LMU Controller
9. Run the harness cabling and the GPS and Cellular cabling to the intended LMU Controller location.
10. Connect the GPS and Cellular connectors to the LMU Controller.
11. Connect the 20 pin harness to the LMU Controller.
12. Tie off unused wires from harness.

LMU Controller LEDs

Operation Status

Once the 20 pin harness is connected to the LMU Controller, this will have power.
The LMU Controller is configured to provide vehicle tracking and live video streaming information to vMax Live Plus users.
LEDs on the LMU Controller indicate operation status and display operation mode conditions as described below.
LED Status Indicators
Comm LED - Orange
Off
Slow Blinking
Fast Blinking
Fast Blink to Solid
Solid
p. 9
Condition
Modem Off
Comm On - Searching
Network Available
Registered - no Inbound Acknowledgment
Registered - Inbound Acknowledgment
GPS LED - Green
Off
Slow Blinking
Fast Blinking
Solid
© Safe Fleet | March 2019 | All rights reserved | Part #: 700-1132 R3
LMU Controller LEDs
Condition
GPS Off
GPS On
GPS Time Sync
GPS Fix
