Half Bar
Added this function: if pressed during the first half of the measure, the 1/2 bar fill is
heard during the current measure. However if pressed during the 2
measure, the 1/2 bar fill is played at the beginning of the next measure.
Tempo accelerando/ritardando
By pressing Tempo button together in the STYLE mode, the Tempo related features
are displayed. Now, by touching and holding down for 2 seconds the ACC icon, you
can access editable parameters for both accelerando and ritardando. Touching either
the EXIT icon on the screen or on the panel returns the keyboard to the normal screen.
The new functions available in the EDIT mode are – Step, Lower, Limit and Upper Limit.
• Step
Once turned on, this allows you to change the « rate » of acceleration or
deceleration, so the tempo will increase/decrease in steps of x, rather than the
default steps of 1:
➢ Range from 1–20: the change in tempo will be proportional to the
quantity defined for each measure.
➢ Range from 1-20 beat: the tempo will be proportional to the value
defined by each bar
• Lower Limit
Use to set the lowest tempo value the style can go to when Ritardando is used,
however please note that the value for the tempo (set in View => Drum) will
take precedence over any minimum tempo value set.
• Upper Limit
Use to set the highest tempo value the style can go to when Accelerando is
used, however please note that the value for the tempo (set in View => Drum)
will take precedence over any maximum tempo value set.
The default values are: Step=5 (bar), Lower Limit=40, Upper Limit = 250.
The defined values can be saved within the CUSTOM STARTUP. The accelerando &
ritardando set values can also be saved within each style independently. If a style has
these values, these will super exceed the default values saved within the CUSTOM
STARTUP menu.
Once the style has been stopped, the values return either to the default numbers (min
= 40, max=250) or that stored within the CUSTOM STARTUP. In the PLAYER mode
(when using Midifiles), the values that have been 'edited' into or stored within the
Midifile are those that will be used (ranging from 1-20 bars).
SD7 - Update 1.3.0
nd
half of the
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for KETRON SD7
Summary of Contents for KETRON SD7
- Page 1 SD7 - Update 1.3.0 Half Bar Added this function: if pressed during the first half of the measure, the 1/2 bar fill is heard during the current measure. However if pressed during the 2 half of the measure, the 1/2 bar fill is played at the beginning of the next measure.
- Page 2 Registration Registrations can now be loaded from USB sticks. Registrations name are up to 30 characters. Complete save feature on Registration for Voice families. Store of Intro of style: if in start, the style starts with the Intro saved, if in stop and key start the style starts with the intro saved at the touch of a button or by Start button.
- Page 3 Changed the Wah Wah 4 preset and changed the response curve on the volume pedal in the case of an inserted Wah-Wah EFX. Second Voice From the main menu while holding down the 2nd Voice tab, you access directly the second tone selection menu.
- Page 4 This may be useful if any anomalies should occur. Whole disk check Pressing both the TALK + FADE & Enter enables the SD7 to do a complete disk check. This function takes quite some time and so the instrument should not be switched off during this procedure.
- Page 5 The function can be saved on Custom Startup, on Footswitch and User Tabs (Bass Sus. Disk edit Folders are no longer automatically available when the Disk Edit button is turned on. Locked navigation if SD7 is connected to the PC (PC-CONNECT ON).
- Page 6 Player Position track in the Player menu is now available with an enlarged font. Search function in the Playlist can only be activated for searching for files within a Playlist and not for searching the playlist with the arrow and or dial buttons. Fixed Pdf display problem when used with Mp3 / Wav + Pdf file selected after a Midifile with lyric (when pdf was disabled after the start of the Mp3).
- Page 7 you to select also Fill, Break, Intro, Ending (with Reintro) with the style in stop. With SAVE you can save the style with the changes made on the modeling. Selection The selection of the Voice and Styles families has been corrected. Rotary Fixing issue when Rotary effect is out of Morphing mode (it sent the reverb to zero).
- Page 8 FILL/BREAK Reserve information cleared of a new FILL/BREAK if you press the same FILL/BREAK while it is already running.
