  • Page 1 Med-Fit Maternity TENS Pelvic Floor Stimulator Muscle Toning Stimulator TENS and Muscle Stimulator Pain Relief TENS Machine Patient Instruction & User Manual Tel: 0800 121 4626 email: sales@med-fit.co.uk...
  • Page 2 1 x Carry case 1 x User manual 1 x Pair TENS patient leads 1 x User manual To purchase extra self-adhesive pads (SA20) please visit www.tensmachineuk.com Med-Fit UK Ltd. Unit 8, Martel Court S. Park Business Park Hamilton Road Stockport SK1 2AF.
  • Page 3: Table Of Contents

    Contents GENERAL DESCRIPTION INTRODUCTION CONTROLS AND FEATURES STIMULATOR PROGRAMMES MATERNITY MODE OPERATING INSTRUCTIONS PELVIC FLOOR STIMULATOR OPERATING INSTRUCTIONS MUSCLE STIMULATOR OPERATING INSTRUCTIONS TENS PAIN RELIEF OPERATING INSTRUCTIONS GENERAL PRECAUTIONS & WARNINGS TECHNICAL SPECIFICATIONS GRAPHIC SYMBOLS ELECTRODE INSTRUCTION FOR USE...
  • Page 4: General Description

    Thank you for purchasing a Premier Range Stimulator. These devices are manufactured to the highest of medical standards using the latest and most advanced technology. Each unit is fully tested in final assembly and inspection ensuring you receive the highest quality and an extremely reliable device.
  • Page 5: Introduction

    The Med-Fit 4 in 1 Obstetric TENS and Muscle Stimulator comes with 4 modes and 12 built-in programmes: Mode 1 - Maternity Mode Mode 1 Maternity Mode Mode 2 Pelvic Floor Stimulation Mode 3 EMS Muscle Stimulator Mode 4 TENS Pain Relief...
  • Page 6: Controls And Features

    Channel 1 Boost Button Intensity controls Mode control Set control Only operational with programmes P1& P2 (Obstetic TENS mode) Channel 2 Intensity controls On-Off Up/down control pause control Keylock facility CONTROLS AND FEATURES 9v PP3 Battery Sockets for electrodes Telephone: 0800 121 4626 www.tensmachineuk.com...
  • Page 7: Stimulator Programmes

    Features Four Modulations, TENS, EMS, Muscle Toning, Conditioning, Birth and Pelvic Floor Treatment Obstetric Porgrams Mode Prog Timer Labour - Early stage contractions C = Continuous Labour - Later stage contractions C = Continuous Pelvic Floor Toning Programs Mode Prog Timer Pelvic floor toning C = Continuous...
  • Page 8: Maternity Mode Operating Instructions

    Using you TENS in Obstetric (Maternity) mode A. Insert the 9v battery provided into the battery Fig1 compartment as shown in Fig1 and fit the battery cover back in place B. Now turn on the TENS by pressing the On-Off button in the bottom left hand corner of the device Fig2...
  • Page 9 Fig7 Fig 6 When connecting the Patient leads, please ensure they are inserted completely straight and not at an angle. Pushing at an angle may bend the pins Insert both patient leads in to the sockets on top of the device Connecting the electrodes pads MATERNITY MODE The 4 self-adhesive electrodes need to be placed correctly for maximum pain relief.
  • Page 10 Switch the unit on by pressing the On-Off button as already described, ensure that the boost button is in the off position (off) and always start with programme (P1). Begin by pressing the arrow up keys. Each single press increases the intensity by 1mA. The intensity level should be set at a level which is strong and comfortable.
  • Page 11: Pelvic Floor Stimulator Operating Instructions

    Tightens & Tones the pelvic floor muscles, and restores pelvic health. Programmes 3,4,5,6 are ideal for women who have given childbirth and would like to strength, tighten and tone there pelvic floor muscles and restore pelvic health. THESE 4 PROGRAMMES ARE SPECIFICALLY RECOMMENDED FOR THE FOLLOWING Weak pelvic floor muscles PROGRAMME INDICATIONS B.
  • Page 12 1. Use the toilet before beginning the treatment if necessary. 2. Clean the probe as per the instructions. 3. Make sure the stimulator is turned off before use. 4. Connect the probe to the device as per the instructions. 5. Apply a thin coating of lubricating gel on to the vagina opening or apply a small amount of gel on to the tip of the probe.
  • Page 13 Urinary incontinence is an inability to hold urine and / or faeces until able to reach a toilet. It is often temporary, and it always results from an underlying medical condition. Women experience incontinence twice as often as men. Pregnancy, childbirth, the menopause and the structure of the female urinary tract account for this difference.
  • Page 14 URGE INCONTINENCE MIXED INCONTINENCE An overactive bladder cause leakage of large amounts of urine at unexpected times, including sleep. Sufferers experience a sudden strong urge to go to the toilet and are often unable to retain the urine. The frequency of urination also increase causing problems for ELECTRICAL STIMULATION everyday life.
  • Page 15 PRECAUTIONS 1, Read the instruction manual before use. 2. Patients with an implanted electronic device (for example, a pace maker or other device) must not undergo incontinence stimulation treatment without first consulting their WARNINGS doctor. 3. If incontinence therapy becomes ineffective or unpleasant stimulation should be discontinued until its use is re-evaluated by the physician or therapist.
  • Page 16: Muscle Stimulator Operating Instructions

    TONING AND MASSAGE THERAPY PROGRAMMES 7, 8, 9 & 10 INTENSITY LEVEL The E.M.S (electronic muscle stimulation) programmes are designed to help tighten and tone a range of muscle groups. Each programme runs for 20/30 minutes per session, on EXPLANATION OF EMS the following pages you will find recommendations for position of electrodes, you may try each programme (7, 8, 9 &...
  • Page 17 POSITION OF ELECTRODES For Muscle Stimulation, Toning and Conditioning Programmes 7, 8, 9 &10 Toning Abdominals Best results are achieved by placing the electrodes directly over the pain site. With dual machines, additional electrodes can also be used to stimulation traditional acupressure points if required.
  • Page 18 Buttocks & leg toning EMS STIMULATION MODE Electrode Placement Telephone: 0800 121 4626 www.tensmachineuk.com...
  • Page 19 Inner thigh toning Waist line toning & shaping EMS STIMULATION MODE Electrode Placement www.tensmachineuk.com Telephone: 0800 121 4626...
  • Page 20: Tens Pain Relief Operating Instructions

    HOW TENS WORKS There is nothing “magic” about Transcutaneous Electrical Nerve Stimulation (TENS). TENS is intended to be used to relieve pain. The TENS unit sends comfortable impulses through EXPLANATION OF PAIN the skin that stimulate the nerve (or nerves) in the treatment area. In many cases, this stimulation will greatly reduce or eliminate the pain sensation the patient feels.
  • Page 21 Once you have familiarised yourself with the controls and features of your TENS device, it is important to place the TENS electrodes in a position which gives the most pain relief. This may take 3 or 4 attempts to find the most suitable position, for maximum pain relief. If you are using two electrodes, place the electrodes directly onto the painful area at a position where you feel the pain starts and where it finishes.
  • Page 22 Frozen Shoulder Shoulder Pain Suggested Suggested Programmes Programmes P11, P12 P11, P12 Degenerative Arthritis: Chronic Hip Pain Cervical and Lumbar Primary Placement TENS MODE Primary Placement Alternative Placement TENS ELECTRODE PLACEMENT Suggested Suggested Programmes Programmes P11, P12 P11, P12 Primary Placement Primary Placement Alternative Placement Telephone: 0800 121 4626...
  • Page 23 Lower Back Pain Hip Neuralgia Suggested Suggested Programmes Programmes P11, P12 P11, P12 Phantom Limb, Lower Sciatica Extremity TENS MODE Primary Placement Primary Placement TENS ELECTRODE PLACEMENT Suggested Suggested Programmes Programmes P11, P12 P11, P12 Primary Placement Primary Placement Alternative Placement www.tensmachineuk.com Telephone: 0800 121 4626...
  • Page 24 Low Extremity Pain Wrist Pain Suggested Suggested Programmes Programmes P11, P12 P11, P12 Degenerative Arthritis - Primary Placement Carpal Tunnel Syndrome Knee Pain Primary Placement Alternative Placement TENS MODE Primary Placement Alternative Placement TENS ELECTRODE PLACEMENT Elbow & Forearm Pain Suggested Suggested Programmes...
  • Page 25 Lower Leg Pain Knee Pain - Post-Op Suggested Suggested Programmes Programmes P11, P12 P11, P12 Cervical Placement Chronic Cervical Strain Primary Placement Primary Placement TENS MODE Alternative Placement Alternative Placement TENS ELECTRODE PLACEMENT Suggested Suggested Programmes Programmes P11, P12 P11, P12 Primary Placement Primary Placement Alternative Placement...
  • Page 26: General Precautions & Warnings

    Contraindications Related to Pregnancy: DO NOT USE the TENS prior to 37 weeks of your pregnancy unless under medical Precautions & Warnings supervision. DO NOT PLACE the Self-adhesive Electrode in the area of the abdomen without medical supervision. The Mums to Be TENS offers three other modes of operation, Pelvic Floor Stimulation, Muscle Toning Stimulation and General Pain Relief.
  • Page 27 Turn the TENS off before applying or removing electrodes. Isolated cases of skin irritation may occur at the site of electrode placement following long term application. If this occurs, discontinue use and consult your physician. If TENS therapy becomes ineffective or unpleasant, stimulation should be discontinued and consult your physician.
  • Page 28: Technical Specifications

    Mechanism Technical Description Channel Dual isolated between channels Pulse Amplitude Adjustable, 0-100mA peak into 500ohm load each channel Wave Form Asymmetrical Bi-Phasic Square Pulse Voltage Form 0- to 500V (Load: 500ohm) Power source One 9 Volt Battery Size 11.8cm(L) x 6cm(W) x 3.1cm(H) Weight 157 grams with battery Timer...
  • Page 29: Graphic Symbols

    Degree of electrical Protection BF Do not insert the plug into AC power supply socket Timer Increment Decrement Consult instructions for use Manufacturer Serial number GRAPHIC SYMBOLS Lock Low battery Pause DC current (DC Power source) Comply with MDD 93/42EEC requirements as amended by 2007/47/EC. Notify body Det Norske Veritas (DNV) Power www.tensmachineuk.com...
  • Page 30: Electrode Instruction For Use

    Turn Stimulator OFF before applying or removing electrodes Application 1. Skin site must be very clean and dry, dirty, flaky or oily skin will prevent electrodes from adhering to the skin. If necessary, trim excess hair with scissors. If skin is oily wipe down with an alcohol or electrode skin prep prior to application.
  • Page 31 Manufacturer: All EV-806 Digital TENS/EMS models carry a warranty of one year from the date of delivery. The warranty applies to the stimulator only and covers both parts and labor relating thereto. Representative in the EU: The warranty does not apply to damage resulting from failure to follow the operating instructions, accidents, abuse, alteration or disassembly by unauthorized personnel.
  • Page 32 This product needs special precautions regarding EMC and needs to be installed and put into service according to the EMC information provided, and this unit can be affected by portable and mobile RF communications equipment. 1)* Do not use a mobile phone or other devices that emit electromagnetic fields, near the unit.
  • Page 33 Guidance and manufacture’s declaration – electromagnetic immunity The DEVICE is intended for use in the electromagnetic environment specified below. The customer or the user of DEVICE should assure that it is used in such an environment. Immunity test IEC 60601 Compliance level Electromagnetic environment test level...
  • Page 34 Guidance and manufacture’s declaration – electromagnetic immunity The DEVICE is intended for use in the electromagnetic environment specified below. The customer or the user of DEVICE should assure that it is used in such an environment. Immunity test IEC 60601 Compliance Electromagnetic environment test level level - guidance...
  • Page 35 Recommended separation distances between portable and mobile RF communications equipment and the DEVICE . The DEVICE is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the DEVICE can help prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and the DEVICE as recommended below, according to the maximum output power of the communications equipment.
