Congratulations !
You have purchased the latest in Benchtop Specific Ion-pH-mV-Temperature instrumentation. We
trust that your new 900-I3 will give you many years of reliable service.
The 900-I3 is a breeze to operate. This manual has been designed to help you get started, and also
contains some handy application tips. If at any stage you require assistance, please contact either
your local TPS representative or the TPS factory in Brisbane.
The manual is divided into the following sections:
1. Table of Contents
Each major section of the handbook is clearly listed. Sub-sections have also been included to
enable you to find the information you need at a glance.
2. Introduction
The introduction has a diagram and explanation of the display and controls of the 900-I3. It
also contains a full listing of all of the items that you should have received with unit. Please
take the time to read this section, as it explains some of items that are mentioned in subsequent
sections.
3. Main Section
The main section of the handbook provides complete details of the 900-I3, including operating
modes, calibration, troubleshooting, specifications, and warranty terms.
4. Appendices
Appendices containing background information and application notes are provided at the back
of this manual.
TPS Pty Ltd
4 Jamberoo Street
Springwood, Brisbane,
Australia, 4127
Phone
: (07) 32 900 400
International : 61 7 32 900 400
Fax
: (07) 3808 4871
International : 61 7 3808 4871
E-mail
:
tps@tpssite.com.au
Web Site
: www.tpssite.com.au
900-I3
Three Channel Specific Ion-
pH-mV and Temp. Meter
Date
: 04-Sep-98
Author : MS
