in the up position).
  • Page 71: Power Save Timer

    Operating in Battery Mode Power Save Timer Power Save Mode The Power Save Timer is an adjustable countdown timer from 1 to By enabling the power save mode, the inverter can automatically 25 hours (25 hours is the default) that automatically shuts down go to load sense mode by sending short pulses to further reduce inverter operation to reduce battery discharge and preserve the battery discharge.
  • Page 72: Checking Battery Status

    Operating in Battery Mode Any warnings such as error or fault conditions or imminent Checking Battery Status shutdown are both displayed on the LCD screen and sounded on During inverter operation (in battery mode), you can check the the alarm speakers. See To manually reset the alarm: on page 58. battery status by observing the battery capacity indicator on the Audible alarm for warning: The unit beeps once when a warning LCD screen.
  • Page 73: Operating During Transition Between Grid Mode And Battery Mode

    Operating During Transition Between Grid Mode and Battery Mode Operating During Transition Transitioning from Grid Mode to Battery Mode Between Grid Mode and Battery When the unit is operating in grid mode and shore power is lost, Mode the Freedom X has less than 20 milliseconds (default) to switch to The Freedom X’s advanced power management is capable of operating in battery mode (if the Power button is pressed in the On transitioning power from an AC source to DC source within a...
  • Page 74: Transitioning From Battery Mode To Grid Mode

    Operating During Transition Between Grid Mode and Battery Mode Transitioning from Battery Mode to Grid Mode When the unit is operating in Battery Mode and shore power becomes available, the Freedom X begins a 20-second countdown to verify the stability of the shore power. If shore power remains stable for a 20-second countdown, at the end of the countdown, the Freedom X will switch to shore power mode within 20 milliseconds and start drawing power from the AC...
  • Page 75: Operating Limits

    Operating Limits Power Output The Freedom X can deliver up to: These are the operating limits of the Freedom X: 1000 watts (Freedom X 1000 120VAC 12VDC) or Power Output 2000 watts (Freedom X 2000 120VAC 12VDC or 24VDC as Input Voltage...
  • Page 76: Input Voltage

    Operating Limits Input Voltage Operating Battery Comment The allowable Freedom X input battery voltage ranges are shown Condition Voltage in the following table: The buzzer sounds a single one- Table 11 Input battery voltage range second low battery alarm beep and the LCD screen shows error Operating Battery Comment...
  • Page 77: Overload Conditions

    Overload When the Freedom X’s AC load increases to near Voltage 32.0 volts Shutdown ~1100 W (Freedom X 1000 120VAC 12VDC) ~2100 W Shutdown NOTE: Although the Freedom X (24VDC (Freedom X 2000 120VAC 12VDC or 24VDC as incorporates over-voltage model) applicable) and ~3100 W (Freedom X 3000 120VAC...
  • Page 78: Over-Temperature Conditions

    Operating Limits Over-temperature Conditions During inverter operation, when the Freedom X’s internal temperature starts to approach its preset shutdown limit, the display will show error code E07. If the over-temperature condition persists, the display will show error code E04. The Status LED turns solid RED and the inverter will shut down to prevent damage to the inverter and protect the battery from being over-discharged.
  • Page 79: Routine Maintenance

    5 ROUTINE MAINTENANCE Regular maintenance is required to keep your Freedom X operating properly. This section includes: Freedom X Unit 975-0787-01-01...
  • Page 80: Freedom X Unit

    Freedom X Unit Freedom X Unit WARNING ELECTRICAL SHOCK HAZARD Turning the Power button to Standby mode does not disconnect DC battery power from the Freedom X. You must disconnect from all power sources before working on any circuits connected to the unit. Failure to follow these instructions can result in death, serious injury, or equipment damage.
  • Page 81: Troubleshooting

    TROUBLESHOOTING This section will help you narrow down the source of any problem you encounter. Before contacting customer service, please work through the steps listed in Pre-service Checklist on page 68. This section includes: Pre-service Checklist Warning Messages Troubleshooting Reference 975-0787-01-01...
  • Page 82: Pre-Service Checklist

    Pre-service Checklist Whether any extreme ambient conditions existed at Pre-service Checklist the time (temperature, vibrations, moisture, etc.) 3. If your Freedom X is not displaying an error code, check the following to make sure the present state of the installation WARNING allows proper operation: Is the inverter located in a clean, dry, adequately...
  • Page 83: Warning Messages

    Warning Messages Warning Messages Warning messages in the form of audible alarms and error codes that appear on the LCD screen to alert you to an impending system change. Warnings do not affect operation. With the exception of the error codes displayed on the screen, only the audible alarm can be turned ON or OFF.
  • Page 84 Warning Messages Table 12 Error codes displayed on the LCD screen Error Code Condition Mode Action Low battery voltage Check battery status and recharge if necessary. shutdown is imminent Battery mode depending on the setting, Check for proper DC cable sizing. (inverting) see Freedom X Unit on Check for loose connections and tighten if necessary.
  • Page 85 Warning Messages Error Code Condition Mode Action Reduce the loads connected to the AC outlet of the unit. Check that the ventilation grille is not blocked. Over-temperature alarm Battery mode Check for ambient temperature and move the unit to a cooler and fan lock alarm (inverting) location whenever possible.
  • Page 86: Troubleshooting Reference

    Troubleshooting Reference Troubleshooting Reference WARNING ELECTRICAL SHOCK HAZARD Do not disassemble the Freedom X. It does not contain any user- serviceable parts. Attempting to service the unit yourself could result in an electrical shock or burn. Failure to follow these instructions can result in death, serious injury, or equipment damage.
  • Page 87 Troubleshooting Reference Table 13 Troubleshooting reference Problem Possible Cause Solution Alarm does not sound when an error is Alarm is turned OFF. See Freedom X Unit on page 66 and follow instructions encountered. to turn the alarm buzzer on again. No output voltage. The status LED is AC shore power is not available or out of operating range and the inverter has shut down red.
  • Page 88 Troubleshooting Reference Problem Possible Cause Solution No output voltage is shown in the LCD GFCI (when installed) has tripped Check load and reset the GFCI or supplementary screen but the green status LED for or supplementary breaker has breaker. Battery mode is illuminated. tripped.
  • Page 89 Troubleshooting Reference Problem Possible Cause Solution The fan turns on and off during AC The battery is discharged. Do not be alarmed, the unit is performing normally. shore power mode. AC pass-through current is high. The fan turns on and off during inverter The inverter is running Do not be alarmed, the unit is performing normally.
  • Page 90: Inverter Applications

    Inverter Applications Inverter Applications Motor Loads Induction motors (that is, motors without brushes) require two to The Freedom X performs differently depending on the AC loads six times their running current on start up. The most demanding connected to it. If you are having problems with any of your loads, are those that start under load, for example, compressors and read this section.
  • Page 91: Specifications

    SPECIFICATIONS This section summarizes the hardware and electrical specifications of the Freedom X Inverter. This section includes: Physical Specifications Environmental Specifications System Specifications Regulatory Approvals NOTE: Specifications are subject to change without prior notice. 975-0787-01-01...
  • Page 92: Physical Specifications

    Physical Specifications Physical Specifications Table 14 Physical specifications Freedom X 1000 120VAC Freedom X 2000 (Both 12 & Freedom X 3000 120VAC 12VDC 24VDC models) 12VDC 13.4” × 9.1” × 3.7” 14.6” × 10.8” × 3.9” 15.4” × 10.8” × 4.0” (340mm ×...
  • Page 93: Environmental Specifications

    Environmental Specifications Environmental Specifications Table 16 Environmental specifications Freedom X 1000 120VAC Freedom X 2000 (Both 12 & Freedom X 3000 120VAC 12VDC 24VDC models) 12VDC Ambient Temperature:    Operating Temperature Range -4 –140 ºF (-20 –60 ºC), with output derated above 104 ºF (40 °C)    Storage Temperature Range -40 –158 ºF (-40 –70 ºC) Humidity: Operation/Storage...
  • Page 94: System Specifications

    System Specifications System Specifications Table 17 System specifications Freedom X 2000 (Both 12 & Freedom X 1000 120VAC 12VDC Freedom X 3000 120VAC 12VDC 24VDC models) Transfer relay rating (A Transfer time (milliseconds    Shore to inverter: <20 milliseconds <20 milliseconds <20 milliseconds    Inverter to shore: <20 milliseconds with a 20-...
  • Page 95 System Specifications Table 18 DC input for inverting Freedom X 1000 120VAC Freedom X 2000 (Both 12 & Freedom X 3000 120VAC 12VDC 24VDC models) 12VDC Operating voltage range LBCO voltage –18.0 VDC LBCO voltage –18.0 VDC LBCO voltage –18.0 VDC 25.2 VDC (12VDC models) Maximum non-operating voltage 24 VDC...
  • Page 96 System Specifications Table 19 AC output for inverting Freedom X 1000 120VAC Freedom X 2000 (Both 12 & Freedom X 3000 120VAC 12VDC 24VDC models) 12VDC Output voltage options 120, 110, 108 VAC 120, 110, 108 VAC 120, 110, 108 VAC Continuous power (W 1000 W @ 40 °C 2000 W @ 40 °C...
  • Page 97: Regulatory Approvals

    Regulatory Approvals Regulatory Approvals Table 20 Regulatory approvals Freedom X 2000 (Both 12 & Freedom X 1000 120VAC 12VDC Freedom X 3000 120VAC 12VDC 24VDC models) ETL-listed complies to CSA 107.1 ETL-listed complies to CSA 107.1 ETL-listed complies to CSA 107.1...
  • Page 98 (Toll Free USA/Canada) +1 800 670 0707 (Outside USA/Canada) +1 408 987 6030 Printed in: 975-0787-01-01 Rev F...
