Assembly Instruction; Required Tools; Packing List - Catcher; Assembly - Excel Two Bag Catcher Operator's Manual

These instructions apply to the assembly of the Excel Two
Bag Catcher on the following mowers:
Hustler Raptor Flip-Up 48/54
® ®
BigDog Blackjack 48/54
®
It is intended that these units be installed by trained Excel
service personnel. If additional assistance is required,
contact the Excel Customer Service Department.
Directions given in these instructions, for example left and
right, refer to direction while seated on the mower.
Before proceeding, read through the following instructions
to familiarize yourself, while at the same time identify and
inventory kit parts supplied.
Unpack and inspect all parts. Notify carrier of any shipping
damages immediately.

Required Tools

The following is a list of the tools required to assemble the
catcher to the mower.
• Tape measure
• One 3/8" combination wrench or socket
• Two 9/16" combination wrench or socket
• Torque wrench (with 118 ft.-lbs range) with a
15/16" hex socket
124505

ASSEMBLY INSTRUCTION

Packing List - Catcher

PART NO.
781567
604887
N/A
029629
605662
016899
029751
121489
768523
036236
025395
767954
054502
120864
604475
068551
704916
768515
552460
796649
602446
N/A
552396
604387
NOTE: Refer to the Parts Manual section (starting on 7-1) of
this manual for more detailed parts information.

Assembly

NOTE: Refer to illustrated parts listings when assembling
the unit.
NOTE: Do not remove the mower's discharge chute. The
discharge chute does not need to be removed when attaching
this catcher to the mower.
3-1
DESCRIPTION
NT .500-13 NL G5
CE .375 X 3.00 WITH BALE
CATCHER FRAME
CS .375-16 X .75 HX FLK
TENSION ROD
NT .375-16 HX FLK ZNYC
CS .375-16 X 1.00 HX FLK
WEIGHT PLATE
FW .343 X .687 X .051/.080H
CS .312-18 X 1.00 HX G5
CB .375-16 X 1.00 G5 ZNY
FW 0.379 x 0.813 x 0.063
NT 0.375-16 HX G5
LATCH SUPPORT
BUNGEE LATCH
NT .250-20 HX ZY NL
CS .250-20 X 1.25 HX G5
FW .281 X .625 X .051/.080H
CATCHER BAG
CATCHER BLADE (48" DECK)
CATCHER BLADE (54" DECK)
DECK CHUTE
CATCHER LID
UPPER CHUTE
Allow engine and muffler to cool before assembling
the catcher to the mower.
QTY.
2
2
1
4
2
6
2
2
2
2
4
4
4
1
1
1
1
2
2
1
1
1
1
1
REV A
