- Page 1 OG-8800...
- Page 2 Assembly Instructions Ogawa AI Master Drive massage chair arrives in 3 boxes. THIS SIDE UP Calibrated Instument Please Do Not Drop Ogawa AI Master Drive. OG-8800B-5083 Ogawa OG-8800 BLUE & SAND BLUE & SAND Calibrated Instument Calibrated Instument Please Do Not Drop...
- Page 3 Adjust chair position. Use the power cord to connect the chair to the power supply and turn on the power Remove cotter pins and bolts from chair base. Locate the two cotter pins and bolts on the chair base. switch. The chair will go back to home position. Then disconnect the power cord. Take them off...
- Page 4 Connect wires in footrest. Connect both footrest wire connectors and screw the caps tight. Then connect the Open box 2 with side boards. Take out the side boards. Detach the cover from the side board. air hose. Caution: After the wire connector has been connected the cap must be screwed tight. Here is how you detach the side board cover.
- Page 5 Attach the right side board cont. Move the right side board close to the chair. Route the air hose and wire through the hole of the side board. Then fix the side board with screw, nut, and washer. Here is the one way air hose. Here is what it will look like with all the wires connected.
- Page 6 Assemble the decoration strip. First, attach the decoration strip. Then fix it with six cross recessed pan head Attach the speaker covers. These are also attached by snap joints. Attach the side covers first, then the decoration screws. strip on the top. Attach the side board covers.
- Page 7 Attach the remote control holder. Remove the screw first, then fix the remote control holder onto the armrest. Attach the backrest pad to the backrest. Zip the zipper on top of the backrest. Then fix the elastics of the Secure it with the screw nut. Then attach the pulse sensor and tablet onto the holder. backrest pad to the backrest.
- Page 8 Attach the seat pad. Then zip the zipper between the seat pad and footrest cushion. Turn on the chair. Connect the chair to a power supply and turn on the power switch.
