BA488CF-F
FOUNDATION™ fieldbus
Intrinsically safe
Panel mounting display
issue 12
Issue: 12
th
6
June 2011

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FOUNDATION BA488CF-F and is the answer not in the manual?

Questions and answers

Summary of Contents for BEKA FOUNDATION BA488CF-F

  • Page 1 BA488CF-F FOUNDATION™ fieldbus Intrinsically safe Panel mounting display issue 12 Issue: 12 June 2011...
  • Page 2: Table Of Contents

    CONTENTS 1. Description 6. Display & Alarm Configuration 1.1 Documentation 6.1 Default configuration 1.2 Version 2.3 firmware 6.2 Accessing the display configuration menus 6.3 Configurable functions 2. Operation 6.3.1 Screens (Display format) 2.1 Controls 6.3.2 Input settings 6.3.3 Tags 6.3.4 Units 3.
  • Page 3: Description

    (2 x IS) Multiple bargraph limits added The required Device Description files, which may Input scaling added downloaded from either Fieldbus Foundation or the BEKA websites, depend upon Selectable function blocks added: which BA488CF-F FOUNDATION™ fieldbus display revision is selected. Revision 1...
  • Page 4: Operation

    FOUNDATION™ fieldbus display downloaded from either the Fieldbus Foundation or from the BEKA associates websites. Fig 1 Simplified block diagram of BA488CF-F 2.1 Controls The user can scroll through the display screens by operating the ▼ or ▲ push buttons. The number of screens available depends upon how the BA488CF-F display has been configured.
  • Page 5: Intrinsic Safety Certification

    The BA488CF-F FOUNDATION™ fieldbus display Some of the standards specified may have is powered and communicates via the fieldbus, subsequently been deharmonised, see BEKA which is connected to terminals 1 and 2. These Declaration of Conformity for current conformity terminals comply with the Fieldbus Intrinsically...
  • Page 6: Alarm Outputs

    It shows the 14.7V dc ATEX certification information, a statement that the 146.7mA dc instrument is a FISCO Field Device, plus BEKA 0.58W associates name and location. Non European certification information may also be included.
  • Page 7: Non Fisco Systems

    4.2 Non FISCO Systems BA488CF-F FOUNDATION™ fieldbus display is to be connected to a fieldbus segment that does not comply with FISCO requirements, the safety parameters of the power supply and the BA488CF-F must be compared using the entity concept. The maximum output safety parameters of the device powering the fieldbus segment must be equal to, or less than, the input safety parameters...
  • Page 8: Installation

    5. INSTALLATION 5.2 Installation Procedure 5.1 Location a. Insert the BA488CF-F into the instrument The BA488CF-F FOUNDATION™ fieldbus display panel cut-out from the front of the panel. is housed in a robust aluminium enclosure with a toughened glass window mounted in a Noryl bezel. b.
  • Page 9: Emc

    5.3 EMC The BA488CF-F complies with the requirements of the European EMC Directive 2004/108/EC. specified immunity all wiring should be in screened twisted pairs with the screens connected to the potential equalising network as recommended in EN 60079-14.
  • Page 10: Display & Alarm Configuration

    6. DISPLAY & ALARM CONFIGURATION Operating the P and E push buttons simultaneously addition loading BA488CF-F accesses the display configuration menu. If the FOUNDATION™ fieldbus display Device BA488CF-F is not protected by an access code the Description files onto the system host and defining main menu will be displayed.
  • Page 11: Configurable Functions

    6.3 Configurable functions One variable + horizontal bargraph This section provides an explanation of each configurable function and should be read in conjunction with Fig 7. 6.3.1 Screens (Display format) The BA488CF-F can display up to eight fieldbus Two variables + horizontal bargraphs variables.
  • Page 12: Tags

    bargraphs from eight to six. If a negative number is likely to be displayed, a Version 2.3 firmware includes the improved ‘Per digit must be allocated for the negative sign. If the Input’ option that enables the lower and upper display overanges all the digits will display ‘?’.
  • Page 13: Display

    There are eight alarm-conditioning sub-menus. 6.3.6 Display 6.3.6.1 Settings 6.3.5.1 Alarm summary The backlight brilliance and display contrast are Shows to which fieldbus variable each alarm is adjustable from this sub-menu. linked and how each alarm has been conditioned i.e. high, low, or combined high & low alarm with 6.3.6.2 Quick Access normally open or closed output.
  • Page 14: Unit Info

    6.3.8 Code To change the BA488CF-F FOUNDATION™ Defines the four digit alphanumeric code that must fieldbus display revision, highlight the required be entered to gain access to the instrument revision in the ‘Restore Defaults’ menu and follow configuration menus. Alpha characters are case the screen prompts until ‘Defaults Loaded Now sensitive.
  • Page 16: Programming

    BA488CF-F not have correct That the FOUNDATION™ fieldbus displays are returned to protocol BA488CF-F BEKA associates or to our local agent for repair. protocol is the same as the fieldbus. i.e. Fieldbus 8.4 Routine maintenance Foundation or The mechanical and electrical condition of the Profibus PA.
  • Page 17: Accessories

    9.2 FOUNDATION™ fieldbus Interface Guide The BEKA FOUNDATION™ fieldbus Interface Guide which may be downloaded from the BEKA web site at www.beka.co.uk contains conditioning information for all BEKA FOUNDATION™ fieldbus...
  • Page 18: Index

    10. INDEX Subject Section Subject Section Alarms 6.3.5 Notified Body 1; 3.1 Activation 6.3.5.2 Number Format 6.3.2 Output 3.5; 6.3.5.3; 4.4 Summary 6.3.5.1 Programming Guide 7; 9.2 ATEX Directive Profibus PA Backlight 6.3.6.1 Quick access menu 6.3.6.2; 6.4 Bargraph Limits 6.3.2 Revisions 1 &...
  • Page 19: Appendix 1

    Control Drawing CI480-18, which is identification 3022546. Copies of the Certificate of attached to this Appendix, and with the National Compliance are available from BEKA associates. Electrical Code ANSI/NFPA70. A1.1 Intrinsic safety approval The FM Nonincendive Approval also allows the...
  • Page 28: Appendix 2

    IECEx certification scheme and to view the BEKA associate certificates, please visit www.iecex.com A2.1 IECEx Certificate of Conformity The BA488CF-F Fieldbus Display has been issued with an IECEx Certificate of Conformity number IECEx ITS 05.0007 which specifies the following...
