Excel Two Bag Catcher Operator's Manual page 29

Catcher Frame
INDEX NO.
124505
PART NO. QTY.
1 781567 2
2 604887 2
3 121303 1
4 029629 4
5 605662 2
6 016899 6
7 029751 2
8 121489 2
9 768523 2
10 036236 2
11 025395 4
12 767954 4
13 054502 4
14 120864 1
15 604475 1
16 068551 1
17 704916 1
18 768515 2
DESCRIPTION
NT .500-13 NL G5
CE .375 X 3.00 WITH BALE
CATCHER FRAME
CS .375-16 X .75 HX FLK
TENSION ROD
NT .375-16 HX FLK ZNYC
CS .375-16 X 1.00 HX FLK
WEIGHT PLATE
FW .343 X .687 X .051/.080H
CS .312-18 X 1.00 HX G5
CB .375-16 X 1.00 G5 ZNY
FW 0.379 X 0.813 X 0.063
NT 0.375-16 HX G5
LATCH SUPPORT
BUNGEE LATCH
NT .250-20 HX ZY NL
CS .250-20 X 1.25 HX G5
FW .281 X .625 X .051/.080H
NOTES:
7-3 REV A
