Run pre-loaded demo

Follow the sequence below (Function 0 to Function 3) to launch the demo application:
Function 1 is executed and each click on user button B1 changes the executed function
as shown in
Function
0
1
2
3
The following is the detailed procedure and description of each function.
Function 0:
Function 1:
Function 2:
Function 3:
Table 1.
Table 1. STM32F072B-DISCO functions and LEDs
LED
LD3/4/5/6
Four LEDs LD3, LD4, LD5,LD6 are blinking
blinking
LD3/4/5/6
The four LEDs will indicate the board movement.
ON or OFF
Connect a second USB type A to Micro-B cable
LD3/6
between CN2 and the PC, then observe the mouse
blinking
cursor moving according to the board movement.
LD3/4/5/6 The LEDs will light up according to the position of the
ON or OFF user's fingertip on the linear touch sensor.
When connecting the STM32F072 Discovery board to a PC, the LEDs LD1 (COM)
and LD2 (PWR) will light up and four LEDs LD3, LD4, LD5, LD6 are blinking.
Press the User button B1 to enable the gyroscope MEMS sensor (L3GD20). The
four LEDs will indicate the board motion, direction and speed.
Connect STM32F072 Discovery board to a PC with a 'USB type A to Micro-B'
cable through USB connector CN2 (USB USER). This converts the board to a
standard mouse. Press User button to start the USB test. Move the STM32F072
Discovery board and see the mouse move according to the board movement.
Press the User button again to enable the linear touch sensor; the four LEDs will
be ON or Off according to the position of the fingertip on the linear touch sensor.
DocID025256 Rev 1
Displayed description
Quick start
Main function
LEDs blinking
MEMS sensor
Standard mouse
Linear sensor
