- Page 1 The Quick and Easy User Guide for the Maxi Stim EMS Plus Neuromuscular Stimulator Please read this User Manual before using your Device Tel: 0161 429 7330 www.tensmachineuk.com email: sales@thetenscompany.co.uk...
- Page 2 Thank you for purchasing a Med-Fit Maxi EMS Plus Stimulator. This device is manufactured to the highest of medical standards using the latest and most advanced technology. Each unit is fully tested in final assembly and inspection ensuring you receive the highest quality and an extremely reliable device.
-
Page 3: Table Of Contents
Contents STEP BY STEP GUIDE MUSCLE STIMULATOR PROGRAMMES MANUAL ADJUSTMENTS INTRODUCTION HOW EMS WORKS CAUTIONS CONTRAINDICATIONS ADVERSE REACTIONS WARNINGS ELECTRDOE INSTRUCTIONS EMS PROGRAMMES ELECTRODE PLACEMENT TECHNICAL SPECIFICATIONS www.tensmachineuk.com Telephone: 0161 429 7330... -
Page 4: Step By Step Guide
This easy to use instruction manual, explains how to set up the Med-Fit Maxi-Stim EMS Plus in programme mode. Install the PP3 9V battery supplied into the compartment at the rear of the device. Fig A STEP BY STEP GUIDE Telephone: 0161 429 7330 www.tensmachineuk.com... - Page 5 Easy to use 2 channel stimulator offers 12 clinically approved pre-set programmes P1-P12. Switch on your device by turning one of the rotary controls located at the top of your stimulator. To change the programme simply press the up/down keys to the desired programme. To access the controls, open the front cover (opens from the left hand side see Fig B) for control functions.
- Page 6 You are now ready to use your device. It is recommended to now turn off the device and connect the patient leads to the sockets as shown in Fig C. Depending on the condition and treatment area, you may use any number of electrodes up to a maximum of 4 electrodes and 2 channels.
-
Page 7: Muscle Stimulator Programmes
MUSCLE STIMULATOR & MASSAGE PROGRAMMES Programmes P1 - P4 Muscle Training & Muscle Re-Education Programmes Choose from one fo the programmes 1, 2, 3 and 4 Suitable Conditions These programmes can be used for muscle training, prevention of muscle atrophy. Please follow the electrode placement chart for individual muscles shown on pages 16 to 23. -
Page 8: Manual Adjustments
Choose the desired mode by pressing the mode Mode Button There are 3 modes available Constant, Synchronous and Alternate. Constant Constant or normal is stimulation based on setting value. Only pulse width, pulse rate and timer are adjustable in this mode. - Page 9 Frequency Selection With all muscle stimulators, it is important that the frequency, pulse width and 15-25Hz (pulse per second) work rest times are set correctly, to both maximise the results and use the device in a safe and responsible manner. 25-50Hz (pulse per second) The range of frequencies helps to promote muscle endurance and conditioning.
- Page 10 Work Rest (Contraction /Relaxation) Times When setting the work / rest times it is important that the rest time is at least Ramp Time equal to the work time; for example 4 seconds on time 4 seconds off time. For weaker muscles a larger rest time will be required for example 4 seconds on This allows for muscle recovery and reduces muscle fatigue.
-
Page 11: Introduction
EXPLANATION OF EMS This EMS unit is used for muscle stimulation. The device is provided with controllable output channels, each independent of the other. A pair of electrodes can be connected to each output channel. An independent switch controls the intensity level and settings. -
Page 12: Cautions
1. Safety of powered muscle stimulators for use during pregnancy has not been established. 2. Caution should be used for patients with suspected or diagnosed heart problems. 3. Caution should be used for patients with suspected or diagnosed epilepsy. 4. Caution should be used in the presence of the following: a. -
Page 13: Warnings
It is imperative that patients read and understand the warnings and precautions before using this device. Do not allow your machine or electrodes to be used by anyone else, as they are designed for single patient use only. It is recommended that proper medical advice on the use of EMS is sought from a Qualified Practitioner (Physiotherapist, Doctor or Nurse) prior to use, in order to ensure safe and effective treatment. - Page 14 1. Non-flammable cleaning solution is suitable for cleaning the device. Note: Do not smoke or work with open lights (for example, candles, etc.) when working with flammable liquids. 2. Stains and spots can be removed with a cleaning agent. 3. Do not submerge the device in liquids or expose it to large amounts of water. 4.
-
Page 15: Electrdoe Instructions
Turn Stimulator OFF before applying or removing electrodes Application 1. Skin site must be very clean and dry. Dirty, flaky or oily skin will prevent electrodes from adhering to the skin. If necessary, trim excess hair with scissors. If skin is oily wipe down with an alcohol or electrode skin prep prior to application. -
Page 16: Ems Programmes
These 12 individual electronic muscle stimulator (E.M.S) programmes have been clinically proven for the treatment of 1. Muscle Re-Education 2. Muscle Training 3. Muscle Strengthening 4. Muscle Toning Please refer to the electrode placement charts provided for recommended treatment time and suggested programmes. It is important to remember to take professional medical advice wherever possible. -
Page 17: Electrode Placement
There are many questions as to the optimal position for the adhesive electrodes during an electro-stimulation session. Consequently, we are going to try to answer your various question by setting out below the effective positions for the sport (rectangular) and beauty (round) electrodes for different areas of the body. We are definitely not trying to give an anatomy class here but is is necessary to understand the whole muscle system to get a more precise grasp of the human muscle system. - Page 18 Forearm Biceps ELECTRODE PLACEMENT www.tensmachineuk.com Telephone: 0161 429 7330...
- Page 19 This position is useful for muscle training and for gaining volume using the devices' muscle strengthening programmes. But it is equally very useful for diminishing the effects of lactic acid (substances manufactured by the muscles after sporting exertion and that result in pain during the following few hours).
- Page 20 Internal Thigh Thigh ELECTRODE PLACEMENT Telephone: 0161 429 7330 www.tensmachineuk.com...
- Page 21 The Gluteals This position is ideal for shaping the gluteal muscle. The Trapezius muscles and Dorsals ELECTRODE PLACEMENT www.tensmachineuk.com Telephone: 0161 429 7330...
- Page 22 The Legs and Calves The medial and lateral gastrocnemius ELECTRODE PLACEMENT Telephone: 0161 429 7330 www.tensmachineuk.com...
- Page 23 The Abdominals It is the abdominal muscle which, when electro-stimulated, will make a six-pack appear. The Pectorals BE SURE to follow the positioning. ELECTRODE PLACEMENT DO NOT POSITION ON THE HEART AREA ! www.tensmachineuk.com Telephone: 0161 429 7330...
-
Page 24: Technical Specifications
MECHANISM TECHNICAL DESCRIPTION Channel Dual, isolated between channels Pulse Amplitude Adjustable, 0-100 mA peak into 500 ohm load each channel. Wave Form Asymmetrical Bi-Phasic Square Pulse Voltage 0 to 50V (Load: 500 ohm) Power source One 9 Volt Battery Size 10.1cm(L) x 6.1cm(W) x 2.45cm(H) Weight 150 grams with battery. -
Page 25: Ems
Guidance and manufacture’s declaration – electromagnetic immunity The DEVICE is intended for use in the electromagnetic environment specified below. The customer or the user of DEVICE should assure that it is used in such an environment. Immunity test IEC 60601 Compliance level Electromagnetic environment test level... - Page 26 Guidance and manufacture’s declaration – electromagnetic immunity The DEVICE is intended for use in the electromagnetic environment specified below. The customer or the user of DEVICE should assure that it is used in such an environment. Immunity test IEC 60601 Compliance Electromagnetic environment test level level - guidance...
- Page 27 Recommended separation distances between portable and mobile RF communications equipment and the DEVICE . The DEVICE is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the DEVICE can help prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and the DEVICE as recommended below, according to the maximum output power of the communications equipment.
- Page 28 0161 429 7330 0161 427 0215 Tel: Fax: www.tensmachineuk.com...
